Summary of Contents for Hedson IRT AutoSpot
- Page 1 Instruction Manual (original language) Betriebsanleitung Mode d’emploi Bruksanvisning Manuale d’uso Manual de funcionamiento IRT AutoSpot 196363 rev 1 ©Hedson Technologies AB 2018...
-
Page 2: Table Of Contents
TABLE OF CONTENTS - original language Safety instructions ............3 Intended use of the product ........3 Product description .............3 Instructions to the owner ..........4 Assembly instruction ...........4 Basic instruction for operation ........4 Program mode .............5 Extended usage information ........6 Settings mode .............6 10. -
Page 3: Safety Instructions
Final boost Soft cure 13-17 Intended use of the product The IRT AutoSpot infrared dryer can be used either on 3.1.3 Regulated temperature stand with control unit or handheld. This product serves The dryer has a pyrometer which carefully controls exclusively to accelerate the drying/curing of putty, filler, temperature of the object. -
Page 4: Instructions To The Owner
Basic instruction for operation Technical data All dryers emit shortwave IR-radiation with a peak at Keyboard 1120 nm. Voltage 220–240 V 1Ph/PE Frequency 50–60 Hz Current Software defined button Software defined button Power 2 kW Confirmation choices Cancellation choices Fuse* 10 A The dryer shall be operated with the recommended fuse rating. -
Page 5: Program Mode
Program Mode – General rules for navigation in the software – The display shows software defined options in the bottom corner fields. To adjust the values use the arrow keys. – – To move to previous display without saving, press cancel. Basic navigation There are twelve predefined programs and three empty ones. -
Page 6: Extended Usage Information
Extended usage information Settings Mode Temperature control Log In The mobile dryer is equipped with an automatic tem- To enter the settings mode you first have to log in. Press both arrow keys as you turn the main switch on. The perature control. - Page 7 Settings 9.4.6 8 Short Distance Limit The original settings for the correct short distance limit available in is 55 cm. You can change the value for the short distance Overview Basic Advanced limit from 35 to 95 cm. Settings higher than 80 cm are 9.4.1 1 Select Language not recommended.
- Page 8 9.4.15 43 Advanced Code Test 5: Ventilator Test/cassette The ventilator in the cassette now starts. A sound from It is possible to enable/disable the request for a PIN code. This will remove the PIN code request in program the ventilator confirms that it is working. Press enter or mode and the code 0000 will give you access to ad- next to continue.
-
Page 9: Programming Examples
10. Programming examples EX 1. FLASH OFF/PREHEATING Initial temperature 20°C/86°F Time 4 min Temperature increase 15°C/27°F /min Final temperature 80°C/176°F FULL BAKE/CURING Initial temperature 60°C/140°F Time 0 min t (min) Temperature increase 5°C/9°F /min EX 2. FLASH OFF/PREHEATING Initial temperature 20°C/86°F Time 4 min... -
Page 10: Maintenance And Service
11. Maintenance and Service 11.1 IRT lamp replacement Attention! Weekly Do not touch either the gold coated reflector or the new Check that all IR lamps light up during mobile dryer op- IR lamp with your fingers. Only remove the protective eration. -
Page 11: Spare Parts
12. Spare parts Position Qty Part no. Description 421074 Bracket twin reflector Position Part no. Description Washer 8.4x24x2 DIN9021 713585 Reflector FF2 713904 Reflector FF2 with foil and lamp- 712393 Lamp holder holders Surfac Drawn by Approved by Scale View type treatm Certified by 104074... -
Page 12: Ec Declaration Of Conformity
According to testing institutes and according to the machinery directive the IRT product in this manual are not defined as machines, wherefore the machinery directive reference cannot be included in this declaration. In accordance with EN 17050-1:2010 Hedson Technologies AB Box 1530 SE-462 28 Vänersborg... -
Page 13: Electrical Diagrams
14. Electrical diagram • Elektrischer Schaltplan • Schéma de cablage électrique • Elschema • Schemi elettrici • Diagrama eléctrico 196363 rev 1... -
Page 14: Weight And Dimensions
15. Weights and dimensions • Gewicht und Abmessungen • Poids et dimensions • Vikt och dimensioner • Peso e dimensioni • Peso y Dimensiones Dimensions in mm Weight 17,2 kg 196363 rev 1... - Page 15 196363 rev 1...
- Page 16 © Hedson Technologies 2018 The manufacturer reserves the right to introduce technical modifications. Tel +46 (0) 521 28 12 30 HEDSON TECHNOLOGIES AB Telefax +46 (0) 521 28 12 31 Nygatan 100, Box 1530 industrialcuring@hedson.com SE-462 28 Vänersborg www.hedson.com SWEDEN...
