DECrepeater 90FS
Installation and Configuration
Part Number: EK–DEFMI–IN. A01
August 1994
This manual describes how to install and configure the
DECrepeater 90FS module.
Revision/Update Information:
This is a new manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DECrepeater 90FS and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Equipment DECrepeater 90FS

Summary of Contents for Digital Equipment DECrepeater 90FS

  • Page 1 DECrepeater 90FS Installation and Configuration Part Number: EK–DEFMI–IN. A01 August 1994 This manual describes how to install and configure the DECrepeater 90FS module. Revision/Update Information: This is a new manual.
  • Page 2 August 1994 The information in this document is subject to change without notice and should not be construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that may appear in this document.

  • Page 3: Table Of Contents

    ......... DECrepeater 90FS Installation Menu (DEChub 90/Standalone Options) DECrepeater 90FS Installation Menu (DEChub 900 Options) .
  • Page 4 ......7 DECrepeater 90FS Best-Case Maximum Launch Power ...

  • Page 5: Safety

    Safety Any warning or caution that appears in this manual is defined as follows: WARNING Contains information to prevent personal injury. CAUTION Contains information to prevent damage to equipment. VORSICHT Enth lt Informationen, die beachtet werden müssen, um den Benutzer vor Schaden zu bewahren. ACHTUNG Enth lt Informationen, die beachtet werden müssen, um die Ger te vor Schaden zu bewahren.
  • Page 6 Safety (Cont.) The cautions that must be observed for the hardware described in this manual are listed below in English, German, French, and Spanish. The pages on which these safety messages appear are also listed. WARNING Some fiber optic equipment can emit laser or infrared light that can injure your eyes.
  • Page 7 Safety (Cont.) CAUTION This action deletes all configured settings and replaces them with factory default values. All configuration settings will be lost. [Page 25.] ACHTUNG Bei diesem Vorgang werden alle Konfigurationseinstel- lungen gel scht und die Werkseinstellungen wieder ein- gesetzt. Alle Konfigurationsdaten gehen verloren. ATTENTION Cette action supprime tous les paramètres de configura- tion et les remplace par des valeurs prédéfinies.
  • Page 8 Safety (Cont.) CAUTION If power is interrupted during Stage 3 of the DLU process, the firmware image can become corrupted. Do not turn off power to the unit or perform any action that can cause the unit to lose power during Stage 3 of the DLU process. [Pages 34, 36, and 39.] ACHTUNG Sollte w hrend der Phase 3 des DLU–Prozesses eine...

  • Page 9: Introduction

    Introduction The DECrepeater 90FS (also referred to in this manual as the module) is an Ethernet repeater that provides two external 10BaseFL fiber-optic ports and one external AUI port. In this manual, the term 10BaseFL refers to the International Standards Organization (ISO) 8802-3/ANSI/IEEE 802.3 fiber-optic local area networks (LAN) standards.

  • Page 10: Features

    Introduction (Cont.) Features Your DECrepeater 90FS module includes the following features: • ThinWire, 10Base2 port available as an external connection on the module side panel (when the module is installed as a standalone unit) or to the backplane segment in a DEChub 900 or a DEChub 90.

  • Page 11: Front Panel

    OBM. 13) Cooling fan unit — Provides air circulation. 14) ThinWire port connector — Connects through a BNC T-connector when module is operating as a standalone unit. LKG-8817-93I DECrepeater 90FS Installation and Configuration...

  • Page 12: Back Panel

    DEChub 900 or a DEChub 90. 7) Cooling fan unit — Provides air circulation. 8) Back cover — The back cover is used only when the module is a standalone unit. LKG-8881-93I DECrepeater 90FS Installation and Configuration...

  • Page 13: Installing The Module

    DEChub 90. Installing the Module as a Standalone Unit You can use the DECrepeater 90FS as a standalone unit by placing it onto a table, mounting it onto a wall, or installing it into a standard 19-inch rack using a shelf assembly (Digital Part Number: H9544–MS).
  • Page 14 Connect the cable from the power supply (Digital Part Num- ber: H7827-BA) to the power connector on the back of the module. b. Plug the power supply cable into the power supply, then into a wall outlet. DECrepeater 90FS Installation and Configuration...
  • Page 15 Module OK LED lights and remains lit. LKG–8820-93I NOTE: If the LEDs do not operate as described, refer to the section titled Problem Solving Using the LEDs. Go to the section titled Connecting the Cables. DECrepeater 90FS Installation and Configuration...

  • Page 16: Removing The Back Cover

    • Into a DEChub 900, go to the section titled Installing the Module into a DEChub 900. • Into a DEChub 90, go to the section titled Installing the Module into a DEChub 90. LKG-8818-93I DECrepeater 90FS Installation and Configuration...

  • Page 17: Installing The Module Into A Dechub 900

    Installing the Module (Cont.) Installing the Module into a DEChub 900 The DECrepeater 90FS hot-swap feature allows you to install the module into the DEChub 900 without turning off power. Seating the module initiates the powerup sequence. If any of the module’s power requirements Compare your module’s power...
  • Page 18 Hub Manager status display shows: LKG–9550-94I DECrepeater 90FS NOTE: If the LEDs do not operate as described, refer to the section titled Problem Solving Using the LEDs. Go to the section titled Connecting the Cables. DECrepeater 90FS Installation and Configuration...

  • Page 19: Installing The Module Into A Dechub 90

    Installing the Module (Cont.) Installing the Module into a DEChub 90 The DECrepeater 90FS hot-swap feature allows you to install the module into the DEChub 90 without turning off power. Seating the module initiates the powerup sequence. Install the module into slot 7 or 8 only.
  • Page 20 Module OK LED lights and remains lit. LKG–9550-94I NOTE: If the LEDs do not operate as described, refer to the section titled Problem Solving Using the LEDs. Go to the section titled Connecting the Cables. DECrepeater 90FS Installation and Configuration...

  • Page 21: Connecting The Cables

    Connect the other end of those cables to the remote primary port. e. Connect the master’s secondary port cables to the master’s secondary port. Connect the other end of those cables to the remote secondary port. DECrepeater 90FS Installation and Configuration...
  • Page 22 If your site is prewired, the fiber-optic cables should be labeled with information on size and attenuation characteristics. Digital recommends that you use 62.5/125-micron multimode graded index fiber-optic cable with the DECrepeater 90FS. Refer to the section titled Fiber-Optic Loss Budget for more information. WARNING...
  • Page 23 LKG–8819-93I NOTE: To disconnect the cable, push the connector slide latch to the unlocked position, then disconnect the cable. After all cables are installed, go to the section titled Configuring the Module. DECrepeater 90FS Installation and Configuration...

  • Page 24: Removing The Module

    Unlock b. To disconnect the AUI connec- tor, push the connector slide latch to the unlocked position, then disconnect the cable. LKG–8822-93I DECrepeater 90FS Installation and Configuration...
  • Page 25 DEChub 900 slot or the DEChub 90 slot. b. Pivot the module back on its bottom mounting tab, and dis- engage the module from the backplane. Mounting LKG–8731-93I Lift release lever Mounting LKG–8838-93I DECrepeater 90FS Installation and Configuration...

  • Page 26: Configuring The Module

    The setup port on the DEChub 900 MultiSwitch or on the module’s front-panel serial port (when the module is operating as a standalone unit or in a DEChub 90) allows you to access and set DECrepeater 90FS parameters. This section describes how to access the module from either port and set those parameters.

  • Page 27: Accessing The Setup Port

    H8571-J To setup port device H8571-J H8575-A BN24H cable H8575-A BN24H cable DEChub 900 MultiSwitch DECrepeater 90FS LKG-8825-94I 3. Press on the setup port device a few times until a menu appears. Return DECrepeater 90FS Installation and Configuration...
  • Page 28 Configuring the Module (Cont.) a. If the setup port device is connected to the module’s front-panel serial port, the DECrepeater 90FS INSTALLATION MENU appears. Go to the section titled DECrepeater 90FS Installation Menu (DEChub90/Standalone Options). b. If the setup port device is connected to the Hub Manager setup port on the...

  • Page 29: Start Redirect Mode

    (such as the DECrepeater 90FS) that is installed in the DEChub 900. Choosing this option allows you to configure or obtain status of an installed network module by accessing the module’s installation menu.

  • Page 30: Decrepeater 90Fs Installation Menu (Dechub 90/Standalone Options)

    DECrepeater 90FS INSTALLATION MENU when the module is installed into a DEChub 90 or as a standalone unit. The following is an example of the DECrepeater 90FS INSTALLATION MENU: DECrepeater 90FS DECrepeater 90FS INSTALLATION MENU Reset with Factory Defaults Reset with Current Settings...

  • Page 31: Decrepeater 90Fs Installation Menu (Dechub 900 Options)

    DECrepeater 90FS Installation Menu (DEChub 900 Options) This section shows the options available from the DECrepeater 90FS Installation Menu when the module is installed into the DEChub 900. The following is an example of the DECrepeater 90FS Installation Menu: DECrepeater 90FS – Slot 3...

  • Page 32: Description Of Menu Options

    Out-of-band interface IP address –– this address is deleted. • Out-of-band interface port speed –– reset to 9600. Following are the only parameters that are not reset: • Serial number • Reset count • Error log data DECrepeater 90FS Installation and Configuration...
  • Page 33 Enter selection : 1 DECrepeater 90FS – slot 7 RESET WITH FACTORY DEFAULTS * * * * * * * * * * * * * * * * * * * * * * * * * * * * * *...
  • Page 34 The following is an example of the dialog associated with this option (user response is shown in boldface type): Enter selection : 2 DECrepeater 90FS – slot 3 RESET WITH CURRENT SETTINGS This selection will reset your system with the current configuration settings.
  • Page 35 The following is an example of the display associated with this option: Enter selection : 3 DECrepeater 90FS Slot 3 DECrepeater 90FS, 2 port FO Ethernet Rptr SNMP HW=v2 RO=v01 SW=v1.1 SysUpTime : 01:36:00 SNMP Read/Write Community...
  • Page 36 SNMP entity. Return Enter the community string [public] : tony1970 SNMP Read/Write community string set. Press Return for Main Menu ... DECrepeater 90FS Installation and Configuration...
  • Page 37 The following is an example of the dialog associated with this option (user response is shown in boldface type): Enter selection : 5 DECrepeater 90FS – slot 3 ADD SNMP TRAP ADDRESSES Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...
  • Page 38 The following is an example of the dialog associated with this option (user response is shown in boldface type): Enter selection : 6 DECrepeater 90FS – slot 3 DELETE SNMP TRAP ADDRESSES Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...
  • Page 39 CURRENT RESET COUNT: 14 Entry # Timestamp Reset Count = 13 Trap @315 in console_cfg.c Backplane clock failure Return Dump another entry Y/[N]? N No more Error Log entries. Press Return for Main Menu ... DECrepeater 90FS Installation and Configuration...
  • Page 40 The following is an example of the dialog associated with this option (user response is shown in boldface type): Enter selection : 8 DECrepeater 90FS – slot 3 SET IN-BAND INTERFACE IP ADDRESS Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...
  • Page 41 The following is an example of the dialog associated with this option (user response is shown in boldface type): Enter selection : 9 DECrepeater 90FS – slot 3 SET IN-BAND INTERFACE DEFAULT GATEWAY ADDRESS Format: The standard 4 octet dotted decimal notation in which each octet of the address is represented as a decimal value, separated by a ’.’...
  • Page 42 IP address. If the module is not configured with an IP address, select the Set In-Band Interface IP Address option (option [8] ) from the DECrepeater 90FS Installation Menu to set an IP address. Do not use the DEChub 900 MultiSwitch Hub Manager’s IP address to upgrade the DECrepeater 90FS.

  • Page 43: Dlu Process Description

    LED remains on. The Module OK LED turns off. The Redundancy Enabled LED lights. • HUB Manager display — DECrepeater 90FS unknown • Typical time to complete this stage — normally 1 minute. However, due to variances in network configurations (load path, bit rate, and traffic levels), this stage of the DLU process can take up to 10 minutes to complete.
  • Page 44 LED and the Module OK remain on. The Redundancy Enabled LED lights. • HUB Manager display — DECrepeater 90FS unknown • Typical time to complete this stage — normally 30 seconds. The module resets, runs self-test, and then begins executing the new firmware image.
  • Page 45 IP address. If the module is not configured with an IP address, select the Set In-Band Interface IP Address option (option [8] ) from the DECrepeater 90FS INSTALLATION MENU to set an IP address. Do not use the DEChub 900 MultiSwitch Hub Manager’s IP address to upgrade the DECrepeater 90FS.
  • Page 46 ... Press Return Key to Start Load [Ctrl/C to abort]... NOTE: The DECrepeater 90FS is nonfunctional only during reset and self-test (about 1 minute of Stage 4) of the DLU process. During the first three stages of the process, the module continues to function as a repeater.
  • Page 47 The Hub Manager status display indicates the following: Hub Manager Status Display 4: DECrepeater 90FS unknown The Hub Manager status display continues to display this message until the DLU process is complete. This is normal. DECrepeater 90FS Installation and Configuration...
  • Page 48 The screen displays one of the following: • If the module is installed into a DEChub 90 or as a standalone unit, the screen displays the DECrepeater 90FS INSTALLATION MENU. • If the module is installed into a DEChub 900, the screen displays the follow- ing message: Press Return for Main Menu ...
  • Page 49 The module is nonfunctional only during reset and self-test (about 1 minute of Stage 4) of the DLU process. During the first three stages of the process, the module continues to function as a repeater. DECrepeater 90FS Installation and Configuration...
  • Page 50 To enable out-of-band management, you need to assign an OBM IP address (use Option [11]) and select an OBM port speed (use Option [12]) from the DECrepeater 90FS INSTALLATION MENU. The following is an example of the dialog associated with this option (user response...
  • Page 51 Press Return for Main Menu ... The OBM port speed you select must match the speed of your OBM port device. NOTE: The front-panel serial port, when used for OBM, supports only 9,600 baud or higher speed modems. DECrepeater 90FS Installation and Configuration...
  • Page 52 [2] Return to main menu Return Enter selection [N] :1 Return Press Y to confirm [N] : y Press Return for Main Menu ... Switching console port to Out-of-Band Management mode Press Return for Main Menu ... DECrepeater 90FS Installation and Configuration...
  • Page 53 A modem with a 25-pin D-Sub connector BN25G-xx /8585-AA A PC with a 9-pin D-Sub communications port BN24H-xx /8584-AA An 8-pin MJ terminal server xx indicates cable length in meters. Not for connection to public networks in Sweden, Germany, or Japan. DECrepeater 90FS Installation and Configuration...
  • Page 54 Type ctrl-C to end Out of Band Management mode. c. Press on the setup port device within 30 seconds after the message Ctrl/C is displayed on the setup port device to end the OBM session. DECrepeater 90FS Installation and Configuration...

  • Page 55: Led Descriptions

    Port Link Associated Associated Associated fiber-optic receiv- fiber-optic receiv- fiber-optic port has er is not detect- er is detecting an intermittent ing sufficient light sufficient light. connection. or not connected. DECrepeater 90FS Installation and Configuration...

  • Page 56: Problem Solving Using The Leds

    If the problem persists, replace the power supply or the module. If the module is installed into either the DEChub 900 or the DEChub 90: Reseat the module. (continued on next page) DECrepeater 90FS Installation and Configuration...
  • Page 57 Replace the appropriate power supply. faulty. Module OK Module does not Ensure Power LED is on. LED is off. have sufficient power. Self-test is in Wait up to 1 minute for self-test progress. to complete. (continued on next page) DECrepeater 90FS Installation and Configuration...
  • Page 58 7 or 8. Verify that the MAU (if one is installed) and connectors are installed correctly and operating properly. Port state LED is Associated port is Enable the associated port if necessary. flashing. disabled by network management. DECrepeater 90FS Installation and Configuration...

  • Page 59: Connector Pin Assignments

    Power (12V) Ground CI– Ground DO– 15-pin AUI connector LKG-8866-93I Serial Port (8-pin MJ) Connector The following illustration shows the front-panel serial port 8-pin MJ connector and its pin assignments: Assignment 8-pin MJ connector LKG-9237-94I DECrepeater 90FS Installation and Configuration...

  • Page 60: H8571-J Adapter

    The following illustration shows the H8575-A adapter (6-pin MMJ to 25-pin D-Sub connector) and its pin assignments: 8 MJ DB25 TXD GND TXD GND RXD GND H8585-AC Note: Not for connection to public networks in Sweeden, Germany, or Japan. LKG–6975-92I DECrepeater 90FS Installation and Configuration...

  • Page 61: H8585-Ac Adapter

    * Note: Not for connection to public networks in Sweden, Germany, or Japan. LKG–6975-92I H8584-AA Adapter The following illustration shows the H8584-AA adapter (8-pin MP to 6-pin MJ connector) and its pin assignments: 8 MP 6 MJ RXD GND TXD GND TXD GND TXD GND H8584-AA LKG–6972-92I DECrepeater 90FS Installation and Configuration...

  • Page 62: H8585-Aa Adapter

    Connector Pin Assignments (Cont.) H8585-AA Adapter The following illustration shows the H8585-AA adapter (8-pin MJ to 9-pin DB connector) and its pin assignments: 8 MJ DRDY TXD GND RXD GND H8585-AA LKG–6973-92I DECrepeater 90FS Installation and Configuration...

  • Page 63: Redundant Fiber-Optic Link Configuration

    A non-responder port provides only partial fault detection because it does not signal the master if a failure occurs in its receive link. NOTE: The DECrepeater 90FS and the DECrepeater 900FP are the only DECrepeaters that can be configured as redundant port repeaters.
  • Page 64 Ethernet communications. Activity defaults to the primary link after a reset condition. • Secondary Link The secondary link is the other link of the RLP to which the master fails over if there is a failure in the primary link. DECrepeater 90FS Installation and Configuration...

  • Page 65: Redundant Fiber-Optic Link Operation

    The active link always remains enabled (active) until a failure is detected on that link. Redundant Fiber-Optic Link Operation When you initially configure the DECrepeater 90FS for redundant operation, the primary port is the active port and the secondary port is the standby port. In operation, the active port communicates with its remote responder port until the master detects a link failure or until the port is internally partitioned.

  • Page 66: Simple Redundant Link Configuration

    Single pair Port n Port b responder port LKG-8834-94I Once these ports are properly configured using HUBwatch and connected together, one connection is the active link and the other is the standby link. DECrepeater 90FS Installation and Configuration...

  • Page 67: Complex Redundant Link Configuration

    Redundant Fiber-Optic Link Configuration (Cont.) Complex Redundant Link Configuration The DECrepeater 90FS also supports a more complex redundant link topology. In general, the redundant link consists of a pair of master ports on one module, each connected to enabled remote ports. The remote ports must reside on the same LAN (or extended LAN), but can be on separate modules as shown in the following illustration.

  • Page 68: Partial Fault Detection

    – Internally detected MAU failure When the DECrepeater 90FS fiber-optic ports are connected to a non-responder repeater, such as the DECrepeater 90FL, 90FA (as shown in the following illustration), or any IEEE 802.3 10BaseFL repeater port, partial fault detection is available.

  • Page 69: Full Fault Detection

    Redundant Fiber-Optic Link Configuration (Cont.) Full Fault Detection The DECrepeater 90FS supports full fault detection. This feature enables the master module to react to failures at either end of the receive or transmit media. If a failure occurs in the responder’s receive port, the responder signals its partner master port.

  • Page 70: Recommendations For Redundant-Link Configuration

    Detected Failure in Both Detected Detected Recommendations for Redundant-Link Configuration Consider the following recommendations when configuring the DECrepeater 90FS for redundancy to increase fault detection and improve network reliability: • Use responder ports (rather than non-responder ports) whenever possible. •...

  • Page 71: Fiber-Optic Loss Budget

    DECrepeater 90FS. Note the labeling on the fiber-optic cable that is being installed with the DECrepeater 90FS. Cables are tagged according to fiber type (for example, 50/125-, 62.5/125-, 85/125-, or 100/140-micron fiber) and the attenuation of each cable is also characterized and recorded.

  • Page 72: Foirl Compatibility

    –12.0 dBm average for FOIRL and 10BaseFL devices, respectively. When calculating the loss budget for fiber-optic devices, ensure that the higher output from the DECrepeater 90FS, in conjunction with the increased launch power into the two largest fiber sizes (85/125 and 100/140 microns), does not overload the receivers.

  • Page 73: Decrepeater 90Fs Best-Case Maximum Launch Power

    –12.0 –9.8 –6.5 When the DECrepeater 90FS is connected to short lengths of 85/125-micron or 100/140-micron fiber-optic cable, the connection might require additional attenuation to prevent exceeding the –9.0 dBm peak (–12 dBm average) received power level. To make that determination, do the following: 1.

  • Page 74: Product Specifications

    Product Specifications Table 8 provides operating specifications for the DECrepeater 90FS module. Note the additional parameters (listed in the tables) to consider when the module is installed as a standalone unit. Table 8 Operating Specifications Parameter Specification Operating Environment Operating Temperature 5°...

  • Page 75: Acoustical Specifications

    Current values for specific configurations are available from Digital Equipment Corporation representatives. 1 B = 10 dBA. Aktuelle Werte f r spezielle Ausr stungsstufen sind ber die Digital Equipment Vertretungen erhältlich. 1 B = 10 dBA. DECrepeater 90FS Installation and Configuration...

  • Page 76: Associated Documents

    Associated Documents The following documents provide related information about the module. Ordering information is provided at the back of this manual. Title and Order Number Description DEChub 900 MultiSwitch Provides installation, use, security, and Owner’s Manual troubleshooting information for the EK–DH2MS–OM DEChub 900 MultiSwitch.
  • Page 77 Digital’s local subsidiary or approved distributor Internal orders should be placed through U.S. Software Supply Business (SSB), Digital Equipment Corporation, 10 Cotton Rd. Nashua, NH. 03063-1260 *Any prepaid order from Puerto Rico must be placed with the Local Digital Subsidiary:...
  • Page 79 DECrepeater 90FS Installation and Configuration EK-DEFMI-IN. A01 Please return this card. Your comments and suggestions will help us improve the quality and usefulness of our documentation. Did you use the manual as a reference or as a step-by-step procedure to install the device?
  • Page 80 DO NOT CUT – FOLD HERE AND TAPE NO POSTAGE NECESSARY IF MAILED IN THE UNITED STATES BUSINESS REPLY LABEL FIRST CLASS PERMIT NO. 33 MAYNARD MASS. POSTAGE WILL BE PAID BY ADDRESSEE Information Design and Consulting 550 King Street, LKG1–3/L12 Littleton, MA 01460–1289 DO NOT CUT –...
