Piper Warrior III Maintenance Manual page 1067

NOTES:
1 - S/N'S 2842008 & UP ONLY.
2 - OPTION AVAILABLE IN
S/N'S2842019 & UP ONLY.
DN30A 22
2 1
GPS
TO DIM
RELAY
DN4A 22
TO PITOT
HEAT SENSOR
TO PITOT HEAT SWITCH
TO ALTERNATOR
OUT SWITCH
TO LOW
VOLTAGE
MONITOR
TO OIL
PRESSURE
SWITCH
W4B 20
DAY
DN1B 22
DN1C 22
P304
TO OPTIONAL
DN3B 22
S-TEC MANUAL
ELECTRIC TRIM
SWITCH
DN32A 22
(See Note 2)
ANNUNCIATOR
DN10A 22
DN18A 22
DN19A 22
PITOT HEAT
OFF/INOP
DN20A 22
DN9A 22
STE1-20 STARTER ENG
DN21A 22
TO STARTER
CONTACTOR
5 AMP FUSE
DN14A 22
ALT INOP
W2A 20
DN16A 22
W6A 20
OIL PRESS
DN12A 22
VACUUM
SENSOR
VACUUM INOP
W4A 20
DN11A 22
LOW BUS VOLT
P6C 20
DN22A 22
CARB ICE
DN13A 22
TO CARBURETOR
ICE DETECTOR
C
NIGHT
P304
C
NO
TO
PITOT
PRESS
P304
SENSOR
TO
ASSY.
TEST
(See Note 1)
PANEL
(OPT)
ANNUNCIATOR
PANEL
(OPT)
DN1A 22
5
DN2A 22
DN3A 22
DN2B 22
