Summary of Contents for SKF TKRS 41
- Page 1 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz SKF TKRS 41 Instructions for use...
- Page 2 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz...
-
Page 3: Table Of Contents
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz Table of contents Safety recommendations ......................... 2 EC Declaration of conformity ......................3 1. Complete overview of connections, controls and settings ............4 2. Technical data ........................... 5 3. About these operating instructions .................... 6 3.1 Conventional representation in this document ...................6 3.1.1 Presentation of work instructions......................6 4. -
Page 4: Safety Recommendations
Never direct the LED beam at people or animals and do not stare directly at the beam. • Laser class 2 The SKF Stroboscope TKRS 41 is itted with a class 2 laser. This is located at the front of the device. The laser beam can damage eyes. -
Page 5: Ec Declaration Of Conformity
(495) 727-22-72 promshop- biz@ya.ru www.promshop.biz EC Declaration of conformity We, SKF Maintenance Products, Kelvinbaan 16, 3439 MT Nieuwegein, The Netherlands herewith declare that the products described in these instructions for use, are in accordance with the conditions of the following directive:... -
Page 6: Complete Overview Of Connections, Controls And Settings
LASER PRESS: FLASH ON/OFF CHARGE Reset 5 sec. Fig.1 – Stroboscope SKF TKRS 41 1. Brightness in μs and/or degrees (BRIGHT) 2. Delay in ms and/or degrees (DELAY) 3. Phase shift (PHASE) 4. Unit of frequency in rpm, Hz and/or FPM 5. -
Page 7: Technical Data
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 2. Technical data General parameters TKRS 41 Number of LEDs Frequency range 30 to 300 000 lashes per minute (f/min) Display Multi-line backlight LCD Accuracy ±0.02 % (±1 digit / ±0.025 μs) Resolution ±... -
Page 8: About These Operating Instructions
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 3. About these operating instructions 3.1 Conventional representation in this document These operating instructions are an integral part of the device. They must be stored in an easily accessible location and passed on to subsequent 3.1.1 Presentation of work instructions users. -
Page 9: Scope Of Delivery
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 4. Scope of delivery Check the scope of delivery. • Stroboscope: – portable version TKRS 41 (= 118 LEDs, with auto-sync laser function) • Operating instructions • Charger with connector set • Trigger plug •... -
Page 10: Connect Trigger
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 5.3 Connect trigger N O T E : The device has the option of being externally The device must be manually switched triggered. between external and internal trigger signals – “Standard mode / How to select †... -
Page 11: Operation
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 6. Operation N O T E : Please note that this device is available in standard and pro modes ( – “Standard mode” † section 6.2.2 – “Pro mode”). † section 6.2.3 6.1 Controls (†... -
Page 12: Standard Mode († Ig. 2)
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 6.2.2 Standard mode († ig. 2) N O T E : Not all of the settings shown in ig. 2 are available in standard mode. Position of the Display Adjustable Description selector switch (E) parameters –... - Page 13 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz Position of the Display Adjustable Description selector switch (E) parameters MENU PHASE deg.: Delay setting between the trigger 0 … 359 signal and lash (in degrees, relative to the frequency) Position ixed; actual delay depending on current frequency.
- Page 14 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz Position of the Display Adjustable Description selector switch (E) parameters MENU INT / EXT Internal / external trigger How to select an internal / external trigger: Turn the selector switch (E) to the “MENU” position. Select the INT / EXT parameter using the rotary/push knob (D).
-
Page 15: Pro Mode († Ig. 2)
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 6.2.3 Pro mode N O T E : († ig. 2) If pro mode is activated, a “P” will be shown in the N O T E : bottom right area of the display. Follow the steps below to access the pro mode: ►... - Page 16 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz Position of the Display Adjustable Description selector switch (E) parameters MENU rpm / Hz / FPM Unit of frequency selection: – rpm: unit for measuring rotational speed – Hz: lash frequency per second –...
- Page 17 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz Position of the Display Adjustable Description selector switch (E) parameters MENU SLOW: – The lash frequency exceeds 0 … 600 the trigger frequency by the value selected. – This function is only possible when the “external trigger”...
-
Page 18: Laser Modes
• Laser class 2 The stroboscope TKRS 41 is itted with a class 2 To enable the integrated “Auto Save” feature, direct laser. The laser beam can damage eyes. For this the stroboscope at the rotating object for at least reason, do not stare directly at the laser beam 2 seconds. -
Page 19: Operating Mode
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 6.2.5 Operating mode The following operating modes may be displayed: Position of the Display Description selector switch (E) BATTERY STATUS Fully charged BATTERY STATUS Half charged BATTERY STATUS Low (symbol will lash) LASER / EXT / The trigger frequency is below the SLOW... -
Page 20: Determining The Actual Rotational Speed Of An Object
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz 7. Determining the actual rotational Useful information: speed of an object • It’s helpful to have a rough idea of the object’s The stroboscope can be used as a digital revolution rotational speed beforehand. indicator to determine an object’s actual rotational •... - Page 21 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz Which is correct? To determine the fan’s actual rotational speed, one of the ventilator vanes is attached with a marking and the test is repeated. Image No. Flashing rate 3,300 2,200 1,650 1,320 Image No.
-
Page 22: Spare Parts
8. Spare parts Designation Description TKRT–RTAPE Rel ective tape for tachometers (TKRT) and stroboscopes (TKRS) TKRS 41–CHARG Charger and power adapter for TKRS 41 (110-230V, 50/60Hz, EU/US/UK/AUS plugs) TKRS 41–PROT Rubber side protectors for TKRS 41, 2 pcs. 20 EN... - Page 23 ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru www.promshop.biz...
- Page 24 | mapro.skf.com | skf.com/mount ® SKF is a registered trademark of the SKF Group. © SKF Group 2018 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy of the information contained in this publication but no liability can be accepted for any loss or damage whether direct, indirect or consequential arising out of the use of the information contained herein.
