Figure 3-6: Mini 10-Pin and Mini 20-Pin Keyed Header Dimensions
3.16

Target Headers For Part# CYCLONE_ACP

PEmicro Part# CYCLONE_ACP features 3 ports labeled A-C.
3.16.1 PORT A: 10-Pin Keyed Mini Connector (Kinetis, S32 (ARM), other PEmicro-Supported ARM
devices)
The Cyclone provides a keyed 10-pin 0.050-inch pitch double row connector for ARM targets. The
location of the this header is indicated as PORT A in Figure 3-4. The 10-pin keyed mini connector
pin definitions for JTAG mode are as follows:
10-Pin Keyed Mini Connector JTAG Mode Pin Assignments
CYCLONE programmers also support SWD Mode. This replaces the JTAG connection with a
clock and single bi-directional data pin.
10-Pin Keyed Mini Connector SWD Mode Pin Assignments
User Manual For CYCLONE Programmers
Figure 3-5: 20-Pin Un-Keyed Header Dimensions
PIN 1 - TVCC
PIN 3 - GND
PIN 5 - GND
PIN 7 - NC
PIN 9 - NC
PIN 1 - TVCC TMS/SWDIO - PIN 2
TMS - PIN 2
TCK - PIN 4
TDO - PIN 6
TDI - PIN 8
RESET - PIN 10
9
