MANUAL
Powerview® Quick Start Guide Gen 2
This guide will help getting you started with your Powerview® purchase.
Step 1. Install your shades
Make sure you have properly installed your shades and that they are connected to a power source (battery pack or power
supply).
Battery pack
Power supply
Step 2. Your Powerview® components
Packed with your purchased product you will find one or more remotes, repeaters and a Hub (which is optional and only
required when you want to control your shades using a tablet or smartphone). Remotes come in different colours. Please
locate them all before you start.
Pebble remote
Surface remote
Repeater
Hub
Step 3. Pairing remotes
In case no remotes are used or you want to start the setup process using the PowerView® Hub & App, please proceed to
step
5.
Page 1 of 23
version: 1.1
Advertisement
Table of Contents
Related Manuals for Hunter Douglas Powerview Gen 2
Summary of Contents for Hunter Douglas Powerview Gen 2
- Page 1 MANUAL Powerview® Quick Start Guide Gen 2 This guide will help getting you started with your Powerview® purchase. Step 1. Install your shades Make sure you have properly installed your shades and that they are connected to a power source (battery pack or power supply).
- Page 2 MANUAL Note If you only have one remote, please proceed to step By pairing PowerView® remotes you make all your remotes part of the same PowerView® Network. This is important for seamless installation of the PowerView® system. Take all remotes. Name one remote "SOURCE"...
- Page 3 MANUAL On the , Press and release the source remote stop button. As a confirmation, the group buttons on the target remote will flash 2x. If the buttons on the are still flashing source remote Press for 6 seconds. stop Keep pressing until the remote lights stop blinking.
- Page 4 MANUAL Roller blind Roller blind 230V Twist® Roller Blind EOS Bottom-Up blind CHR Bottom-Up blind CHR Top-Down Bottom-Up blind Vertical Venetian blind Venetian blind Roman shade Press and hold the button for 6 seconds. stop Keep pressing until the remote lights start blinking. Page 4 of 23 version: 1.1...
- Page 5 MANUAL Press the button. group1 This will activate group 1 on the remote. Press and hold the manual control button Press the open button. The blind will jog 1x. Release the manual control button Page 5 of 23 version: 1.1...
- Page 6 MANUAL Press and hold the button for 6 seconds. stop Keep pressing until the remote lights stop blinking. The remote will exit programming mode automatically after 20 seconds. Step 5. Connect and setup the Hub Download the Powerview® App from the on your mobile Apple App store Google Play store...
- Page 7 MANUAL Connect the power cable of the Hub to a power outlet Page 7 of 23 version: 1.1...
- Page 8 MANUAL Watch out for the of the LED. colour The Hub is ready to be discovered within the App when the LED is Blinking Amber Open the app and select Connect to Hub The app will start looking for an available Hub. Make sure your mobile device and the PowerView®...
- Page 9 MANUAL Select New Setup Note 1 If you already have a Gen 1 Hub installed in your PowerView® network, select Migrate from an Existing and follow the in App instructions to Transfer Gen 1 Hub data to the new Gen 2 Hub. Note 2 If you already have a Gen 2 Hub installed in your PowerView®...
- Page 10 MANUAL Select Pair with PowerView® Remotes 5.10 Choose remote. In this quick start guide we select one remote, regardless of the amount of remotes you have. 5.11 Follow the onscreen instructions to add the Hub to your Powerview® network. The Hub is added when the LED is Solid Blue Page 10 of 23 version: 1.1...
- Page 11 MANUAL 5.12 You can now start discovering blinds. Hub led behaviour Hub status LED behaviour Power On Solid Aqua Bootup Blinking Aqua Downloading & applying firmware update Solid Amber Ready to connect to a wifi network Solid Magenta Ready to join a PowerView network Blinking Amber Connect to a PowerView network.
- Page 12 MANUAL Pro-Tip Check the range of the Hub Your Hub should be able to reach each shade in the house. Use your remote from the same location as your Hub to operate your shades. If some shades do not respond, add or relocate a repeater and check again. To Optimize the range of your Gen2 Hub you can place it in a central location of your home where it can reach the majority of your blinds.
- Page 13 MANUAL Press and hold the button for 6 seconds. stop Keep pressing until the remote lights start blinking. Keep the Remote within 50cm from the Repeater and press the stop button. The Repeater light will stop blinking and turns off. The Repeater has been added to your Powerview®...
- Page 14 MANUAL Select the blind's button. group For example, button. group 1 Select the button instead of to move all group 1 shades from all 6 groups on the remote. group button will light up. Press the Press the Press the ...
- Page 15 MANUAL Press the button. Press the button. Press the button. favourite arrow up arrow down Blinds assigned to group 1 will go Blinds assigned to group 1 will tilt Blinds assigned to group 1 will tilt to their favourite position. open or slowly move open.
- Page 16 MANUAL 7.2.2 Move the blind to the desired favourite position. Use the open , stop and close buttons to move the blind. 7.2.3 Press and hold the button for 6 seconds. stop Keep pressing until the remote lights start blinking. DO NOT select a group on the remote! ...
- Page 17 MANUAL 7.2.4 Press and hold the manual control button 7.2.5 Press the button. favourite The blind will jog 1x to acknowledge the favourite position is set. And will indicate green LED 7.2.6 Release the manual control button Page 17 of 23 version: 1.1...
- Page 18 MANUAL 7.2.7 The favourite position is set! If your remote is still blinking, Press the button stop for 6 seconds. Keep pressing until the remote lights stop blinking. 7.3. Remove a shade from a group Removing a shade from a group on a remote will unlink the shade from the remote. It will not remove the shade from the Powerview®...
- Page 19 MANUAL 7.3.2 Select the blind's button. group For example, button. group 1 group button will light up. IMPORTANT Watch out to perform steps 7.3.3 and 7.3.4 within 3 seconds! 7.3.3 Press and hold the manual control button 7.3.4 Press the ...
- Page 20 MANUAL 7.3.5 Release the manual control button 7.3.6 The blind is removed from the remote! If your remote is still blinking, Press the stop button for 6 seconds. Keep pressing until the remote lights stop blinking. 7.5. Install a Scene Controller A Scene Controller works in combination with the Powerview®...
- Page 21 MANUAL 7.5.2 Select Accessories Scene Controllers Follow the App instructions. 7.6. Erase Hub data This procedure will remove the Hub from the PowerView® network. All data inside (e.g. blinds, scenes, settings etc.) will be permanently deleted. Warning Erasing the Hub data will permanently delete all data stored inside the Hub and will put the Hub in its factory default setting.
- Page 22 MANUAL 7.6.2 Press and hold the for 6 seconds. Reset button Keep pressing until the LED turns off. 7.6.3 The Hub will . All data on the hub has been reboot erased Wait for the hub to start Blinking Amber The Hub is ready to be added to a PowerView®...
-
Page 23: Important Notice
Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from Hunter Douglas under the patents or other intellectual property of Hunter Douglas.
