DecoFlex Wirefree RTS Wall Switch
Motorization
Radio Technology Somfy
®
eliminating the need to point or aim the transmitter at the window covering. With a simple press of a button, users have the
ability to control all motorized window coverings individually and/or as a group with one control.
WIREFREE WALL SWITCH
• Recommended control for hospitality settings
• Available in 1 Channel, 2 Channel, and 5 Channel
• Channel buttons can be custom engraved for
easy organization
1 Channel
RTS Wall Switch
RTS Wall Switch
Installation FEATURES
• Mounting bracket attaches to drywall
• No need for an electrical box (If used, it must be
plastic)
• Switch can be installed anywhere up to 65 ft
from the motor
NOTE:
For guest room installation, it is recommended
to mount the wall switch near the shade it will
control to insure guests are aware of motorization
Las Vegas • Chicago
800.229.5300
HDhospitality.com
(RTS) wall switches allow for up to a 65 ft. control range. The radio waves travel through walls
2 Channel
Available fi nishes:
White (shown)
Default color
unless specifi ed
Ivory
Black
5 Channel RTS Wall Switch
RTS Wall Switch Installation Items
Mounting
DecoFlex
Bracket
Switch
LED indicator for each channel
Custom engraving on channel
buttons
"STOP" button stops the window
covering when it is in motion.
When the window covering is
stationary, the "STOP" button
brings it to the programmed
favorite position.
UP AND DOWN
Command Buttons
Programming Button (recessed)
Wall plate
Screws
100319
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hunter Douglas DecoFlex Wirefree RTS
Summary of Contents for Hunter Douglas DecoFlex Wirefree RTS
- Page 1 100319 DecoFlex Wirefree RTS Wall Switch Motorization Radio Technology Somfy (RTS) wall switches allow for up to a 65 ft. control range. The radio waves travel through walls ® eliminating the need to point or aim the transmitter at the window covering. With a simple press of a button, users have the ability to control all motorized window coverings individually and/or as a group with one control.
-
Page 2: Battery Replacement
DecoFlex Wirefree ™ RTS Assembly/Installation/ Operating Instructions Wall Switch Instructions (Ref: 1810813 +others) ASSEMBLY ASSEMBLE MULTIPLE BUTTON SWITCHES Begin with a standard (assembled) 1 or 5 control button DecoFlex switch. Using a small flat blade screw driver, carefully separate the SWITCH BASE ASSEMBLY from the FACEPLATE (as shown in figure 1). - Page 3 DecoFlex Wirefree™ Wall Switch INSTALLATION Included is a special SOMFY low voltage device mounting bracket which attaches to drywall and eliminates the need for an electrical box. The bracket can be used in two mounting type configurations: Individual or “stand-alone” (1 switch) mounting configurations (shown below), Or adjacent (pre-existing) Decora-style light switch (specific instructions available).
- Page 4 DecoFlex WireFree™ RTS Switch To ensure accuracy, please be sure this document has been printed as “Actual Size.” Please verify using measurements provided. Align the thin side of the template on existing electrical box (opposite stud side). Align the mounting screw height with existing switch. Trace the inside shape of the bracket on the wall.
