OPTIONAL ACCESSORIES

1 . . Inductive .Clamp .and .Cables .
Use .the .inductive .clamp .(4 .inch .open-
ing) .for .energizing .telephone .cables .and .
power .cables .inductively .
2 . . .Cable .Drum .with .50 .meter .cable . . .
It .can .be .used .in .the .Loop .Cable .mode .
to .put .a .strong .signal .on .a .target .line, .or .
when .you .can't .get .a .good .ground . .You .
can .also .make .up .your .own .Loop .Cable .
if .you .prefer .
3 . . 8 .KHz .Sonde . .
Locate .plastic .pipes, .clay-pipe .sewers, .
etc . .by .pushing/pulling .a .sonde .transmit-
ter .through .them .
4 . . Heavy-Duty . A BS .Plastic .Hard .Case . .
Transport .the .PL-2000 .in .a .custom-foam .
hard .case .for .maximum .protection .
2

OPERATION OF TRANSMITTER

Transmitter Unit
Operation Panel
1 5
. 1 Power .Switch, .On/Off
. 2 Mode .Selection .Switch
. 3 Frequency .Selection .Switch
4
. Output .Power .Level .Switches
5
. LCD .Display
3
Handle
Operation Panel
Direct Mode Connection
Battery Compartment Cover
Serial Number Plate
4
2 3
