- Page 1 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Contents/Inhalt/Inhoud/Contenu/Contenuto Page/Seite/Bladzijde/Page/Pagina Important note Wichtiger Hinweis Belangrijke opmerking Note importante Nota Importante Assembly Montage Montage Montage Montaggio Wiring Verdrahtung Bedrading Câblage Cablaggio Programming Programmierung Programmeren Programmation Programmazione DOB3590203-00 04-2013...
- Page 2 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Important/Wichtig/Belangrijk/Important/Importante Switch off the main power to the boiler, close the gas supply and close the hydraulic shut off valves. Schalten Sie den Hauptschalter zum dem Kessel aus, schließen Sie die Gas- versorgung und schließen Sie die Wasserhähne.
- Page 3 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Assembly/Montage/Montage/Montage/Montaggio R601-R607 Remove frame plates Entferne Rahmenplatten Verwijder frame platen Retirer des plaques de châssis Togliere le piastre del telaio Remove manifold, keep the bolts Entferne Wasserzirkulationseinheit, Schrauben aufbewahren Verwijder water omkeerstuk, bewaar de bouten Retirer l'unité...
- Page 4 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Assembly/Montage/Montage/Montage/Montaggio R601-R603 First assemble bypass group, then tighten bolts. Zuerst Bypass Baugruppe montieren, dann die Schrauben anziehen Eerst bypass groep assembleren, daarna bouten aandraaien Avant assemblée groupe bypass, puis serrez les boulons...
- Page 5 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Assembly/Montage/Montage/Montage/Montaggio R604-R607 Assemble frame plates Montiere Rahmenplatten Monteer frame platen Monter des plaques de châssis Montare le piastre del telaio DOB3590203-00 04-2013...
- Page 6 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Wiring/Verdrahtung/Bedrading/Câblage/Cablaggio R601-R607 Boiler Kessel Pump Ketel Chaudière Pumpe caldaia Pomp Pompe Pompa Pump Pumpe Pomp Pompe Pompa Remove jumper between terminals 8 and 9 Verbindung zwischen Klemmen 8 und 9 entfernen...
- Page 7 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Wiring/Verdrahtung/Bedrading/Câblage/Cablaggio R601-R607 Boiler Kessel Ketel Chaudière caldaia Important! Switch wires QX1 with wires AUX2. Wichtig! Drähten QX1 umwechseln mit Drähten AUX2. Belangrijk! Draden QX1 omwisselen met draden AUX2. Important! Remplacer fils QX1 par la prise fils AUX2.
- Page 8 Bypass R600 Bypass R600 Bypass R600 By-pass R600 Bypass R600 Programming/Programmierung/Programmeren/Programmation/Programmazione R601-R607 turn drehen draaien tourner ruotare push drucken drukken appuyer premere Shows only at start-up (2 s) >1 s Boiler type setting R601 R602 R603 R604 R605 R606 R607...
