- Page 2 1. Brass Elbow 2. ½”NPT Brass nut 4. Speaker 6. Rain Shower head 5. White LED Light 12. Steamer Cleaning Port 14. Foldable Seat 16. Flex Drain Assembly 13. Massage Jet 24. Exhaust Fan 22. Door Handles...
- Page 3 25. Color LED Light 4x16mm Screws:7pcs Brackets: 11pcs 26. Metal Bracket 3.5x30 Screws:8pcs 29. Faucet Valves 28. Hand Shower Pole 4x10mm Screws:33pcs Wall brackets: 4pcs 3mm Hex Allen Wrench:1Pc 4x25mm Screws:12pcs 34. Door Rollers Panel screw hole cover: 12 Pcs...
-
Page 4: Electrical Junction Box
Electrical junction box... - Page 5 Install the Shower base 1. Carefully put the shower base on the floor in the final position where shower will be when complete. 2. Put the Spirit Level on the shower base and check the base for level in both directions as illustrated. If not use a wrench to adjust the leveling feet to make sure the shower base becomes level.
- Page 6 Corner Aluminum Profile...
- Page 7 4. Attach white metal brackets on the back side at top, middle and bottom of panels with fold down seats to allow panels to be removed from inside shower once shower is in place.
- Page 8 4mm Plastic washer...
- Page 9 Connect Wires 1. Put the top cover onto the steam shower carefully (illustrated in Drawing A) 2. Use a phillips screwdriver to fix the top cover to the shower assembly with 4x10mm screws and stainless steel brackets. Illustrated in Drawing B. 3.
- Page 10 Install Moveable doors 1. Hang the doors on the upper track (Illustrated in Drawing A) Then press the lower spring loaded wheels down to hook into the lower aluminum track. (Illustrated in Drawing B) Note: there is an adjustment screw on the upper wheel assembly to adjust if there is a gap between the moveable doors or if the doors are overly stiff in movement then adjust the upper wheels to correct fit of doors.
- Page 11 Connect Fittings and Water Lines 1. Connect the Overhead rain shower head hose to rain shower head joint. Connect the drain hose from the steamer to the shower base and connect the steam outlet hose to the steam outlet, Illustrated in Drawing A. 2.
