16-Port Dual Rail LCD KVM Switch
Model Number: KL1116
ATEN International Co., Ltd.
3F, No. 125, Sec. 2, Datung Rd., Sijhih City, Taipei, Taiwan 221
Phone: +886-2-8692-6789
Fax: +886-2-8692-6767
http://www.aten.com
1
CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KL1116 and is the answer not in the manual?

Questions and answers

Related Manuals for ATEN KL1116

Summary of Contents for ATEN KL1116

  • Page 1 16-Port Dual Rail LCD KVM Switch Model Number: KL1116 ATEN International Co., Ltd. 3F, No. 125, Sec. 2, Datung Rd., Sijhih City, Taipei, Taiwan 221 Phone: +886-2-8692-6789 Fax: +886-2-8692-6767 http://www.aten.com CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 2 Document Revision History: Revision Date Revision Details Version September 4, 2008 KL1116 Marketing Spec Book Write-Up November 5, 2008 KL1116 Marketing Spec Book Release CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 3: Table Of Contents

    : ............................... 28 ABEL 4.4. P : ............................... 29 ACKAGING 4.5. C :..............................30 ABLES 5. POWER SUPPLY: ............................31 5.1. P :............................31 OWER ORDS CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 4: Product Overview

    16 computers. As many as 31 additional KVM switches can be daisy chained to each other, so that up to 512 computers can all be controlled from a single KL1116 unit. To access the computers on your installation, simply use the conveniently-located pushbuttons, enter Hotkey combinations from the keyboard, or take advantage of the powerful, mouse-driven OSD (On Screen Display) menu system.

  • Page 5: Features And Benefits

    Safely and quickly install the unit by yourself. No more available having to hold the switch with one hand while trying to screw it on to the rack. CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 6: Product Specifications

    Scan Interval User Specified: 1-255 seconds I/P Rating 100-240 VAC, 50/60 Hz; 1A Power Consumption 120V / 24W; 230V / 24W Operating Temperature 0-40℃ Storage Temperature -20-60℃ CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 7 Humidity 0-80% RH, Non-condensing Housing Metal Weight 17.1 kg Size （L×W×H） 68.0 x 48.2 x 4.4 cm MTBF 62,523 hours CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 8: Certifications

    2.2. Certifications: [CE] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 9 [FCC] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 10 [CB] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 11: Product Reliability Test

    10 times per unit, from a height of 31 - 97cm, depending on package weight Master Carton Bump Test IEC 68-2-29 Eb Reference; 10 grams, 16ms Pass CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 12: Cables

    2L-5206P (6.0m, PS/2) 2L-5202UP (1.8m) 2L-5203UP (3.0m) Cables and Converters for USB interface support 2L-5206UP (6.0m) CV131A (Sun USB compatible) CV130A (Sun Legacy compatible) Firmware Upgrade Cables LIN5-04A2-J11G CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 13: Front And Rear View

    1. Upper Handle 2. LCD Display 3. LCD Controls 4. Port Switches and Port LEDs 5. Keyboard 6. Touchpad 7. Lower Handle 8. Power LED 9. Lock LEDs and Reset Switch 10. Release Catch 11. Firmware Upgrade Section 12. Rack Mounting Brackets CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 14 [Rear View] 1. Daisy Chain Port 2. KVM Ports 3. Power Socket 4. Power Switch 5. External Console Section CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 15: Connection Diagram

    2.6. Connection Diagram: Connection Method: Daisy Chain Compatible KVM Switches: KH0116 CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 16 [Single Stage Installation] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 17 [Daisy Chained Installation] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 18: Package Contents

    Quick Start Guide Registration Card Optional Equipment: Item Standard Rack Mount Kit - Long Easy Installation Rack Mount Kit – Short Easy Installation Rack Mount Kit - Long CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 19: Function Overview

    Port Selection, Auto Scan, Auto Scan Duration, Skip Mode, Beeper ON-OFF 3.2. Pushbutton Function Overview: Pushbutton Function Overview Pushbutton Function Port Selection, Auto Scan, KM Reset Pushbutton LED Function Display Online Status, Display Port Selection CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 20: Osd Function Overview

    Timeout/Edit Port Names/Reset to Factory Default Settings/Clear Port Names/Beeper ON-OFF/Set Quick View Ports/Set Accessible Ports/Reset Station IDs/Enable Firmware Upgrade Mode/Set PS-2 CLK Mode/Set Console Mode/Enable Skip Mode/Enable Broadcast Mode/Enable Auto Scan/Logout CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 21: Osd Factory Default Settings

    Scan/Skip Mode Screen Blanker 0 (OFF) Logout Timeout 0 (OFF) Beeper Y (On) Accessible Ports F (Full) For all Users on all Ports Hotkey Command Mode CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 22: Product Dimensions

    4. Product Dimensions: 4.1. KVM Switch: CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 23: Rack Mount Kit

    4.2. Rack Mount Kit: Standard Rack Mount Kit Easy Installation Rack Mount Kit Short (42-77 cm) Short (Optional, 54-70 cm) Long (Optional, 68-105 cm) Long (Optional, 68-105 cm) CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 24 [Standard Rack Mount Kit – Short] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 25 [Standard Rack Mount Kit – Long (Optional)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 26 [Easy Installation Rack Mount Kit – Short (Optional)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 27 [Easy Installation Rack Mount Kit – Long (Optional)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 28: Label

    4.3. Label: CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 29: Packaging

    4.4. Packaging: CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 30: Cables

    4.5. Cables: [PS/2 KVM Cable] [USB Converter Cable] [Daisy Chain Cable] [Firmware Upgrade Cable] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.

  • Page 31: Power Supply

    5. Power Supply: 5.1. Power Cords: [US (AC 125V)] [UK (AC 250V)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 32 [Germany (AC 250V)] [Korea (AC 250V)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 33 [Japan (AC 125V)] [Australia (AC 250V)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
  • Page 34 [China (AC 250V)] CONFIDENTIAL – Do not distribute without prior written permission from ATEN International Co., Ltd.
