OPERATION OF RECEIVER
Four Operating Modes in
Receiver
The .PL-2000 .Receiver .has .4 .operating .
modes: .Peak, .Null, .DIST, .and .Sonde .
1 . . .Peak .Mode
The ."Peak" .Mode .employs .the .PL-2000's .
patented .differential .antenna .to .pro-
duce .the .most .accurate .locates . .Depth .
Measurement .(+ .or .– .5% .accuracy) .is .
available .in .Peak .Mode .
2 . . .Null .Mode
The .PL-2000's ."Null" .mode .is .a .fast .locat-
ing .tool .with ."left-right" .guidance .in .a .cross-
section .view .of .the .pipe .and .the .user .
3 . . .DIST .Mode
The ."DIST" .Mode .offers .even .longer .
distance .locating .than .the .Peak .Mode, .
as .much .as .40% .– .50% .further . .Locating .
accuracy .is .less .in .the .DIST .Mode, .and .
Depth .Measurement .is .not .available .
4 . . .Sonde .Mode
The ."Sonde" .Mode .allows .the .Receiver .
to .locate .sewer .Sondes .accurately .and .
measure .their .depths .correctly . . A ny .512 .
Hertz .Sonde .or .the .SubSurface .8 .kHz .
Sonde .can .be .used .
Three Active Frequencies and
Two Passive Frequencies
The .PL-2000 .Receiver .has .3 ."active" .
frequencies, .meaning .these .frequencies .
are .transmitted .by .the .Transmitter .and .
matched .by .the .Receiver: .27kHz, .8Hz .
and .0 .5kHz . .Higher .frequencies ."bleed" .
off .faster .than .lower .frequencies, .and .
lower .frequences .will .go .longer .distances .
down .the .pipes .and .cables . .However, .
higher .frequencies .can .be .applied .more
Continued on page 10
8
MODE AND FUNCTION DISPLAYS
(Peak .Mode, .Null .Mode, .and .Depth .Mea-
surement .Function)
Frequency. Sensitivity Level. (00 to 40)
27kHz SENS.30
Numerical Value. (000 to 100) Bar Graph.
Frequency. Sensitivity Level. (00 to 40)
27kHz SENS.30
Pipe. Left or Right.
Frequency. Sensitivity Level. (00 to 40)
27kHz SENS.30
inch
Depth. NORMALIZED CURRENT MEASUREMENT
(Useful where "ghost" or multiple lines are detected. Highest
current measurement indicates your particular target line.)
9
OPERATION OF RECEIVER
PEAK MODE
Battery Power.
Display of Peak Mode
NULL MODE
Battery Power.
Display of Null Mode
DEPTH MEASUREMENT
FUNCTION
Residual Battery Power.
Display of Depth
Measurement Function
