- Page 1 AOC-CTGS-i2T User's Guide Revision 1.0c...
- Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
-
Page 3: About This Add-On Card
The AOC-CTGS-i2T with NC-SI allows cus- tomers to monitor the servers remotely. Based on the latest Intel® X550 controller, the AOC-CTGS-i2T is an excellent choice for customers who are looking to expand their network connectivity with highest bandwidth. -
Page 4: Smc Networking Add-On Cards
AOC-CTGS-i2T Add-on Card User's Guide Conventions Used in the User's Guide Pay special attention to the following symbols for proper system installation and to prevent damage to the system or injury to yourself: Warning: Important information given to ensure proper system installation or to prevent damage to the components or injury to yourself. - Page 5 2 SFP+ (10Gb/port) 4.85" (123mm) x 1.54" (39mm) AOC-CTG-i2T 10GbE MicroLP PCI-E x8 Intel® X540-AT2 2 RJ45 (10GBase-T) 4.8” (123mm) x 2.75” (77mm) AOC-CTGS-i2T 10GbE MicroLP PCI-E x4 Intel® X550-AT2 2 RJ45 (10GBase-T) 4.45” (113mm) x 1.54” (39mm) AOC-C25G-m1S 25GbE...
-
Page 6: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML... -
Page 7: Table Of Contents
AOC-CTGS-i2T Add-on Card User's Guide Table of Contents Preface About this User's Guide ....................3 About this Add-on Card ....................3 An Important Note to the User ..................3 Returning Merchandise for Service ................3 Naming Convention ....................... 4 SMC Networking Add-on Cards ..................4 Conventions Used in the User's Guide ................. -
Page 8: Chapter 1 Overview
Overview Congratulations on purchasing your add-on card from an acknowledged leader in the industry. Supermicro products are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. For product support and updates, please refer to our website at http://www.supermicro.com/ products/nfo/networking.cfm#adapter. -
Page 9: Technical Specifications
AOC-CTGS-i2T Add-on Card User's Guide Technical Specifications General • Intel® X550 10GbE controller with integrated 10GBase-T copper PHYs • MicroLP Form Factor • PCI-E 3.0 x4 (8GT/s) interface • Dual RJ45 connectors with speeds up to 10Gb/s per port •... - Page 10 Chapter 1: Overview • Supports Fibre Channel over Ethernet (FCoE) • DMA coalescing Virtualization • Support for Virtual Machine Device Queues (VMDq1 and Next Generation VMDq) • L2 Ethernet MAC Address filters and VLAN filters • PCI-SIG SR-IOV (64 VFs) •...
- Page 11 AOC-CTGS-i2T Add-on Card User's Guide OS Support • Windows® Server 2012 R2, 2012, 2008 R2 X86-64 • Linux Redhat EL 6.5 and 7.0 IA-32, X86-64, and IA-64 • Linux SuSE SLES 11 SP3 and 12 IA-32, X86-64, and IA-64 •...
-
Page 12: Compliance/Operating Environment
CBL-NTWK-0612: RJ45 CAT6A 550MHz Rated Blue 24 ft. patch cable Platform Support • Supermicro Twin Server and MicroCloud Systems with MicroLP expansion slot (See MicroLP Compatibility Matrix online) http://www.supermicro.com/support/resources/aoc/microLP_compatibility.cfm Compliance/Operating Environment The AOC-CTGS-i2T add-on card is compliant with the following environmental regulations: • RoHS Compliant 6/6, Pb Free... - Page 13 AOC-CTGS-i2T Add-on Card User's Guide Notes...
-
Page 14: Chapter 2 Hardware Components
DESIGNED IN USA Intel X550 The AOC-CTGS-i2T Layout Major Components The following major components are on the AOC-CTGS-i2T: 1. Intel® X550 10GbE LAN Controller 2. 3.3V Standby Power Enable Jumper 3. (RJ45 Ethernet) LAN Port 1 & LAN1 LED Indicator... -
Page 15: Jumpers And Indicators
AOC-CTGS-i2T Add-on Card User's Guide Jumpers and Indicators Connector Pins Explanation of Jumpers To modify the operation of the add-on card, a Jumper jumper can be used to choose between optional settings. A jumper creates shorts between two pins to change the function of the connector. Pin... -
Page 16: Led Indicators
Chapter 2: Hardware Components LED Indicators Link LED Activity LED GLAN Port LEDs Two LAN ports (LAN 1/LAN 2) are LAN 1/LAN 2 Activity LED (Left) LED State located on the add-on card. Each Color Status Definition Ethernet LAN port has two LEDs. The Amber Flashing Active... -
Page 17: Chapter 3 Installation
Chapter 3: Installation Chapter 3 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam- aging your add-on card, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Precautions •... -
Page 18: Before Installation
AOC-CTGS-i2T Add-on Card User's Guide Before Installation Before you install the add-on card, follow the instructions below. 1. Power down the system. 2. Unplug the power cord. 3. Use industry-standard anti-static equipment such as gloves or a wrist strap and follow the precautions on page 3-1 to avoid damage caused by ESD. -
Page 19: Installing Drivers On Windows
Follow the steps below to install the drivers for Windows. Download the drivers from the Supermicro website at https://www.supermicro.com/wftp/driver. 1. Run CDR-NIC. 2. When the SUPERMICRO window appears, click on the computer icon next to the product model. Note: If the FOUND NEW HARDWARE WIZARD screen displays on your system, click CANCEL. - Page 20 AOC-CTGS-i2T Add-on Card User's Guide Follow the instructions below to build the driver manually. 1. Move the base driver tar file to the directory of your choice. For example: /home/username/ixgbe /usr/local/src/ixgbe 2. Untar/unzip archive, where <x.x.x> is the version number for the driver tar file: tar zxf ixgbe-x.x.x.tar.gz...
-
Page 21: Installing Drivers On Freebsd
Chapter 3: Installation In addition, when using 2.6-based kernels, make sure that older ixgbe drivers are removed from the kernel before loading the new module. To do this, use: rmmod ixgbe; modprobe ixgbe 6. Assign an IP address to the interface by entering the following, where x is the interface number: ifconfig ethx <IP_address>... - Page 22 AOC-CTGS-i2T Add-on Card User's Guide 5. To assign an IP address to the interface, enter the following: ifconfig ixgb<interface_num> <IP_address> 6. Verify that the interface works. Enter the following, where <IP_address> is the IP address for another machine on the same subnet as the interface that is being tested: ping <IP_address>...
- Page 23 Chapter 3: Installation /dev/ixgb/if_ixgb_fx_hw.c optional ixgb /dev/ixgb/if_ixgb_phy.c optional ixgb Edit the kernel configuration file (i.e., GENERIC or MYKERNEL) in /usr/src/sys/ i386/conf, and ensure the following line is present: device ixgb Compile and install the kernel. Reboot the system for the kernel updates to take affect.
- Page 24 AOC-CTGS-i2T Add-on Card User's Guide Notes...
- Page 25 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
