LPKF ZelFlex ZR User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Double-sided mechanical stretching frame
Step by step User guide
1
V1.00 © 2009

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZelFlex ZR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LPKF ZelFlex ZR

Summary of Contents for LPKF ZelFlex ZR

  • Page 1 ZelFlex ZR Double-sided mechanical stretching frame Step by step User guide V1.00 © 2009...
  • Page 2 ZelFlex ZR Frame without stencil © 2009...
  • Page 3 ZelFlex ZR Using hexagon- headed screws, attach the rear bar according to the stencil length. © 2009...
  • Page 4 ZelFlex ZR Tighten the two hexagon-headed screws. Rear bar must be parallel to the rear frame profile. © 2009...
  • Page 5 ZelFlex ZR Unwind the nuts from the stretching screws by about 10 mm. © 2009...
  • Page 6 ZelFlex ZR Unwind the nuts from the rear bar by about 4 mm. © 2009...
  • Page 7 ZelFlex ZR Orient the stencil according to the coding side (offset for stencil cut-out on rear bar). © 2009...
  • Page 8 ZelFlex ZR Insert the stencil on pins in rear clamping bar and close it with holding bar. © 2009...
  • Page 9 ZelFlex ZR Fasten nuts clamping bar lightly. © 2009...
  • Page 10 ZelFlex ZR Unwind the nuts from the front bar by about 4mm. © 2009...
  • Page 11 ZelFlex ZR Insert the stencil on pins in front stretching bar and close it with holding bar. © 2009...
  • Page 12 ZelFlex ZR Fasten nuts stretching bar lightly. © 2009...
  • Page 13 ZelFlex ZR Assembly of protect frame Tighten nuts stretching units evenly to lightly tension of the stencil. V1.00 © 2009...
  • Page 14 ZelFlex ZR Assembly of protect frame Tighten the nuts on both bars normally. V1.00 © 2009...
  • Page 15 ZelFlex ZR Assembly of protect frame The gap between locker on the stretching screw and the bar should be approx. 3 mm for required working tension. V1.00 © 2009...
  • Page 16 ZelFlex ZR Assembly of protect frame Frame with stretched stencil from bottom side. V1.00 © 2009...
  • Page 17 ZelFlex ZR Assembly of protect frame Your ZelFlex ZR frame is ready to use! V1.00 © 2009...
  • Page 18 ZelFlex ZR www.ZelFlex.com V1.00 © 2009...
  • Page 19 Thank you for your attention. LPKF Laser & Elektronika d.o.o. · Polica 33 · 4202 Naklo · Slovenia sales@lpkf.si · support@lpkf.si © 2009...
