Summary of Contents for Elliott 99062 Series
- Page 1 99062 Series Electric Rolling Motor For 1/4” – 5/8” (6.35mm – 15.88mm) Tube O.D. Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions WARNING: Read these instructions before using this tool. www.elliott-tool.com...
-
Page 3: Table Of Contents
Safety Instructions ....................5 Setup ........................7 Troubleshooting Electric Rolling Motors............... 9 Care & Maintenance ................... 10 Brush Replacement .................... 11 99062 Series Parts Diagram ................12 99062 Series Parts List ..................13 Technical Information ..................14 Warranty ......................15 99062 Series... -
Page 4: Introduction
If you have any questions regarding this product, manual or operating instructions, please call Elliott at +1 800 332 0447 toll free (USA only) or +1 937 253 6133, or fax us at +1 937 253 9189 for immediate service. -
Page 5: Safety Instructions
Do not continue to run the motor after the motor has reached its maximum torque. Do not operate the motor beyond the maximum amperage rating shown on the name plate. Use only original replacement parts from the motor manufacturer. 99062 Series... - Page 6 ® 99062 Series TM-101 Model No. 9017 Super Maxi-Torq Pneumatic Rolling Control Page 6 of 20...
-
Page 7: Setup
Setup Connect to Torque Controller To get full use of the auto-reverse and torque shut-off features, this motor must be used with the Elliott Model ELC110220 Electronic Torque Controller. Connect the 7-pin connector on the motor cord to the 7-pin socket on the torque controller. The controller will automatically detect whether the motor is 110V or 220V and whether the motor is auto-reversing or manual reversing. - Page 8 Refer to the chart below to determine the required minimum wire size. Recommended Minimum Wire Gauge for Extension Cords Nameplate Extension Cord Length Amperes 25’ (7.6m) 50’ (15.2m) 75’ (22.8m) 100’ (30.5m) 150’ (45.7m) 200’ (61.0m) 0.0 - 5.0 99062 Series...
-
Page 9: Troubleshooting Electric Rolling Motors
See Care & Maintenance Motor runs hot. Ambient temperature are high. on page 10. Have the motor serviced by an Defective motor. authorized repair specialist. Motor will not Ensure plug connection to torque Loose plug connection. auto-reverse. controller is secure. 99062 Series... -
Page 10: Care & Maintenance
Frequency and duration of cooling periods are dependent on the ambient temperature. If using in conjunction with Elliott ELC110220, this practice will not adversely affect the performance of the controller. -
Page 11: Brush Replacement
6. Slide the brush holder & carbon brush into slot in the housing set. 7. Repeat steps 2 thru 5 for replacing the carbon brush on the other side of the armature (Item 12). 8. Replace the housing set & the (7) side screws. 99062 Series... -
Page 12: 99062 Series Parts Diagram
99062 Series Parts Diagram 99062 Series... -
Page 13: 99062 Series Parts List
99062 Series Parts List Item Part Number Description 810-037-037 QR Chuck (3/8” Sq. both ends) 810-025-037 QR Chuck (1/4” Sq. x 3/8” Sq.) 445903 Square Adapter 44-324376-4 Spindle 44-211242 Ball Bearing 44-233925-5 Retaining Ring 44-226578-7 Helical Gear 44-210028-2 Ball Bearing... -
Page 14: Technical Information
Weight (Lbs. / Kg): 2.7 / 1.2 Dimensions (with toolbox): Length (Inches / mm): 20 / 508 Width (Inches / mm): 10.5 / 266.7 Height (Inches / mm): 10 / 254 Weight (Lbs. / Kg): 6.3 / 2.9 99062 Series... -
Page 15: Warranty
WARRANTY Should any part, of Seller’s own manufacture, prove to have been defective in material or workmanship when shipped (as determined by Seller), Seller warrants that it will, at its sole option, repair or replace said part f.o.b., point of manufacture, provided that Buyer notifies, in writing, of such defect within twelve (12) months from date of shipment from the manufacturing plant. - Page 16 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Contact us or your local support. Locally Supported By: Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 Phone: +1 937 253 6133 • +1 800 332 0447 www.elliott-tool.com/support...
