MOTION SENSOR CAMERA INSTRUCTION MANUAL

You know when

you're in safe hands!

www.killgerm.com

Killgerm Motion Sensor Camera

Instruction Manual

Instruction Manual was adapted and edited by Killgerm Chemicals Ltd

Table of Contents

Need help?

Do you have a question about the Motion Sensor Camera and is the answer not in the manual?

Questions and answers

Summary of Contents for Killgerm Motion Sensor Camera

Page 1 MOTION SENSOR CAMERA INSTRUCTION MANUAL You know when you’re in safe hands! www.killgerm.com Killgerm Motion Sensor Camera Instruction Manual Instruction Manual was adapted and edited by Killgerm Chemicals Ltd...
Page 2: Table Of Contents
MOTION SENSOR CAMERA INSTRUCTION MANUAL Contents 1. General Description................3 2. Quick set-up guide................. 4 3. Camera Body Interface..............5 4. Camera Display Infomration............7 5. User Settings..................8 6. Settings Menu................10 7. Text messaging / MMS and Email / SMTP functionality.....12 8. Network settings for text/MMS …..........15 9.
Page 3: General Description
MOTION SENSOR CAMERA INSTRUCTION MANUAL 1. General Information This digital trail camera isn’t just a standard motion sensor camera that takes pictures and records video. It also has text/MMS and email/SMTP capabilities built into the camera. It is triggered by any movement day and night by animals or humans in the region monitored by the camera.
Page 4: Quick Set-Up Guide
MOTION SENSOR CAMERA INSTRUCTION MANUAL 2. Quick guide set-up The below steps are a brief instruction in setting up your camera to help you get started. However, we would advise you read this whole document to set up your camera fully, especially if you are utilising the text/email functionally provided: Step 1: Open-up the camera and insert the x8 AA batteries and Micro SD Card into their specific slots.
Page 5: Camera Body Interface
MOTION SENSOR CAMERA INSTRUCTION MANUAL 3. Camera Body Interface The camera has the following interfaces: USB connector, SIM card slot, TV output and external DC power connect slot. Internal layout: 1. 2inch colour LCD display screen 8. Menu button 2. Shot button 9.
Page 6 MOTION SENSOR CAMERA INSTRUCTION MANUAL Front of camera layout Front of camera layout...
Page 7: Camera Display Infomration
MOTION SENSOR CAMERA INSTRUCTION MANUAL 4. Camera display information 4. Camera display information The information in the diagram below will display when the camera is placed The information in the diagram below will display when the camera is placed into into “TEST”...
Page 8: User Settings
MOTION SENSOR CAMERA INSTRUCTION MANUAL 5. User Settings There are a variety of functions that can be used and set on the camera including; camera set-up, manual capture and preview. To use these functions and set the camera settings, first place the camera into “TEST”...
Page 9 MOTION SENSOR CAMERA INSTRUCTION MANUAL Field Use - Putting into “ON” Mode Before field use, please pay attention to the following information: • Do not face directly into a light course as it may cause false triggers. • Place a minimum of 1m from the ground to provide an optimum space to capture.
Page 10: Settings Menu
MOTION SENSOR CAMERA INSTRUCTION MANUAL 6. Settings Menu Press the “MENU” button when the camera in the TEST mode to change and set the camera settings. System Settings: (Image 1)
Page 11 MOTION SENSOR CAMERA INSTRUCTION MANUAL Photo Settings: (Image 2) Video Settings (Image 3)
Page 12: Text Messaging / Mms And Email / Smtp Functionality
MOTION SENSOR CAMERA INSTRUCTION MANUAL 7. Text messaging / MMS and Email / SMTP functionality Preparation You will need to ensure you have the following items, before being able to set up the text messaging or email function on the camera.
Page 13 MOTION SENSOR CAMERA INSTRUCTION MANUAL 4. Software set-up • Connect the camera to the PC with the included USB cable. • Load up the MMS Configuration Software on your computer. • First select and open the software file as highlighted in image 4 below.
Page 14 MOTION SENSOR CAMERA INSTRUCTION MANUAL • Amend the information on the menu tab to set your requirements of the information you want to record and receive. Importantly – you need to change the “MODE” setting to suit you as circled in image 6.
Page 15: Network Settings For Text/Mms
IMPORTANT: Killgerm have provided the specifc Network set-up data in pre-set files which are available in the software download package from the website. These files cover the set up details for Vodafone and O2 as outlined in the following pages.
Page 16 MOTION SENSOR CAMERA INSTRUCTION MANUAL Text messaging / MMS – O2 Set-up Load up the software, and select the “MMS” tab. Once on the MMS page, switch the “Mode” to manual instead of “Auto and then input the data in each section as per the...
Page 17 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 8) Mobile number which will receive the images • Once you have completed inputting the correct network date. Click the “SAVE” button and save as “Parameter.dat” file to the MICRO SD Card. Note: Only have 1 “Parameter.dat” saved onto the MICRO SD Card at any one time or the camera won’t work.
Page 18 MOTION SENSOR CAMERA INSTRUCTION MANUAL Text messaging / MMS – Vodafone Set-up Load up the software, and select the “MMS” tab. Once on the MMS page, switch the “Mode” to manual instead of “Auto and then input the data in each section as per the...
Page 19 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 9) Mobile number which will receive the images • Once you have completed inputting the correct network date. Click the “SAVE” button and save as “Parameter.dat” file to the MICRO SD Card. Note: Only have 1 “Parameter.dat” saved onto the MICRO SD Card at any one time or the camera won’t work.
Page 20 MOTION SENSOR CAMERA INSTRUCTION MANUAL Text messaging / MMS – Three network Set-up Load up the software, and select the “MMS” tab. Once on the MMS page, switch the “Mode” to manual instead of “Auto and then input the data in each section as per the...
Page 21 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 10) Mobile number which will receive the images • Once you have completed inputting the correct network date. Click the “SAVE” button and save as “Parameter.dat” file to the MICRO SD Card. Note: Only have 1 “Parameter.dat” saved onto the MICRO SD Card at any one time or the camera won’t work.
Page 22: Network Settings For Email/Smtp
MOTION SENSOR CAMERA INSTRUCTION MANUAL 9. Network settings for email/SMTP Load up the software, select the SMTP tab (circled in image 11) in the middle to set the specific network settings. (Image 11) Network settings for email/SMTP Each network is different and has very speicific settings you need to input to get the SIM Card working and sending data.
Page 23 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for Gmail with O2 Sim Load up the software, and select the “SMTP” tab. Once on the SMTP page, switch the “Mode” to manual instead of “Auto and then input the data in each section as per the...
Page 24 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for Hotmail with O2 Sim Load up the software, and select the “SMTP” tab. Once on the SMTP page, switch the “Mode” to manual instead of “Auto and then input the data in each section as per the...
Page 25 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for BT lnternet with O2 Sim Load up the software, and select the “SMTP” tab. Once on the SMTP page, switch the “Mode” to manual instead of “Auto and then input the data in each section as per the...
Page 26 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 12) (Image 13)
Page 27 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 14)
Page 28 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for Gmail with Vodafone Sim Load up the software, and select the “SMTP” tab, then input the data in each section as per the information below:: SMTP Settings: SMTP ON-OFF: ON SMTP MODE: Manual...
Page 29 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for Hotmail with Vodafone Sim Load up the software, and select the “SMTP” tab, then input the data in each section as per the information below: SMTP Settings: SMTP ON-OFF: ON SMTP MODE: Manual...
Page 30 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for BT Internet with Vodafone Sim Load up the software, and select the “SMTP” tab, then input the data in each section as per the information below: SMTP Settings: SMTP ON-OFF: ON...
Page 31 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 15) (Image 16)
Page 32 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 17)
Page 33 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for Gmail with Three Network Sim Load up the software, and select the “SMTP” tab, then input the data in each section as per the information below: SMTP Settings: SMTP ON-OFF: ON...
Page 34 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for Hotmail with Three Network Sim Load up the software, and select the “SMTP” tab, then input the data in each section as per the information below: SMTP Settings: SMTP ON-OFF: ON...
Page 35 MOTION SENSOR CAMERA INSTRUCTION MANUAL Email / SMTP for BT lnternet with Three Network Sim Load up the software, and select the “SMTP” tab, then input the data in each section as per the information below: SMTP Settings: SMTP ON-OFF: ON...
Page 36 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 18) (Image 19)
Page 37 MOTION SENSOR CAMERA INSTRUCTION MANUAL (Image 20)
Page 38: Text Command Codes
MOTION SENSOR CAMERA INSTRUCTION MANUAL 10. Text Command Codes Once the camera is set up for text/MMS or email/SMTP, In order to get pictures/ information sent to your phone or email, you’ll need to send SMS commands to the SIM Card phone number.
Page 39: Cautions
MOTION SENSOR CAMERA INSTRUCTION MANUAL 11. Cautions The working voltage of the camera is 6.0 V. • Please unlock and format the Micro SD Card before use. • Please unlock and add credit to the SIM Card before use. • Please do not insert or take out the Micro SD Card when the power switch is in the ON position.
Page 40 MOTION SENSOR CAMERA INSTRUCTION MANUAL 12. Support Still having issues with setting up your camera? Contact the Killgerm Technical team of 01924 268512 or technical@killgerm.com. Alternatively contact you Killgerm Area Sales Manager for onsite support. Copyright (c) 2019 Killgerm Chemicals UK All Rights Reserved.
