  • Page 1 VDSL2 Home Gateway Innbox V50-U Quick Start...
  • Page 2 The document contains “8” pages. Document ident. no.: “KSS6922I0-EDE-020” Document Title: “Quick Start”  Iskratel 2012. All rights reserved. Technical specifications and features are binding insofar as they are specifically and expressly agreed upon in a written contract. Technical modifications possible.
  • Page 3 Quick Start Safety precautions When using this equipment, consider the following precautions and requirements: Fiber cable, when operating, transmits a beam of infrared laser light You shall not look at the optical cable if it is at one side connected to the optical transmitter while the other end is not connected.
  • Page 4 Quick Start...

  • Page 5: Table Of Contents

    Quick Start Contents Document B Quick Start Light indicators ....................... 1 Front panel....................... 2 Back panel ....................... 2 Powering on and connecting to the internet socket..........3 Powering on and connecting to optical network ..........4 Connecting the PC ....................5 Connecting the STB....................

  • Page 7: Light Indicators

    Light indicators Light indicators Figure 1-1: Light indicators on - The device is on, the IP connection is established, the device is synchronized. off - power is off. Broadband blinking slow - The IP connection failed. red - error off - No IP connection established. on - The IP session is established, no broadband traffic activity.

  • Page 8: Front Panel

    Enable or disable the WPS (Wi-Fi Protected Setup) function. Turn the device on or off. Back panel The following figure shows the back panel of your Innbox V50-U home gateway. Figure 3-1: Back panel Port for connecting the ethernet cable to your internet socket.

  • Page 9: Powering On And Connecting To The Internet Socket

    Powering on and connecting to the internet socket Powering on and connecting to the internet socket You need:  The home gateway unit  The AC power adapter  Ethernet RJ-45 UTP cable Figure 4-1: Powering on and connecting to the internet socket 1.

  • Page 10: Powering On And Connecting To Optical Network

    B. Quick Start Powering on and connecting to optical network You need:  The home gateway unit  The AC power adapter  A SFP module mounted in a SFP cage labeled FTTH (not supplied)  The optical cable (not supplied) Figure 5-1: Powering on and connecting to optical network 1.

  • Page 11: Connecting The Pc

    Connecting the PC When you turn the home gateway on, observe the light indicators. It takes about 30 seconds for the home gateway to become active - the Power and Broadband lights are on uninterruptedly. Connecting the PC You need: ...

  • Page 12: Connecting The Stb

    B. Quick Start Connecting the STB You need:  The home gateway unit  Ethernet RJ-45 UTP cable  STB unit Figure 7-1: Connecting the STB Note: Your STB device may differ from the sample device in this picture. The picture shows only how to connect a STB device to your home gateway.

  • Page 13: Starting The Internet Session

    Starting the internet session Starting the internet session Once you have powered on your home gateway, connected it to the internet socket and connected the PC to the home gateway, you are ready to use the internet. The internet connection is established automatically.

  • Page 14: Accessing The Web Management Interface

    B. Quick Start Accessing the web management interface To access the web management interface, you need:  IP address of the home gateway - default address is 192.168.1.1  user authentication information - the default username is user and password user. 1.
