EDTM ETEKT+ AE1601 Manual

ETEKT+ IMPROPER OPERATING CONDITIONS

The ETEKT+ is the only thing that should be in contact with the glass while
the reading is being taken. The operator may have their hand on the
meter itself, but should not allow any part of their hand to overlap the meter
and come into contact with the glass during testing.
The ETEKT+ must be used with the surface
opposite the POWER button pushed flat
against the window. Using the small end
surface of the unit or tilting the unit away
from the window surface will give
improper results.
Placing your hand or an object on the
opposite side of the window may cause
improper results. Remove hand or object.
IMPORTANT:
Do not operate the ETEKT+ within two (2) inches
of a window frame or any other metallic window
component. Extraneous conductive materials
may impact the accuracy of your test results

AE1601 WARRANTY

The manufacturer warrants all models of the AE1601 to be free from defects in material and
workmanship under normal use and service as specified within the operator's manual.
manufacturer shall repair or replace the unit within twelve (12) months from the original date of
shipment after the unit is returned to the manufacturers factory, prepaid by the user, and the unit is
disclosed to the manufacturers satisfaction, to be thus defective. This warranty shall not apply to any
unit that has been repaired or altered other than by the manufacturer. The aforementioned provisions
do not extend the original warranty period of the unit which has been repaired or replaced by the
manufacturer. Batteries are not covered by warranty.
EDTM, Inc. assumes no liability for the consequential damages of any kind through the use or misuse of
the AE1601 product by the purchaser or others. No other obligations or liabilities are expressed or
implied. All damage or liability claims will be limited to an amount equal to the sale price of the
AE1601, as established by EDTM, Inc.
If the window area under test is excessively
dirty or contaminated, the ETEKT+ may
give improper results. The window area
under test must be RELATIVELY CLEAN.
Clean the test area or move the ETEKT+ to
a clean location on the window.
2"
2"
manual_edtm AE1601
DUAL PANE LOW-E COATING DETECTOR

GENERAL DESCRIPTION:

The "ETEKT+" is a portable instrument using a patented method to detect the
presence and location of Low-E coatings or any other conductive coating
on or within a window assembly. The ETEKT+ is designed to test single or
double pane windows from a single side. The instrument is optimized for
windows containing 3/32" and 1/8" glass with air spaces up through ½",
HOWEVER the AE1601 can test many other window sizes as explained in this
operating manual.
This instrument detects the presence of all electrically conductive coatings
in/on a window, including
reasonably clean before testing. The "FAR" and "CLEAR" indicators are
dependent on the window being within the thickness specifications listed
above. If in doubt about the thickness of the window being tested, always
test both sides of the window and look for the side that yields the "NEAR"
indication. The "NEAR" indication works for any glass thickness.
The
PHONE: (419) 861-1030 FAX: (419) 861-1031
www.EDTM.com
KEEP THE COMPETITIVE EDGE WITH PRODUCTS FROM EDTM, INC.
glass & air space laser meters, tempered glass detectors, SHGC, solar, visible, & uv meters
low-e type detectors, 4 point sheet resistance meters, tin side detectors,
self-clean coating detectors, sales kits, temperature guns & accessories
ETEKT+
MODEL# AE1601
Low-E coatings. Make sure the window is
745 Capital Commons Drive
Toledo, Ohio 43615 USA
Email: sales@edtm.com
