Startup or Refill Checklist
Remove spa cabinet side panel (on keypad side) to
access equipment bay.
1)
Check Barrel Unions are tight
Barrels unions are the connections between the
pumps and heater and the plumbing of the spa.
If they become loose, this can cause water loss.
It is important to check the tightness of these
unions periodically, and especially when spa is
first delivered. The unions are designed to be
re-tightened by hand. Rotate the locking nut
clockwise to tighten.
Note:
If you see water escaping from beneath your
spa, the barrel unions should be the first thing you
Leaks from barrel unions are not covered by the
check.
spa's warranty.
2)
Check valves are open
T-handled valves enable the water flow to be
closed to allow removal of spa equipment for
servicing without the need to empty the spa
water. The T handles must be pulled UP to be
OPEN and allow water flow, and they should be
secured open with clips.
3)
Check drain valve is closed and firmly
tightened
See steps 6 - 8 on the illustration on page 15.
14
4)
Check all jets are open
Water flow to most jets can be turned on or off
by rotating the jet face clockwise (on) or anti-
clockwise (off). Check to ensure all jets are open
before filling with water.
On
Off
5)
Fill water to correct level in spa
The spa should be filled until the water level is at
least 50mm above the skimmer. A water fill level
is marked on the side of the filter area (refer
picture below).
Barrel
Unions
Note:
Always remember to remove the filters and fill
spa through filter pipes.
Spa Draining
Every 90 days, depending upon water condition, you
may need to renew the spa water. To drain your spa,
power must be disconnected at the circuit breaker.
Locate the drain inside at the bottom end of the spa
cabinet.
Note:
the drain will not remove all of the water in the
spa. You may have to remove a small amount of water
by hand.
Valves
(Open)
