- Page 1 PULSE AR III Pulse Induction-based Metal Detector Instruction Manual KTS-Electronic GmbH & Co. KG Germany...
-
Page 2: Table Of Contents
Indication of metal ..................9 Usage of appropriate search coils ..............9 Rechargeable battery and charger ............. 11 Error signals ....................12 Care ....................... 13 Legal notice ....................13 Warranty ....................... 13 Contact ......................14 KTS-Electronic GmbH & Co. KG – PULSE AR III... -
Page 3: Introduction
To avoid possible operating errors please read this instruction manual with due care. We wish you lots of success with your new PULSE AR III and will be at your disposal, if any questions should arise. Your KTS Electronic Team 2. -
Page 4: Electronic Unit
Automatic zero balance. By pressing the RESET-button the device will be adjusted unto the respective ground. FREQ.: Frequency setting controller – the smaller the item you are searching for, the smoother the adjustment must be. VOLUME: Volume control. KTS-Electronic GmbH & Co. KG – PULSE AR III... - Page 5 2. Socket for charger 3. Headphone socket: Any commercial headphones with 6.3mm jack can be plugged. If you use the headphones, the speaker is turned off. Matching, light- weight headphones are provided. KTS-Electronic GmbH & Co. KG – PULSE AR III...
-
Page 6: Search Process
During zero balance look to it that there are no metallic objects near the search coil. This could cause a wrong adjustment of the metal detector and produce unwanted indicator effects (as the case may be repeat the RESET-procedure on another, metal-free spot). KTS-Electronic GmbH & Co. KG – PULSE AR III... - Page 7 The indicated values are guide values, which can be complemented with your own search routine Also consider explanations to error signals on page 12. KTS-Electronic GmbH & Co. KG – PULSE AR III...
-
Page 8: Installation
Dictate your own speed during the search. To search a large area without a great expenditure of time we recommend a speedy pace (no jogging). KTS-Electronic GmbH & Co. KG – PULSE AR III... -
Page 9: Adjustment
8. Adjustment The metal detector PULSE AR III can be adjusted within a short time. 1. With the menu knob you activate the metal detector. Choose the desired sound volume. 2. Briefly press the RESET-button in order to obtain a zero balance which is necessary for a failure-free search. - Page 10 During the search you should hold the search frame between 20 to 50cm over the ground. The higher the distance to the soil the less small and medium-sized metal objects can be displayed. KTS-Electronic GmbH & Co. KG – PULSE AR III...
-
Page 11: Rechargeable Battery And Charger
The charged battery allows a operating time of approx. 4-8 hours. In addition, we deliver an inverter module which enables the charging in the car. KTS-Electronic GmbH & Co. KG – PULSE AR III... -
Page 12: Error Signals
12. Error signals In line with the development of your PULSE AR III great emphasis was placed on stability and the avoidance of incidences. Despite the multiplicity of filters and modulators it is – to our regret - possible that certain soil conditions cause disturbances, which can effect your measured values. -
Page 13: Care
13. Care Your PULSE AR III is easy to clean, yet there are some aspects, which you should consider, in order to receive the optimal readiness for operation. Protect the electronic housing with a plastic bag in case you should get caught in the rain, fog or sandstorm. -
Page 14: Contact
9:00 am to 4:00 pm Copyright by KTS-Electronic GmbH & Co. KG, Moerfelden-Walldorf/Germany, 2015. A duplication or usage of visual and textual content of this publication is not allowed without explicit consent. KTS-Electronic GmbH & Co. KG – PULSE AR III...
