- Page 1 NO FROST REFRIGERATOR Freezer - Fridge User manual FRIGORIFERO NO-FROST Congelatore - Frigorifero Manuale per l’utente NO-FROST-KÜHLSCHRANK Gefrierschrank - Kühlschrank Bedienungsanleitung FD54PXNE4...
-
Page 2: Table Of Contents
Index BEFORE USING YOUR FRIDGE........4 General warnings..............4 Old and out-of-order fridges............6 Safety warnings ................ 7 Installing and operating your fridge........... 8 Before Using your Fridge ............9 Information about NO FROST Technology ....... 9 PARTS AND PIECES OF YOUR FRIDGE ...... 10 USAGE INFORMATION .......... - Page 3 Freezer Compartment.............. 25 SHIPMENT AND REPOSITIONING ........ 30 Repositioning the Door ............30 BEFORE CALLING SERVICE ........31 TIPS FOR SAVING ENERGY .......... 35...
-
Page 4: Before Using Your Fridge
BEFORE USING YOUR FRIDGE General warnings WARNING: Keep vantilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by... - Page 5 BEFORE USING YOUR FRIDGE - staff kitchen areas in shops, offices and other working environments - farm houses and by clients in hotels, motels and other residential type environments - bed and breakfast type environments; - catering and similar non-retail applications •...
-
Page 6: Old And Out-Of-Order Fridges
BEFORE USING YOUR FRIDGE • If the supply cord is demaged, it must be replaced by the manufacturer, its service agent or similar qualified persons in order to avoid a hazard. • This appliance is not intended for use at altitudes exceeding 2000 m. -
Page 7: Safety Warnings
BEFORE USING YOUR FRIDGE Safety warnings • Do not use multiple receptacles or extension cord. • Do not plug in damaged, torn or old plugs. • Do not pull, bend or damage the cord. • This appliance is designed for use by adults, do not allow children to play with the appliance or let them to hang over the door. -
Page 8: Installing And Operating Your Fridge
BEFORE USING YOUR FRIDGE Installing and operating your fridge Before starting to use your fridge, you should pay attention to the following points: • Operating voltage for your fridge is 220-240 V at 50Hz. • Mains cord of your fridge has a grounded plug. This plug should be used with a grounded receptacle that has a 16 ampere fuse minimum. -
Page 9: Before Using Your Fridge
BEFORE USING YOUR FRIDGE Before Using your Fridge • When it is operated for the first time or after transportation, keep your fridge in the upright position for 3 hours and plug it on to allow efficient operation. Otherwise, you may damage the compressor. -
Page 10: Parts And Pieces Of Your Fridge
PARTS AND PIECES OF YOUR FRIDGE The purpose of this presentation is informing you about the parts of your appliance. The parts may vary depending on the model of the appliance. - Page 11 PARTS AND PIECES OF YOUR FRIDGE A) Freezer compartment B) Fridge compartment 1) Freezer compartment shelf 2) Icemaker 3) Freezer lamp and its cover 4) Quick freezing shelf 5) Freezer compartment door shelves 6) Chilled room shelves 7) Fridge compartment lamp and its cover 8) Fridge compartment shelf 9) Crisper cover 10) Crisper...
-
Page 12: Usage Information
USAGE INFORMATION Display and control panel... - Page 13 USAGE INFORMATION 1. It is super freeze indicator. 2. It is freezer set value screen. 3. It is super cooling indicator. 4. It is cooler set value screen. 5. It is alarm symbol. 6. It is economy mode symbol. 7. It is holiday mode symbol. 8.
-
Page 14: Operating Your Fridge
USAGE INFORMATION Operating your fridge Super freeze mode How would it be used? Press freezer set button until Super freeze symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set. During this mode: • Temperature of cooler and super cool mode may be adjusted. -
Page 15: Economy Mode
USAGE INFORMATION Economy mode How would it be used? • Push "mode button" until eco symbol appears. • If no button is pressed for 1 second. Mode will be set. Eco symbol will blink 3 times. When mode is set, buzzer will sound beep beep. -
Page 16: Drink Cool Mode
USAGE INFORMATION • Holiday mode is automatically cancelled and the selected mode is activated. • Economy mode can be selected after cancelling the holiday mode. Then the selected mode is activated. • To cancel, you will just need to press on mode button. Drink cool mode When would it be used? This mode is used to cool the drinks within adjustable time. How would it be used? • Press freezer button for 3 seconds. • Special animation will start on freezer set value screen and 05 will blink on cooler set value screen. -
Page 17: Function Of Child Lock
USAGE INFORMATION Function of Child lock When would it be used? To prevent children from playing with the buttons and changing the settings you have made, child lock is available in the appliance. Activating Child Lock Press on Freezer and Cooler buttons simultaneously for 5 seconds. -
Page 18: Cooler Temperature Settings
USAGE INFORMATION Cooler temperature settings • Initial temperature value for Cooler Setting Indicator is +4 °C. • Press cooler button once. • When you first push this button, the last value appears on the setting indicator of the cooler. • Whenever you press on this button, lower temperature will be set. -
Page 19: Warnings About Temperature Adjustments
USAGE INFORMATION Warnings about temperature adjustments • It is not recommended that you operate your fridge in environments colder than 10°C in terms of its efficiency. • Temperature adjustments should be made according to the frequency of door openings and the quantity of food kept inside the fridge. • Do not pass to another adjustment before completing an adjustment. • Your fridge should be operated up to 24 hours according to the ambient temperature without interruption after being plugged in to be completely cooled. Do not open doors of your fridge frequently and do not place much food inside it in this period. • A 5 minute delaying function is applied to prevent damage to the compressor of your fridge, when you take the plug off and then plug it on again to operate it or when an energy breakdown occurs. Your fridge will start to operate normally after 5 minutes. -
Page 20: Accessories
USAGE INFORMATION Accessories Icemaker • Fill the icebox part of the icemaker with water and place it back. • You can take your ice approximately 2 hours later. • Without displacing the icebox, turn the icebox arm to the right until all the ice cubes are discharged to the ice bucket. -
Page 21: Chilled Room Compartment
USAGE INFORMATION Chilled Room Compartment Clack Keeping food in the Chiller compartment instead of the freezer or refrigerator compartment allows food retain freshness and flavour longer, while preserving its fresh appearance. When chiller tray becomes dirty, remove it and wash it with water. (Water freezes at 0°C, but foods containing salt or sugar freeze at temperature lower than that) Normally people use the chiller compartment for raw fish, lightly pickled,... -
Page 22: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Make sure to unplug the fridge before starting to clean • Do not wash your fridge by pouring water. • You can wipe the inner and outer sides of your appliance with a soft cloth or a sponge using warm and soapy water. • Remove the parts individually and clean with soapy water. -
Page 23: Replacing The Bulb
CLEANING AND MAINTENANCE Replacing the bulb To replace the bulb in freezer and fridge compartments; 1. Unplug the unit from the power supply, 2. Remove the refrigerator light cover with a minus screw driver, and take out the cover.(A) 3. Change the present light bulb with a new one of not more than 15 W.(B) 4. -
Page 24: Placing The Foods
PLACING THE FOODS Where to place in the • For normal operating conditions, adjusting the temperature value of the cooler partition of the fridge to +4°/ +6°C will be enough. • Food should be placed to the fridge in closed containers or covered with appropriate material. -
Page 25: Freezer Compartment
PLACING THE FOODS Freezer Compartment • For normal operating conditions, adjusting the temperature value of the freezer partition of the fridge to -18 / -20 C will be enough. • The freezer is used for storing deep frozen or frozen foods for a long time or for producing ice. - Page 26 PLACING THE FOODS • The expiry date of a frozen food depends on the room temperature, thermostat setting, the frequency of opening the door of your fridge, the type of food, the time passing while carrying it from shop to the house.
- Page 27 PLACING THE FOODS Thawing Storage period at room Duration Fish and Meat Preparation temperature (months) -hours- Packed for freezing in Beef Steak 6-10 convenient portions Packed for freezing in Lamb Meat convenient portions Packed for freezing in Calf Roast 6-10 convenient portions Calf Cubes In small pieces...
- Page 28 PLACING THE FOODS Thawing Storage period at room Vegetables and Duration Preparation temperature Fruits (months) -hours- Remove the leaves, divide the core into parts and keep it It may be used Cauliflower 10 - 12 waiting in water containing a in frozen form little amount of lemon Green Beans,...
- Page 29 PLACING THE FOODS Storage Dairy Products and Preparation Duration Storage Conditions Pastries (months) Packaged In its own package 2 - 3 Homogenised Milk only (Homogenised) Milk They may be left in their original packages for Cheese (except short time storage. They In the form of slices 6 - 8 white cheese)
-
Page 30: Shipment And Repositioning
SHIPMENT AND REPOSITIONING • Original package and foam may be kept for re- transportation (optionally). • You should fasten your fridge with thick package, bands or strong cords and follow the instructions for transportation on the package for re-transportation. • Remove movable parts (shelves, accessories, vegetable bins etc.) or fix them into the fridge against shocks using bands during re-positioning and transportation. -
Page 31: Before Calling Service
BEFORE CALLING SERVICE Check Warnings; Your fridge warns you if the temperatures for cooler and freezer are in improper levels or when a problem occurs in the appliance. Warning codes are displayed in the Freezer and Cooler Indicators. ERROR TYPE ERROR TYPE WHAT TO DO There is/are some... - Page 32 BEFORE CALLING SERVICE SR – Set value 1. Check if the “Super The foods starts to blink on cooler cooling mode” is on Refrigerator freeze because of set value 2. Decrease comp. too Cold the too much cold screen the refrigerator temperature temperature values This is not a failure.
- Page 33 BEFORE CALLING SERVICE setting level is SC?) • Are there many food recently put inside the freezer compartment? If so, your fridge may over cool the food inside the refrigerator compartment as it will operate longer to cool these food. If your fridge is operating too loudly;...
- Page 34 BEFORE CALLING SERVICE the fridge when the doors are opened. Humidity build up will be faster when you open the doors more frequently, especially if the humidity of the room is high. • Building up of water drops on the rear wall after automatic defrosting is normal.
-
Page 35: Tips For Saving Energy
TIPS FOR SAVING ENERGY 1– Install the appliance in a coll, well vantilated room , but not in direct sunlight and not near heat source (radiator, cooker.. etc). Otherwise use an insulating plate. 2– Allow ward food and drinks to cool down outside the appliance. 3–...
