Wall hung, fanflue, roomsealed, high efficiency open vent gas boiler
Service manual
Service manual
ADVANCE
Models
ADVANCE 15OV
ADVANCE 18OV
ADVANCE 24OV
Leave this manual adjacent to the gas meter
Warning:
Service / repairs must be carried out, only by a qualified Gas Safe Registered
Engineer, who will be responsible for the current Regulations for gas
appliances.
Note:
After servicing, complete the relevant Service Interval Record section of the
Benchmark Checklist of the user and installation manual.
G.C. Appl. No.
41-583-35
BOILER
41-583-36
BOILER
41-583-37
BOILER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biasi ADVANCE 15OV
Summary of Contents for Biasi ADVANCE 15OV
- Page 1 Wall hung, fanflue, roomsealed, high efficiency open vent gas boiler Service manual Service manual ADVANCE Models G.C. Appl. No. ADVANCE 15OV 41-583-35 BOILER ADVANCE 18OV 41-583-36 BOILER ADVANCE 24OV 41-583-37 BOILER Leave this manual adjacent to the gas meter Warning:...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1 OVERALL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . .3 9 TEMPERATURE PROBE . -
Page 3: Overall Information
OVERALL INFORMATION OVERALL INFORMATION 1 .1 Overall View Flue temperature probe NTC and Safety thermal fuse Condensing heat exchanger Ighition Burner electrodes Detection electrode C.H. return temp. probe NTC C.H. flow temp. probe NTC Air/gas mixer Safety thermostat Pipe silencer Condensate Electronic controlbox trap... -
Page 4: General Access And Emptying Hydraulic
GENERAL ACCESS AND EMPTYING HYDRAULIC CIRCUITS GENERAL ACCESS AND EMPTYING HYDRAULIC CIRCUITS 2 .1 Nomenclature Figure 2 .2 - Bottom view of the boiler Pull the lower part of the front panel and lift it upwards (Figure 2.3). Figure 2 .1 1 Right side panel 2 Front panel 3 Control panel... -
Page 5: Control Panel
GENERAL ACCESS AND EMPTYING HYDRAULIC CIRCUITS Figure 2 .4 Figure 2 .6 2 .3 Control panel 2 .4 Main electronic p .c .b . box Warning: isolate the boiler from the mains electrici- Warning: isolate the boiler from the mains electrici- ty supply before removing any covering or compo- ty supply before removing any covering or compo- nent . -
Page 6: Emptying The Primary Circuit
GENERAL ACCESS AND EMPTYING HYDRAULIC CIRCUITS 2 .5 Emptying the primary circuit Main electronic p .c .b . lid removal To get access to the main electronic p.c.b.: 1 Isolate the cold feed to the F&E tank, also if fitted isolate the 5 Pull the box that contains the electronic p.c.b. and rotate it heating circuit flow and return valves. -
Page 7: Diagrams
DIAGRAMS DIAGRAMS 3 .1 Wiring diagram Gas valve Flame detection Ignition electrode electrodes gnye gnye C.H. temperature probe NTC return Flue temp. probe NTC Safety thermal fuse Fuse 2AF 250VAC 5x20 gnye C.H. temperature probe NTC flow Safety thermostat Time switch (option) Remote External temp. -
Page 8: Circuit Voltages
DIAGRAMS 3 .2 Circuit voltages Electrical voltages with burner on only during C.H. operation C.H. external pump Gas valve Safety Supply network thermostat Figure 3 .2 - 8 -... -
Page 9: Fault Finding
FAULT FINDING FAULT FINDING - 9 -... - Page 10 FAULT FINDING - 10 -...
-
Page 11: Display Diagnostic
FAULT FINDING 4 .1 Display diagnostic The display indications provide help in the diagnosis of fault find- ing. The control panel display gives other information for the user. The following table gives fault code, error and the reson for the fault. Er 01 + RESET Lack of burner ignition Er 02 + RESET Safety thermostat lockout Er 03 + RESET Other faults Faulty primary circuit (no water or absence Er 04 +... -
Page 12: Condensing Heat Exchanger
CONDENSING HEAT EXCHANGER CONDENSING HEAT EXCHANGER 5 .1 Function The Condensing heat exchanger "A" in Figure 5.1 has the func- tion of transferring heat produced from combustion of the gas and from the flue exhausted gas to the water circulating in it. Figure 5 .1 By reducing the combustion products temperature, the latent heat of the vapour is transferred to the water circuit, allowing an extra gain of useful heat. -
Page 13: Cleaning
CONDENSING HEAT EXCHANGER 14 Reassemble the Condensing heat exchanger carrying out the removal operations in reverse order. Ensure to tighten the nuts "H" - Figure 5.2 firmly. 5 .3 Cleaning If there are deposits of dirt on the coil of the Condensing heat exchanger, clean with a bristle paintbrush and remove the dust with a hoover. -
Page 14: Main Electronic Control/Ignition P.c.b
MAIN ELECTRONIC CONTROL/IGNITION P.C.B. MAIN ELECTRONIC CONTROL/IGNITION The fundamental function of the Main electronic control/ignition P .C .B . p.c.b. is that of controlling the boiler in relation to the external needs (i.e. heating the dwelling) and operating in order to keep 6 .1 Function the temperature of the hydraulic circuits constant. -
Page 15: Checking The Temperature
MAIN ELECTRONIC CONTROL/IGNITION P.C.B. Figure 6 .2 1 Connector - ignition electrode. 2 Connector - flame detection electrode 3 Connector - controller fan 4 Connector - C.H. return temperature probe NTC 5 Connector - flue temperature probe NTC 6 Connector - external temperature probe (optional) 7 Connector - safety thermostat and C.H. flow temperature probe NTC 8 Connector - remote control (optional) Figure 6 .3... - Page 16 COMMISSIONING section: Setting record . PARAMETER DIGIT VALUES Boiler type (to be Pr 01 00 = No power Er 99 updated with the 15 = ADVANCE 15OV complete range) 18 = ADVANCE 18OV 29 = ADVANCE 24OV Not used Pr 02...
-
Page 17: Checks
Switch off and on the electricity supply to the boiler, by means of Natural gas (G20) the fused spur isolation switch, the device must not unlock and 70 = ADVANCE 15OV the burner must not turn on. 51 = ADVANCE 18OV... - Page 18 MAIN ELECTRONIC CONTROL/IGNITION P.C.B. Figure 6 .11 6 Re-assemble the Main electronic control/ignition p.c.b. fol- lowing the removal procedures in the reverse order. Important When re-assembling the Main electronic control/ignition p.c.b.: 7 It is not necessary to utilise static protections but it is advis- able to ensure that the p.c.b.
-
Page 19: Thermal Control In The Mode
MAIN ELECTRONIC CONTROL/IGNITION P.C.B. 6 .7 Thermal control in the mode Switch in the function mode Taking circulator off water from the domestic hot circulator on fan still water circuit? Temp. difference Is primary circuit between probes stop circulator (3min) temperature higher than that higher than 35°... -
Page 20: Control Panel Electronic P.c.b
CONTROL PANEL ELECTRONIC P.C.B. CONTROL PANEL ELECTRONIC P .C .B . FUNCTION Faulty pump or primary temperature 7 .1 Function Er 14 + RESET above 105° C None or too low water flow; Faulty pump Er 15 + RESET (temp. difference between probes higher than 35° C) Possible exchange of NTC probes (Flow Er 16 + RESET or Return) or pump wrongly mounted... -
Page 21: Info Modality
CONTROL PANEL ELECTRONIC P.C.B. 7 .4 Function modes setting modality FUNCTION It is possible to select the various boiler control function modes Boiler in chimney sweep in function. hereafter named “parameters” by using the keys of the control The activation of the chimney sweep oc- panel p.c.b. -
Page 22: Gas Valve
GAS VALVE GAS VALVE 8 .3 Adjustment Warning: isolate the boiler from the mains electrici- 8 .1 Function ty supply before removing any covering or compo- nent . The gas valve "A" in Figure 8.1 controls the gas inflow to the boiler burner. - Page 23 23 Read the CO % value. It should be between: Model Type gas % value (range) Natural (G20) 9,0 - 9,6 ADVANCE 15OV Propane (G31) 10,0 - 10,6 Natural (G20) 9,1 - 9,7 ADVANCE 18OV Propane (G31) 10,1 - 10,7 Figure 8 .7...
-
Page 24: Checks
GAS VALVE 26 Close the air-flue sampling points. 27 After adjustment fit the protective brass plug ("C" - Figure 8.2). Important: after the gas pressure checks and any adjust- ment operations, all of the test points must be sealed and tested with LDF . 8 .4 Checks Warning: isolate the boiler from the mains electrici- ty supply before removing any covering or compo-... -
Page 25: Temperature Probe
TEMPERATURE PROBE TEMPERATURE PROBE 9 .2 Checks Temperature-resistance relationship 9 .1 Function The Temperature probe has the function of converting the tem- Warning: isolate the boiler from the mains electrici- ty supply before removing any covering or compo- perature of the water in the hydraulic circuit where it is installed into an electrical signal (resistance). - Page 26 TEMPERATURE PROBE Figure 9 .4 - 26 -...
-
Page 27: Fan And Air Box
FAN AND AIR BOX 10 FAN AND AIR BOX 3 Disconnect the air manifold "E" (Figure 10.2). 4 Unscrew the gas connector "F" and remove the gas pipe "G". 10 .1 Function 5 Disconnect the connector "C". The function of the Fan "A" (Figure 10.1) is to force the mixture of 6 Disconnect the fan connector "D"... -
Page 28: Ignition, Detection Electrodes And Burner
IGNITION AND DETECTION ELECTRODES 11 IGNITION, DETECTION ELECTRODES 2 Disconnect the ignition electrodes connector "D" and the AND BURNER earth wire "E" (Figure 11.1) and disconnect the detection electrode connector "F". 11 .1 Function 3 Unscrew the screws "G" and remove the ignition electrodes Three electrodes are fitted on the fan-burner group. -
Page 29: Removal Of The Burner
IGNITION AND DETECTION ELECTRODES page 28). 2 Remove the front insulation panel by sliding it forward (Figure 11.4). 3 Assemble the new front insulation carrying out the removal Locating tab operation in reverse order. When fitting the new panel ensure that the electrodes holes coincide with the holes of the com- bustion chamber. -
Page 30: Checks
IGNITION AND DETECTION ELECTRODES 11 .7 Checks 1 Remove all the case panels and the sealed chamber lid. Check of the spark generator 2 Check for the integrity of the insulation of wires which con- nect the electrodes to the spark generator and to the control/ Warning: isolate the boiler from the mains electrici- ignition p.c.b. -
Page 31: Safety Thermostat
SAFETY THERMOSTAT 12 SAFETY THERMOSTAT 12 .3 Removal 12 .1 Function Warning: isolate the boiler from the mains electrici- ty supply before removing any covering or compo- The safety thermostat "A" in Figure 12.1 is a device that senses nent . the temperature of the primary circuit water which flows in the outlet pipe of the condensing heat exchanger. -
Page 32: Flue Temperature Probe Ntc And Safety
4 Assemble the Flue temperature probe NTC and Safety ther- and bends. mal fuse carrying out the removal operations in reverse se- Only authentic and original Biasi HE flue components should be quence. used with this product. 5 Ensure the probe seal is in a good serviceable condition to avoid POC and condensate leakage. - Page 33 FLUE TEMPERATURE PROBE NTC AND SAFETY THERMAL FUSE 12500 12000 11500 11000 10500 10000 9500 9000 8500 8000 7500 7000 6500 6000 5500 5000 4500 4000 3500 3000 2500 2000 1500 1000 °C 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Figure 13 .4 - 33 -...
-
Page 34: Condensate Trap
CONDENSATE TRAP 14 CONDENSATE TRAP 14 .3 Removal Warning: isolate the boiler from the mains electrici- 14 .1 Function ty supply before removing any covering or compo- nent . The condensate trap "A" in Figure 14.1 and Figure 14.2 allows the discharge of the condensate via the condensate drain pipe 1 Remove the front and right case panels. -
Page 35: Short Spare Parts List
Description Q .ty Manufacturer Manufacturer’s no . part no . reference Burner BI1563 102 (mod. ADVANCE 15OV, ADVANCE 18OV) Burner BI1563 103 (mod. ADVANCE 24OV) Condensing heat exchanger BI1782 101 (mod. ADVANCE 15OV, ADVANCE 18OV) Condensing heat exchanger BI1782 102 (mod. - Page 36 *1796232450* 17962.3245.0 0719 36A4 Biasi UK Ltd Commercial Road Leamore Enterprise Park WALSALL WS2 7NQ Sales Tel. 01922 714600 Tech. Service Tel. 01922 714636 www.biasi.co.uk...
