- Page 1 99400 Series Electric Rolling Motor For 3/4” – 3” (19.1mm – 76.2mm) Tube O.D. Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions Read these instructions before using this tool. www.elliott-tool.com...
-
Page 3: Table Of Contents
Introduction ......................4 Safety Instructions ....................5 Setup ........................7 Troubleshooting Electric Rolling Motors............... 8 Care & Maintenance ..................... 9 Brush Replacement .................... 10 99400 Series Parts Diagram ................11 99400 Series Parts List ..................12 Technical Information ..................13 99400 Series... -
Page 4: Introduction
If you have any questions regarding this product, manual or operating instructions, please call Elliott at +1 800 332 0447 toll free (USA only) or +1 937 253 6133, or fax us at +1 937 253 9189 for immediate service. -
Page 5: Safety Instructions
Do not continue to run the motor after the motor has reached its maximum torque. Do not operate the motor beyond the maximum amperage rating shown on the name plate. Use only original replacement parts from the motor manufacturer. 99400 Series... - Page 6 99400 Series...
-
Page 7: Setup
Reference ELC Setup information in TM-71. To get full use of the torque shut-off feature, this motor must be used with the Elliott Model ELC110220 Electronic Torque Controller. Connect the power cord on the motor to one end of the included adapter cord and then connect the 7-pin connector on the adapter cord to the torque con- troller receptacle. -
Page 8: Troubleshooting Electric Rolling Motors
Motor is not auto-reversible Motor must be manually reversed. Replace brushes. See “Brush Replace- Carbon brushes need replaced. ment” on page 10. Motor is losing power. Ensure power cord is proper length and Proper amperage is not reaching motor. gauge. 99400 Series... -
Page 9: Care & Maintenance
Frequency and duration of cooling periods are dependent on the ambient tempera- ture. If using in conjunction with Elliott ELC110220, this practice will not adversely affect the perfor- mance of the controller. If the motor becomes hot to the touch, run the motor outside of the tube in free speed for 3 to 5 minutes to increase motor air flow and decrease motor temperature. -
Page 10: Brush Replacement
12 o’clock and 6 o’clock positions (Exception: If handle is installed at the 6 o’clock position, then air vents will be located at the 3 o’clock and 9 o’clock positions.) NOTICE NOTICE: Always remove carbon brushes before changing the handle position. 99400 Series... -
Page 11: 99400 Series Parts Diagram
99400 Series Parts Diagram 99400 Series... -
Page 12: 99400 Series Parts List
99400 Series Parts List Description Part Number Description Part Number Rotor Assembly 40-74643100 Coupling half 40-71540560 Deep Groove Ball Bearings Cup Spring 6000 2Z 40-80410021 28/12,2x1 40-80200713 Seal 10x14x1 40-83000507 Shim 12/18x0,5 40-80200503 Magnetic Disk Assembly 40-7633J325 Shim 12/18x0,2 40-80200502... -
Page 13: Technical Information
) (115+3) dB re 1 pW working place-related emission figure (L ) 105 dB per DIN 45635 – 21 – KL 2 noise level (L ) 107 dB re 1 pW working place-related emission figure (L , cyc) 100 dB per DIN 45635. 99400 Series... - Page 14 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Contact us or your local support. Locally Supported By: Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 Phone: +1 937 253 6133 • +1 800 332 0447 www.elliott-tool.com/support...
