SISO 14.60.290-0 User Manual

Finger print lock
Hide thumbs

Advertisement

Quick Links

Download this manual
User manual for
SISO finger print
lock

Advertisement

loading
Need help?

Need help?

Do you have a question about the 14.60.290-0 and is the answer not in the manual?

Questions and answers

Related Manuals for SISO 14.60.290-0

Summary of Contents for SISO 14.60.290-0

  • Page 1 User manual for SISO finger print lock...

  • Page 2: Table Of Contents

      1. PRODUCT APPEARANCE ................................I   1.1. Panel appearance ..................................I   1.2. L ................................II OCK BODY APPEARANCE   2. PRODUCT DIMENSION ............................... - 1 -   2.3. Hook dimension ................................... - 2 -   4. PRODUCT FUNCTIONS ................................- 6 -  ...
  • Page 3 1. PRODUCT APPEARANCE 1.1. Panel appearance...
  • Page 4 1.2. Lock body appearance...

  • Page 5: Product Dimension

    2. PRODUCT DIMENSION 2.1. Panel dimension 2.2. Lock body dimension...

  • Page 6: Hook Dimension

    2.3. Hook dimension Hook A Hook B - 2 -...
  • Page 7 2.4. Installation dimension Lock body installation Lock Panel installation - 3 -...
  • Page 8 Hook A installation Hook B installation - 4 -...
  • Page 9 3. Installation drawings - 5 -...

  • Page 10: Product Functions

    4. PRODUCT FUNCTIONS 4.1 Functions & features： Functions Features Sound prompt Lock will make sound when press fingerprint, battery is low voltage,correct/wrong key is input and unlocking for a long time Green: means correct Red: means incorrect Light prompt Blue: means low voltage White: standby condition When battery’s voltage is lower than 4.5V, light will shines in blue and lock sounds “di di”...

  • Page 11: Parameters

    4.2. Parameters Material ABS for lock body shell 、PC for panel Static power consumption <40uA Power consumption Dynamic power consumption<250mA Standby power consumption<50mA DC6V(AA 1.5V×4pcs) Working voltage Can be used for around 1 year Working temperature -20℃ ~ +65℃ Working environment Working humidity 10% ~ 90%RH Air static 15KV Anti-static...

  • Page 12: Set Fingerprint

    5.2. Set fingerprint Items Operation Keep pressing “1”button for 2s, lock will prompt with “di”and light shine in green.Input first fingerprint is management Set management fingerprint,light shine in blue,the fingerprint needs to be fingerprint verified three times.First verification“di”,second“di di”,third“di di di”.Pass three verification, fingerprint successfully Keep pressing “1”button for 2s,during green light shining,...

  • Page 13: Change Fingerprint Mode

    5.4 Change fingerprint mode (Factory setting:single fingerprint mode) Single fingerprint Keep pressing button “4” for 1s, lock prompts with “di” and LED shine once. Change to single fingerprint mode successfully. mode Double fingerprint Keep pressing button “4” for 1s, lock prompts with “di di” and LED shine mode twice.
