[9] Technical Data

Power Storage
Order Number
DC-INPUT
Max. recommended DC power
Rated DC power
MPPT
Input per MPPT
Maximum DC current per MPPT
Rated DC voltage
DC start up voltage / power
DC voltage range
MPP voltage range
Maximum voltage DC
Connector type
BATTERY-INPUT
DC voltage range
Maximum charge / discharge current
Maximum charge / discharge power
Connector type
AC-OUTPUT
Rated AC output power
Maximum active power
Maximum apparent power
Nominal AC current per phase
Maximum AC current per phase
Rated frequency
Frequency range
Max. switch-on current
Max. fault current (RMS)
Rated AC voltage
AC voltage range
Total harmonic distortion (THD)
Reactive power factor (cos phi)
Anti-islanding operation
Earth fault protection
DC-current injection
Required phases, grid connections
Number of feed-in phases
Grid voltage monitoring
Type of AC connection
PERFORMANCE
Stand-by consumption
Maximum efficiency (PV – Grid)
European efficiency (PV – Grid)
Maximum efficiency (PV – Battery – Grid)
Topology
4.0
IHP040N1AE0
5000 W
4200 W
2 (paralleling possible)
1
12 A ( 24 A in parallel mode)
700 V
150 V / 25 W
140 V ... 1000 V
200 V ... 800 V
1000 V
Weidmüller PV-Stick (MC4 compatible)
150 V ... 600 V
20 A / 20 A
6000 W / 4000 W
Weidmüller PV-Stick (MC4 compatible)
4000 W
4000 W
6300 VA
5,8 A
9,1 A
50 Hz / 60 Hz
45 Hz ... 65 Hz
13 A, 0,1ms
285 mA
230V / 400 V (L1, L2, L3, N, PE)
180V ... 270V
< 2% at rated power
1 (adjustable range 0,8 cap....0,8 ind )
Yes
RCD
< 0,5% In
3 (L1, L2, L3, N, PE)
3
3-phase
Spring clamps
< 4.0 W
98,16%
97,6%
95,9%
Transformerless
15
5.0
IHP050N1AE0
6250 W
5250 W
220 V ... 800 V
6000 W / 5000 W
5000 W
5000 W
6300 VA
7,3 A
9.1 A
97,7%
6.0
IHP060N1AE0
7500 W
6300 W
265 V ... 800 V
6000 W / 6000 W
6000 W
6000 W
6300 VA
8,7 A
9.1 A
97,9%
