Rooftop Water Heater Model SRT80 120NE
COMMERCIAL GAS WATER HEATER
• INSTALLATION • OPERATION • SERVICE • MAINTENANCE • LIMITED WARRANTY
Thank you for buying this energy efficient water heater from
State Industries. We appreciate your confidence in our
products.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your
building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
PRINTED IN U.S.A. 1005
GAS-FIRED POWER BURNER
FOR DOMESTIC HOT WATER
PLACE THESE INSTRUCTIONS ADJACENT TO HEATER AND
NOTIFY OWNER TO KEEP FOR FUTURE REFERENCE.
1
TEXT PRINTED OR OUTLINED IN RED CONTAINS
INFORMATION RELATIVE TO YOUR SAFETY. PLEASE
READ THOROUGHLY BEFORE INSTALLING AND USING
THIS APPLIANCE.
500 Tennessee Waltz Parkway
Ashland City, TN 37015
www.statewaterheaters.com
CAUTION
PART NO. 197242-000
SUPERSEDES PART NO. 196758-000
Advertisement
Table of Contents
Related Manuals for State Water Heaters ROOFTOP SRT80 120NE
Summary of Contents for State Water Heaters ROOFTOP SRT80 120NE
- Page 1 COMMERCIAL GAS WATER HEATER • INSTALLATION • OPERATION • SERVICE • MAINTENANCE • LIMITED WARRANTY Thank you for buying this energy efficient water heater from State Industries. We appreciate your confidence in our products. WARNING: If the information in these...
-
Page 2: Rough-In Dimensions
TOP VIEW LEFT SIDE VIEW GAS VALVE PIPING SRT80-120 1/2" NPT Table 1. RECOVERY CAPACITIES - NATURAL GAS / L.P. Approx. Gallon Model Input Capacity SRT80-120 120,000 35.17 kwh 303L Recovery capacities are based on heater performance at 80% thermal efficiency. ROOFTOP SRT80-120NE ROUGH-IN-DIMENSIONS TEMPERATURE RISE - DEGREES °F - GALLONS PER HOUR (LPH) -
Page 3: Installation Information
INSTALLATION INFORMATION OUTBACK Installation Information Model: SRT80-120NE series Electrical: 120/24VAC/60 Hz/5 A Maximum Inlet Pressure: 14"WC Manifold Pressure: 4.50"WC Minimum Inlet Pressure: 6.2"WC Warnings Dummy hot return required if hot return from appliance is not used* Avoid flex gas line usage Avoid use of forklift truck to mount unit on outdoor stand Provide enough clearance to service unit Input: 120,000 btuh... -
Page 4: Table Of Contents
This design complies with the current edition of ANSI Z21.10.3 as an automatic circulating tank type water heater and automatic storage water heater. Detailed installation diagrams are found in this manual. These diagrams will serve to provide the installer with a reference for the materials and methods of piping necessary. -
Page 5: Features
FEATURES IMPORTANT IT IS REQUIRED THAT A QUALIFIED SERVICE TECHNICIAN PERFORM THE INITIAL FIRING OF THE HEATER. A CHECKLIST AND SERVICE INFORMATION section are included at the rear of this manual. By using this checklist the user may be able to make minor operational adjustments and save himself unnecessary service calls. -
Page 6: High Limit Switch (E.c.o.)
HIGH LIMIT SWITCH (E.C.O.) The top immersion well of the upper probe also contains the high limit (energy cutoff) sensor. The high limit switch interrupts the main burner gas flow should the water temperature reach approximately 199°F/93°C. Should the high limit switch activate, it must be reset by cycling power to the unit. -
Page 7: Hot Return Recirculation Pump
HOT RETURN RECIRCULATION PUMP The hot return recirculation pump circulates the hot water through the hot water line to eliminate delays at plumbing fixtures, see Figure 5. FIGURE 5 DRAIN VALVE The drain valve is used to drain the water from the tank assembly and plumbing manifold assembly, see Figure 6. -
Page 8: Air Hose
AIR HOSE The air hose is used to provide a flexible air path from the blower to the burner assembly. It is held in place with two standard hose clamps, see Figure 10. FIGURE 10 FLUE ADAPTER The flue adapter is made of a flat metal plate with an exhaust adapter to mate with the exhaust elbow. -
Page 9: Low Gas Pressure Switch
LOW GAS PRESSURE SWITCH The Low Gas Pressure Switch is a single pole, normally open pressure switch that will close its contacts when a rising pressure of 6.2 inches (1.53 kPa) w.c. is encountered. The contacts will open when the pressure falls below the fixed set point of 6.2 inches of w.c. -
Page 10: Low Water Cutoff Board And Probe
LOW WATER CUTOFF BOARD AND PROBE The Low Water Cutoff Board and Probe monitors the water level to confirm the tank is completely full. This function is very important when the unit is first filled with water and when complete loss of power is encountered during freezing temperatures (in case the unit drains while using the anti-freeze kit), see Figure 20. -
Page 11: Cabinet Assembly
CABINET ASSEMBLY CABINET PANELS There are five panels that comprise the cabinet assembly. The ends of the cabinet allow access to all controls and plumbing. Please confirm all joints are attached correctly and sealed to prevent water leakage inside the cabinet, see Figure 26. FIGURE 26 ADDITIONAL CONTROLS GAS VALVE... -
Page 12: Provide Unit Support
WARNING FLAMMABLE ITEMS, PRESSURIZED CONTAINERS OR ANY OTHER POTENTIAL FIRE HAZARDOUS ARTICLES MUST NEVER BE PLACED ON OR ADJACENT TO THE HEATER. OPEN CONTAINERS OF FLAMMABLE MATERIAL SHOULD NOT BE STORED OR USED IN THE SAME ROOM WITH THE HEATER. Water heater life depends upon water quality, water pressure and the environment in which the water heater is installed. -
Page 13: Roof Curb
RIG AND PLACE UNIT Inspect unit for transportation damage. File any claim with transportation agency. Keep unit upright and do not drop. Spreader bars are not required if top crating is left on unit. Rollers may be used to move unit across the roof. Level the unit by using unit frame. -
Page 14: Outdoor Stand
OUTDOOR STAND This rooftop water heater is approved for an outdoor installation with an optional stand. Contact State Order Entry to acquire optional stand kit. The rooftop stand is constructed of a tubular steel frame along with tubular steel legs. See Figure 32. The legs are three feet in length and slide into the corners of the tubular steel frame. -
Page 15: Venting
VENTING WARNING THE INSTRUCTIONS IN THIS SECTION ON VENTING MUST BE FOLLOWED TO AVOID CHOKED COMBUSTION OR RECIRCULATION OF FLUE GASES. SUCH CONDITIONS CAUSE SOOTING OR RISKS OF FIRE AND ASPHYXIATION. WARNING NEVER OPERATE THE HEATER UNLESS IT IS VENTED TO THE OUTDOORS AND HAS ADEQUATE AIR SUPPLY TO AVOID RISKS OF IMPROPER OPERATION, FIRE, EXPLOSION OR ASPHYXIATION. -
Page 16: Connection Of Gas Pipe
WARNING THE HEATER IS NOT INTENDED FOR OPERATION AT HIGHER THAN 14.0" WATER COLUMN (1/2 POUND OR 3.45 kPa PER SQUARE INCH) SUPPLY GAS PRESSURE. HIGHER GAS SUPPLY PRESSURES REQUIRE SUPPLEMENTAL REDUCING SERVICE REGULATION. EXPOSURE TO HIGHER GAS SUPPLY PRESSURE MAY CAUSE DAMAGE TO THE GAS CONTROLS WHICH COULD RESULT IN FIRE OR EXPLOSION. -
Page 17: Gas Valves
Thermometers are installed in the system as a means of detecting the temperature of the outlet water supply. RELIEF VALVE This heater is equipped with an approved temperature and pressure relief valve. ASME ratings cover pressure relief. CSA ratings cover release rate with temperature actuation. FOR SAFE OPERATION OF THE WATER HEATER, THE RELIEF VALVE(S) MUST NOT BE REMOVED OR PLUGGED. -
Page 19: Operation
MENU NAVIGATION The EMC-5000 Interface has 5 buttons on the touch panel of the interface. The EMC-5000's menus are navigated through the touch panel, as shown to the right, which can be found on the outdoor and remote interface box. Basic navigation through the menus begins with the Main Menu. -
Page 20: Operation
(PC Networking only) Network address of the heater on State Industries Networking network. This number must be unique to all devices on the network. Allowable range of 1 to 32 on the network, or 0 to place the device off the network. -
Page 21: Sequence Of Operation
SEQUENCE OF OPERATION 1. When the control is powered up the outdoor interface and the remote interface should display a blank line and copyright on the 2-line display. 2. After one second, the display should switch to indicate that the touch switches are calibrating. -
Page 22: Prior To Start-Up
The following are fault conditions related to the ignition module: Fault: I.M. LOCK OUT I.M Failed an internal hardware or software check Possible Cause Remedy 1. Ignition Module Failure 1. Replace Ignition Module Fault: I.M. PS CLOSED The pressure switch is stuck closed Possible Cause Remedy 1. -
Page 23: Operating Instructions
OPERATING INSTRUCTIONS IMPORTANT IT IS RECOMMENDED THAT A QUALIFIED SERVICE TECHNICIAN PERFORM THE INITIAL FIRING OF THE HEATER. AT THIS TIME THE USER SHOULD ASK THE TECHNICIAN ANY QUESTIONS IN REGARD TO THE OPERATION AND MAINTENANCE OF THE UNIT. CAUTION BEFORE PROCEEDING WITH THE OPERATION OF THE UNIT, MAKE SURE HEATER AND SYSTEM ARE FILLED WITH WATER AND ALL AIR IS EXPELLED FROM HEATER AND PIPING. -
Page 24: Cathodic Protection
e. Repeat steps (c) and (d) until the specified input rate is achieved. f. Turn the manual gas valve to “OFF”. Replace the pressure regulator cover screw. Remove the pressure gauge or manometer from the manifold pressure tap. Replace the set screw in the manifold pressure tap. -
Page 25: Lighting & Operating Label
FOR YOUR SAFETY READ BEFORE OPERATING WARNING: EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. BEFORE OPERATING: ENTIRE SYSTEM MUST BE FILLED WITH WATER AND AIR PURGED FROM ALL LINES. A. This appliance does not have a pilot. It is equipped with an ignitor device which automatically lights the burner. -
Page 26: General Information
GENERAL INFORMATION POWER BURNER The SEQUENCE OF OPERATION is provided on page 21 and the INITIAL START-UP procedure of the unit on page 23. HIGH LIMIT The high limit switch (not adjustable) is factory set to cutout at 199°F (93°C). The controller must be manually reset by cycling the power to the unit and the water temperature must be below 180°F (82°C). -
Page 27: Lime Scale Removal
Aggressive, very hot and softened water causes rapid consumption of the anode requiring frequent inspections. Anodes are available from your distributor or State Industries. To inspect or replace an anode: The anodes on this heater are easily accessible from the front of the heater making replacement simple and quick. -
Page 28: Installation Diagrams
ONE TEMPERATURE - ONE HEATER VERTICAL STORAGE TANK FORCED CIRCULATION CAUTION: IF BUILDING COLD WATER SUPPLY HAS A BACK-FLOW PREVENTER, CHECK VALVE OR WATER METER WITH CHECK VALVE PROVISIONS FOR THERMAL EXPANSION OF WATER IN THE HOT WATER SYSTEM MUST BE PROVIDED NOTE: CONNECT RETURN LINE FROM HOT WATER CIRCULATING LOOP (IF USED) TO COLD WATER INLET LINE. - Page 29 TWO TEMPERATURE - ONE HEATER HIGH TEMPERATURE WITH OR WITHOUT BUILDING RECIRCULATION DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 5. IF HIGHER PREHEAT TEMPERATURES ARE NECESSARY TO OBTAIN ADEQUATE BOOSTER OUTPUT, ADD AN ANTI-SCALD VALVE FOR HOT WATER SUPPLIED TO FIXTURES. CAUTION: IF BUILDING COLD WATER SUPPLY HAS A BACK-FLOW PREVENTER, CHECK VALVE OR WATER METER WITH CHECK VALVE PROVISIONS FOR THERMAL EXPANSION OF WATER IN THE HOT WATER SYSTEM MUST BE PROVIDED.
- Page 30 TWO TEMPERATURE - TWO HEATERS HIGH TEMPERATURE TWO TEMPERATURE - THREE HEATERS (TWO PRE-HEATERS/ONE BOOSTER HEATER) FOR MULTIPLE HEATER INSTALLATION SEE MANIFOLD KIT SPECIFICATIONS. CAUTION: IF BUILDING COLD WATER SUPPLY HAS A BACK-FLOW PREVENTER, CHECK VALVE OR WATER METER WITH CHECK VALVE PROVISIONS FOR THERMAL EXPANSION OF WATER IN THE HOT WATER SYSTEM MUST BE PROVIDED.
- Page 31 TWO TEMPERATURE - TWO HEATERS (ONE PRE-HEATER/ONE BOOSTER HEATER) DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 5. IF HIGHER PREHEAT TEMPERATURES ARE NECESSARY TO OBTAIN ADEQUATE BOOSTER OUTPUT, ADD AN ANTI-SCALD VALVE FOR HOT WATER SUPPLIED TO FIXTURES.
- Page 32 TWO TEMPERATURE - ONE HEATER HIGH TEMPERATURE DANGER TEMPERATURE SETTING SHOULD NOT EXCEED SAFE TEMPERATURE AT FIXTURES. SEE WATER TEMPERATURE CONTROL WARNING ON PAGE 5. IF HIGHER PREHEAT TEMPERATURES ARE NECESSARY TO OBTAIN ADEQUATE BOOSTER OUTPUT, ADD AN ANTI-SCALD VALVE FOR HOT WATER SUPPLIED TO FIXTURES.
-
Page 33: Checklist And Service Information
CHECKLIST AND SERVICE INFORMATION IMPORTANT The installer may be able to observe and correct certain problems which might arise when the unit is put into operation or when it is re-fired after a prolonged shutdown. HOWEVER, it is recommended that only qualified servicemen, using appropriate test equipment, be allowed to service the heater. -
Page 34: Trouble-Shooting
NOTE: ANY BYPASS OR ALTERATION OF THE UNITS SAFETIES WILL RESULT IN VOIDING THE APPLIANCE WARRANTY. Before performing any troubleshooting familiarize yourself with the particular appliance. Refer to the SEQUENCE OF OPERATION on page 21 before continuing. Make sure the appliance is connected to a 120V AC power supply, manual gas valve is in the ON position, and all electrical connections are secure before continuing to troubleshoot this appliance. -
Page 35: Limited Warranty
MODEL SRT80 120NE LIMITED WARRANTY State Water Heaters, the warrantor, extends the following LIMITED WARRANTY to the owner of this water heater. THE TANK If the glass-lined tank in this water heater shall prove upon examination by the warrantor to have leaked due to natural corrosion from potable water therein, during the first THREE years after initial installation, the warrantor will supply a replacement tank less burner and controls or a complete new State water heater of equivalent size and current model at the warrantor's option. - Page 36 500 TENNESSEE WALTZ PARKWAY ASHLAND CITY, TN 37015 Phone: 800-821-2017 Fax: 800-644-9306 www.statewaterheaters.com...
