INTRODUCTION Thank you for purchasing the Kidizoom Pixi camera. This compact ® and lightweight camera with a built-in rechargeable battery is designed for taking great photos, selfies, videos, playing games and listening to music. With dual camera lenses and a wrist strap, you'll be ready to take great photos anytime, anywhere! Use 50+ filters to stylize your pictures with silly face filters, hairstyles, accessories and more.
Page 3
When the switch is set to the Off position , the battery will be disconnected, the camera will not function and the battery can not be charged. When the switch is set to the On position , the battery will be connected, the camera will function, and the battery can be charged.
Press these buttons to make a Up / Down / Left / selection or do the specific function Right Buttons according to the icons shown on screen. Insert a microSD card here for Memory Card Slot memory expansion. Connect to a computer with the Micro-USB Port included micro-USB cable to transfer files and to charge the camera.
Unlock the packaging locks: Turn the packaging lock counterclockwise several times. Pull out and discard the packaging lock. PRODUCT SPECIFICATION Display 1.8'' color LCD 1600 x 1200 (2.0 MP) (default resolution) Photo Resolution 640 x 480 (0.3 MP) 320 x 240 (default resolution) Video Resolution 160 x 120 Focus Range...
Important Note: • Keep the rubber cover of the Micro-USB Port and Memory Card slot tightly closed when they are not in use. STORAGE CAPACITY FOR REFERENCE Photos Videos 160 x 120 320 x 240 0.3 MP 2.0 MP (120p) (240p) (minutes) (minutes)
• Once the connection is successful, you will see the battery charging symbol appear on the camera's screen. • When the battery is fully charged, a message will appear on the camera's screen. The screen will then automatically turn Off. You may now disconnect the camera from your computer.
• Do not expose to high temperatures or place near a heat source. Do not leave in direct sunlight for any length of time. • Do not dispose of in a fire. • Do not handle damaged or leaking batteries. •...
WRIST STRAP ATTACHMENT Step 1: Locate the thread loop on the end of the wrist strap. Insert it into the groove behind the strap hook and then push it through. Step 2: Feed the end of the strap up through the loop and pull it all the way through.
Page 10
Next, set the date and time. Press the Up and Down buttons to select the correct month, day, year, hour and minute. Press the Left and Right buttons jump to the previous or next item. Finally, press the OK button to confirm the setting. If you wish to change the language, date and time later, you can do so from the Settings menu.
View Photos and Videos Press the the Left or Right button to view the previous or next file. To delete the current file, press the Delete button to display the Delete menu and select the check mark to confirm. To delete all files, press the Down button in the Delete menu and select the check mark to continue and follow the prompts to confirm.
• Insert the larger end of the micro-USB cable into a USB port on your computer. A USB port is usually marked with this symbol: • You will see a removable drive called VTech 5203 on your computer. Please use this drive to transfer files to and from the camera. There is another removable drive called VT SYSTEM, which is for the storage of system data only.
NOTE: The Kidizoom Pixi camera only works with four or fewer ® levels of subfolders within the Music folder. System Requirements: Microsoft Windows 7, Windows 8 or Windows 10 Operating System ® ® ® ® Mac OS X 10.9, 10.10, 10.11, macOS 10.12, 10.13 or 10.14 USB port required Microsoft and Windows logos are trademarks of Microsoft Corporation...
Video Select the Video icon in the Home menu to enter this mode. • Press the OK button to start or stop recording. After you have made a recording, a Play icon will appear. Press the OK button to watch the video you just captured.
Page 15
Hint: Try aligning your eyes to the eye position of the face outline first. Then, adjust your position until the rest of your face fits within the face area. Try to keep as much of your face inside the face area as possible for the best results.
Press the Up and Down Size buttons to enlarge or shrink the Glasses size of the glasses. Use the Up, Down, Left and Position Right buttons to adjust the position of the glasses. 2. Face Filter Studio In Face Filter Studio, you can take photos and try out makeup and fun effects.
Page 17
Advanced Effect Type Operation Setting Foundation Choose from one of two different types of foundation to smooth your skin, or turn this filter off. Shape Press the Left and Right buttons to change the shape. Press the Left and Right Blush Adjust buttons to decrease or increase...
Page 18
Press the Left and Right Adjust buttons to decrease or increase the distance between the left and right eye effects. Mascara Press the Up, Down, Left and Position Right buttons to adjust the position of the effect. Press the Left and Right Color buttons to cycle through the mascara color options.
Page 19
Games Master Chef Help the Master Chef create the perfect dish. Press the correct direction button when it is in the box to guide the chef's actions. Mystic Potion Help gather ingredients to concoct the perfect potion. Move the camera until the element you need is in the target and press the OK button to collect it.
Page 20
Memory • Check memory status. See how much memory is used and how much is available on either the Pixi's internal memory or, if you are using one, the microSD memory card. • Reformat the memory. This will erase all photos, videos, MP3 files and game photos in the memory drive in use.
Tip: This feature is designed for parents of children who cannot yet read, since access to the settings is granted by following simple, on- screen instructions. Note: The time limit will reset if the date or time settings are changed. Indoor Light Frequency Set the AC power frequency according to the region you’re in when traveling.
TROUBLESHOOTING Check this section if you experience difficulty operating the Kidizoom ® Pixi camera. Issue Solution 1. Turn the Master Power switch OFF for 30 seconds. Camera 2. Turn the Master Power switch ON again and isn't then press the On/Off button to turn on the working camera.
Page 23
• Check if the memory card is correctly inserted. • Check to see if the memory card is the supported type. The camera only supports microSD or microSDHC card. Memory • Check to see if the file system of your memory card card can’t is FAT or FAT32, Kidizoom Pixi...
® Electronics North America, L.L.C. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this product. VTech ® Electronics North America, L.L.C. and its suppliers assume no responsibility for any damage or loss caused by deletion of data as a result of malfunction, dead battery, or repairs.
® Model: 5203 Product name: Kidizoom Pixi ® Responsible Party: VTech Electronics North America, LLC Address: 1156 W. Shure Drive, Suite 200, Arlington Heights, IL 60004 Website: vtechkids.com THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO...
