Refer to the next section for information regarding double-mount installation of display clocks.
Spectracom Corporation: 1565 Jefferson Road, Rochester, NY 14623
US +1.585.321.5800
FCC ID
NOTE: North American standard colors black,
green, and white for power, ground, and
neutral (respectively)
brown, green/yellow, and blue inter-
nationally.

Figure 2-14: Analog Display Clock Wiring, LEDs, and Switches

DIAGNOSTIC
Switch 1
Diagnostic LED
Switch 2
TRANSMIT/RECEIVE
correspond to
220V W
V
ARIATION
NetClock Wireless Clock System Instructions
1168-5001-0050 Rev. H, Copyright June, 2011
IRING
4 of 19
