Congratulations on purchasing Digital's Pro-face GP-377R Series Graphic
Control Panels (hereafter referred to as "the GP").
This GP unit, with its expanded functionality and improved overall perfor-
mance, is an upgrade of Digital's GP70 series panels. Also, instead of using
the optional 2-Port Adapter, the Mitsubishi Electric Corporation's GPP
software package and the GP's rear face tool connector can now be used to
provide 2-Port feature communication.
Please read this manual carefully as it explains, step by step, how to use the
GP correctly and safely.
Also, in this manual's examples, the Mitsubishi MELSEC-AnA Series PLC
is used whenever possible, connected in a one-to-one relationship with a GP.
<Note>
1) It is forbidden to copy the contents of this manual, in whole or in part,
2) The information provided in this manual is subject to change without
3) This manual has been written with care and attention to detail; however,
4) Please be aware that we are not responsible for any damages resulting
5) The GP377R-TC41-24V is UL/c-UL(CSA) approved and CE marked
All Company/Manufacturer names used in this manual are the registered
trademarks of those companies.
© Copyright 1999, Digital Electronics Corporation
GP-377R Series Users Manual
Preface
except for the user's personal use, without the express permission of the
Digital Electronics Corporation of Japan.
notice.
should you find any errors or omissions, please contact Digital Elec-
tronics and inform them of your findings.
from the use of our products, regardless of article 3 above.
unit. However, installing an expansion unit in the GP that is not UL/c-
UL(CSA) approved and CE marked will cause the GP377R-TC41-24V
to lose its UL/c-UL(CSA) approval and CE marking.
i
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Digital Equipment Pro-face GP-377R Series
Summary of Contents for Digital Equipment Pro-face GP-377R Series
- Page 1 Preface Congratulations on purchasing Digital’s Pro-face GP-377R Series Graphic Control Panels (hereafter referred to as "the GP"). This GP unit, with its expanded functionality and improved overall perfor- mance, is an upgrade of Digital's GP70 series panels. Also, instead of using...
-
Page 2: Table Of Contents
Preface Table of Contents Preface....................i Table of Contents ................ii Essential Safety Precautions ............v UL/c-UL(CSA) Approval ..............viii CE Marking ..................viii About GP-377R Series Models ............ix What is IP65f? ................. ix Package Contents ................x Separately Sold Manual ..............x Documentation Conventions ............ -
Page 3: Preface
Preface Chapter 3 Installation and Wiring 3.1 Installation ................3-1 3.1.1 Installation Procedures ............3-1 3.2 Wiring Cautions ..............3-4 3.2.1 Connecting the GP's Power Cord ........... 3-4 3.2.2 Grounding the GP..............3-5 3.2.3 Placement of I/O Signal Lines ..........3-5 3.3 GP Tool Connector .............. - Page 4 Preface Chapter 6 GP RUN Mode and Errors 6.1 GP RUN Mode ..............6-1 6.1.1 After Powering Up the GP ............6-1 6.1.2 Via OFFLINE Mode ..............6-1 6.2 Troubleshooting ..............6-3 6.2.1 Possible Types of Trouble ............6-3 6.2.2 Troubleshooting Checklists ............
-
Page 5: Essential Safety Precautions
Preface Essential Safety Precautions This manual includes procedures that must be followed to operate the GP correctly and safely. Be sure to read this manual and any related materials thoroughly to understand the correct operation and functions of this unit. Usage of Icons To allow you to use the GP correctly, throughout this manual, the following icons are provided next to operations requiring special attention. - Page 6 Preface Caution Installation Precautions • Be sure to use the attachment screws given (included with the GP) to attach an expansion unit to the GP. If the expansion unit is not attached correctly, incorrect GP operation may be caused, or the expansion unit may malfunction or fall off the GP unit.
- Page 7 Preface • Do not allow water, liquids, metal particles, or charged particles to enter inside the GP’s chassis, since they can cause either a GP malfunction or an electrical shock. • Avoid using or storing the GP in direct sunlight, or in excessively dusty or dirty environments.
-
Page 8: Ul/C-Ul(Csa) Approval
Preface UL/c-UL(CSA) Approval The GP377R-TC41-24V unit is a UL/c-UL listed product. (UL file No.E182139) This unit conforms to the following standards: ! ! ! ! ! UL508 Industrial Control Equipment ! ! ! ! ! UL1604 For use with Electrical Equipment in Class I and II, Division 2 and Class III Hazard- ous (Classified) Locations in industrial control applications. -
Page 9: About Gp-377R Series Models
Preface About GP-377R Series Models The GP-377R Series refers to the following GP model numbers: Series Model Name Model Type Comments GP377R-TC11-24V Standard unit *1 GP-377R GP-377RT UL/c-UL (CSA) approved GP377R-TC41-24V and CE marked unit What is IP65f? This unit's protection rating of IP65f is actually a composite code, consisting of the internationally recognized British "Ingress Protection"... -
Page 10: Package Contents
Preface Package Contents The GP's packing box contains the items listed below. Please check to confirm that all items shown below have been included. GP Unit Installation Guide (1) GP377R-TC11-24V GP377R-TC41-24V Installation Guide GP-377R Series Unit Installation fasteners (4/set) This unit has been carefully packed, with special attention to quality. How- ever, should you find anything damaged or missing, please contact your local GP distributor immediately for prompt service. -
Page 11: Documentation Conventions
Preface Documentation Conventions The list below describes the documentation conventions used in this manual. Symbol Meaning Indicates important information or procedures that must be followed for correct and risk-free software/device operation. Indicates procedures that must be followed. Indicates actions that must not be performed. Provides useful or important supplemental information. - Page 12 Preface Memo GP-377R Series Users Manual...
-
Page 13: Chapter 1 Introduction
Chapter 1 Introduction 1. Prior to Operating the GP 2. System Design 3. Optional Items 4. 2-Port Feature Overview Prior to Operating the GP Be sure to follow these steps when creating projects for the GP unit. 1 Preparation Before using the GP, check that all required hardware is present and read all specification, wiring, and installation information. -
Page 14: System Design
Chapter 1 - Introduction System Design The diagrams on the following pages illustrate the peripheral equipment available for the GP unit. Screen Editing Environment GP Unit GP Operating Environment GP377R-TC11-24V CF Card GP377R-TC41-24V GP077-CF10 GP077-CF20 & Ethernet (10BASE-T) Expansion I/F Unit GP377R-MLTE41 Host Controller Printer... - Page 15 Chapter 1 - Introduction GP Interfaces PLC Interfaces Tool Connector RS-232C Port Serial Interface RS-422 Port Expansion I/F Programming Port (GP rear face connector) Personal Computer Interface Printer Interface *1 For range of compatible PCs, refer to the following manual. GP-PRO/PBIII for Windows Operation Manual (included with the screen creation software) *2 GP-PRO/PBIII for Windows Ver.
-
Page 16: Optional Items
Chapter 1 - Introduction Optional Items All optional equipment listed below is produced by the Digital Electronics Co. Screen Editor Software Product Name Model No. Description GP-PRO/PB Ⅲ Ⅲ Ⅲ Ⅲ for GPW-PB01M-V40 <CD-ROM> Software to be used to create the GP's screen data using a personal computer. - Page 17 Chapter 1 - Introduction Expansion Unit Installation Slot Options Product Name Model No. Description This Ethernet interface unit allows the GP to GP377R-MLTE11 save data to a CF Card, or produce printer Multi Unit E output. Screen Protection Options Product Name Model No.
-
Page 18: 2-Port Feature Overview
Chapter 1 - Introduction 2-Port Feature Overview You can now use Mitsubishi’s GPP software (ladder programming software) on your PC while you connect the Mitsubishi PLC to the GP and the GP to your PC. You can send ladder logic data to and from the PLC, via the GP’s Internal 2 port- feature.With the GP377 Series unit, you can use the 2-Port feature by simply connecting the GP and your PC via the data transfer cable (GPW-CB02) without using the external 2-Port Adapter. - Page 19 Chapter 1 - Introduction )*Internal 2-Port Feature Usage Notes • To use the Internal 2-Port feature, you will need to adjust your GP’s settings. For information about these settings, refer to GP-PRO/PBIII for Windows PLC Connection Manual (included with the GP Screen creation software) •...
- Page 20 Chapter 1 - Introduction MEMO GP-377R Series Users Manual...
-
Page 21: Chapter 2 Specifications
Chapter 2 Specifications 1. General Specifications 4. Names and Functions of GP Parts 2. Performance Specifications 5. Graphic Panel Dimensions 3. Interface Specifications General Specifications 2.1.1 Electrical Rated Power DC 24V+ 15% Supply Power 20W or less (Typ: 13W) Consumption Allowable Pause 2ms or less Duration... - Page 22 Chapter 2 - Specifications 2.1.3 Environmental Specifications Ambient Operating C to 40 Temperature Ambient Storage C to 60 Temperature 20%RH to 85%RH Operating Humidity (non-condensation) 10Hz to 25Hz applied in X, Y, and Z directions for Vibration Endurance 30 minutes each - 19.6m/s Noise voltage: 1000 Vp-p Noise Immunity Pulse length: 1 µ...
-
Page 23: Display Features
Chapter 2 - Specifications Features and Performance 2.2.1 Display Features Display TFT type color LCD Medium 64 colors (RGB-4 levels) Display Color CCFL (lifespan = more than 50,000 hours, when continuously lit) Backlight 320 x 240pixels Resolution 115.2mm (W) x 86.4mm (H) Display Area 4 levels (via touch panel) Brightness... -
Page 24: Touch Panel / Clock Accuracy
Chapter 2 - Specifications 2.2.3 Touch Panel / Clock Accuracy 16 x 12 keys/ screen (1 or 2 point touch) Touch Panel ± Clock Accuracy +/- 65 seconds/ month (at room temperature) The GP's internal clock has a slight error. At normal operating temperatures and conditions, with the GP operating from its lithium battery, the degree of error is 65 seconds per month. -
Page 25: Interface Specifications
Chapter 2 - Specifications Interface Specifications 2.3.1 Serial Interface Pin Connection Pin # Signal Name Condition Frame ground Send data (RS-232C) Receive data (RS-232C) Request send (RS-232C) Clear send (RS-232C) No connection Signal ground Carrier detect (RS-232C) TRMX Termination (RS-422) Receive data A (RS-422) Send data A (RS-422) RESERVE... - Page 26 Chapter 2 - Specifications When creating your own cable, follow the instructions listed below: For RS-422 (The following pairs of pin #'s must be connected to each other) ..#18 (CSB) <—> #19 (ERB) ..#21 (CSA) <—> #22 (ERA) •...
-
Page 27: Names And Functions Of Gp Parts
Chapter 2 - Specifications Names and Functions of GP Parts A: Display Panel The GP monitor screen displays the screen setup and corresponding Host (PLC) data. GP377RT TFT type Color LCD B: Touch Panel Performs any screen change operations and sends data to the Host (PLC). -
Page 28: Graphic Panel Dimensions
Chapter 2 - Specifications Graphic Panel Dimensions 2.5.1 GP-377R Series - External Dimensions For detailed dimension information, please contact your local GP distributor. Unit: mm Top View 155.5 Side View Front View Rear View GP-377R Series Users Manual... -
Page 29: Installation Fasteners
Chapter 2 - Specifications 2.5.2 Installation Fasteners Unit: mm Top View Rear View Front View Side View 2.5.3 GP Panel Cut Out Dimensions Unit: mm 4-R3 or less GP-377R Series Users Manual... - Page 30 MEMO...
-
Page 31: Chapter 3 Installation And Wiring
Chapter 3 Installation and Wiring 1. Installation 2. Wiring Cautions 3. GP Tool Connector Installation 3.1.1 Installation Procedures When installing the GP panel, be sure to follow the steps listed below. Before installing the GP into a cabinet or panel, check that the moisture resistant gasket is securely attached to the unit. - Page 32 Chapter 3 - Installation and Wiring • For easier maintenance and operation, plus better ventilation, mount the GP unit at least 100 mm away from adjacent structures and other equipment. • Be sure that the ambient operation temperature is 0 C to 40 C, and the ambient humidity is 20%RH to 85%RH.
- Page 33 Chapter 3 - Installation and Wiring Panel Installation Direction Side View Securing the Installaiton Fasteners ' There are four (4) insertion slots on the top and bottom of the GP, where the metal installation fasteners hook on. Top/Bottom View Panel Front Side Rear Side Installation fastener...
-
Page 34: Wiring Cautions
Chapter 3 - Installation and Wiring Wiring Cautions 3.2.1 Connecting the GP's Power Cord Warning • To avoid electric shocks, be sure the Power Cord is unplugged from the power outlet when con- necting the power terminals to the GP unit. •... -
Page 35: Grounding The Gp
Chapter 3 - Installation and Wiring 3.2.2 Grounding the GP Caution Do not use common grounding, since it may lead to an accident or machine malfunction. • Connect the FG terminal found at (a) Exclusive grounding (BEST) the back of the unit to an exclu- other sive ground. -
Page 36: Gp Tool Connector
Chapter 3 - Installation and Wiring GP Tool Connector The GP's Data Transfer Cable, Memory Loader, or the Bar Code Reader can be attached to the GP's side face Tool Connector. GP Side view Tool Connector • Before unplugging any connector(s) from the GP, be sure the GP's power cord is unplugged from the main power supply. -
Page 37: Chapter 4 Offline Mode
Chapter 4 OFFLINE Mode 1. Entering OFFLINE Mode 4. SELF-DIAGNOSIS—Standard Operation 2. OFFLINE Mode’s Main Menu 5. Transferring Screen Data 3. INITIALIZE—Standard Operation OFFLINE Mode provides access to the Initialize, Self-Diagnosis, and other features built into the GP. You will need to change the GP to OFFLINE mode before you can use any of these features. -
Page 38: From Forced Reset
Chapter 4 - OFFLINE Mode 4.1.2 From Forced Reset From the Forced Reset screen, touch the OFFLINE button and the Main Menu will appear. For instructions on how to enter the Forced Reset Screen 5.4.3 “Set Up Touch Panel; FORCE RESET” When the GP unit has the Device Monitor function, the following display will appear. -
Page 39: Offline Mode's Main Menu
Chapter 4 - OFFLINE Mode OFFLINE Mode's Main Menu Each menu item shown below has different settings that must be set to match the corresponding PLC in order for the GP to communicate properly. Entering OFFLINE mode calls up the following screen. Select the desired menu item by touching the corresponding item bar on the screen selection. -
Page 40: Initialize-Standard Operation
Chapter 4 - OFFLINE Mode INITIALIZE—Standard Operation Selecting A Menu Touch the menu item, or input field to select it. Entering Numbers After selecting an input field by touching it, use the numeric touch keys located at the bottom of the screen to enter numeric values. After inputting each value, touch the [SET] key to define the value. - Page 41 Chapter 4 - OFFLINE Mode After All Setting Data is Entered Touch the top-right [SET] button. If you wish to exit the screen without saving the changes, touch the CAN- CEL button. • Press the [SET] key to write the Setup conditions onto the Internal FEPROM, which may take some time, causing a delay in returning to the previous...
-
Page 42: Self-Diagnosis-Standard Operation
Chapter 4 - OFFLINE Mode SELF-DIAGNOSIS—Standard Operation Selecting a Sub-Display Touch the desired the menu item and that sub-display will appear. [SET], [CANCEL] Keys After selecting the Self Diagnosis item, the [SET], and [CANCEL] keys may appear at different times at the top of the screen. [SET] Key When this key is pressed, your selected Self-Diagnosis test begins. - Page 43 Chapter 4 - OFFLINE Mode After Check—To Return To SELF-DIAGNOSIS MENU When OK displays, Pressing once anywhere on the display screen returns you to the SELF-DIAGNOSIS MENU. When an Error Message displays When an error message appears on the display screen, touch the bottom two corners of the panel (1, 2) to return to the SELF-DIAGNOSIS MENU.
-
Page 44: Transferring Screen Data
Chapter 4 - OFFLINE Mode Transferring Screen Data This section describes the process required to transfer screen data to the GP, and to receive data from the GP. Connect the Data Transfer cable to the GP's tool connector, located on the side face of the GP, and to the PC's serial port. - Page 45 Chapter 4 - OFFLINE Mode Also, please remember that OFFLINE mode is unavailable in a completely new GP until the necessary Screen Data has been transfered from the screen editor software. Therefore, be sure the GP's power cord is plugged in and no images are displayed on the GP screen.
- Page 46 MEMO...
-
Page 47: Chapter 5 Initializing The Gp
Chapter 5 Initializing the GP 1. Initialization Screen 6. INITIALIZE INTERNAL MEMORY 2. Initialization Items 7. SET UP TIME 3. SYSTEM ENVIRONMENT SETUP 8. SET UP SCREEN 4. SET UP I/O 9. FONT SETTING 5. PLC SETUP Initialization Screen Occasionally, you may want to change one or more of the GP unit's general operation settings. -
Page 48: Initialization Items
Chapter 5 - Initializing the GP Initialization Items The contents of the Initialize setup items listed below are explained in this Chapter. To learn about screen operations and numeric input. Chapter 4, "OFFLINE Mode" 1 SYSTEM ENVIRONMENT SETUP System Settings System Area Settings Global Window Settings Character String Data Settings... -
Page 49: System Environment Setup
Chapter 5 - Initializing the GP SYSTEM ENVIRONMENT SETUP GP environment adjustments are made here. The SYSTEM ENVIRON- MENT SETUP includes the SYSTEM SETUP, SYSTEM DATA AREA, GLOBAL WINDOW SETUP, and CHARACTER STRING DATA SETUP. 5.3.1 SYSTEM SETUP STAND-BY MODE TIME (0-255) To protect the GP display screen, the GP is equipped with a screen saver function that automatically erases the screen when no GP operations have occurred for a period of time. -
Page 50: System Area Setup
Chapter 5 - Initializing the GP DATA TYPE OF SCREEN NO. This setup controls whether BIN or BCD format numbers are used when making screen changes. Screen numbers 1~8999 are available when set up in binary format; screen numbers 1~1999 are available when set up in BCD format. - Page 51 Chapter 5 - Initializing the GP ber", "Error Status", "Clock Data When these five items, "Current Screen Num (Current)", "Change Screen Number", and "Display ON/Off", have been se- lected, word addresses are assigned to each item, in order, as shown here. The System DataArea selection process follows this formula [System Data Start Address + n].
-
Page 52: Global Window Setup
Chapter 5 - Initializing the GP 5.3.3 GLOBAL WINDOW SETUP The GP unit can display one Global Window and two Local Windows at any one time. The Global Window is common to all the display screens. The Local Window displays exclusively on the corresponding base screen. The GLOBAL WINDOW SETUP is described here. -
Page 53: Character String Data Setup
Chapter 5 - Initializing the GP 5.3.4 CHARACTER STRING DATA SETUP Character String Data ordering varies from manufacturer to manufacturer. Setup the Character String Data order here to match the corresponding PLC. Setup the CHARACTER STRING DATA MODE to match the PLC type. - Page 54 Chapter 5 - Initializing the GP I) Data Device Storage Order E.g. Characters A B C D E F G H ' " & $ • Storage from Start Data • Storage from End Data D100 D100 " & D101 D101 &...
- Page 55 Chapter 5 - Initializing the GP III) Double-word Word LH/HL Order E.g. Characters "A B C D E F G H I J" " & $ % • 16 bit Device LH Order • 16 bit Device HL Order D100 D100 "...
-
Page 56: Set Up I/O
Chapter 5 - Initializing the GP SET UP I/O This section describes the communication setup with the host PLC and the setup for any peripheral equipment. The SET UP I/O menu includes the SET UP SIO, COMMUNICATION SETUP and SET UP I/O menus. 5.4.1 SET UP SIO This menu runs the settings related to PLC communication. -
Page 57: Communication Setup
Chapter 5 - Initializing the GP 5.4.2 COMMUNICATION SETUP RECEIVE TIMEOUT Sets the value used for the data reception timeout (PLC - GP). If the cable is not connected, data communication will Timeout in one second, regardless of this setting's value. The default is "10" seconds. •... -
Page 58: Set Up Touch Panel
Chapter 5 - Initializing the GP 5.4.3 SET UP TOUCH PANEL Touch operation and Force Reset setup, and Display Device adjustments are made here. TOUCH OPERATION MODE Designates either One Point, Two Point or No Slide. When No Slide is selected, dragging one's finger across the touch screen will elicit no screen response, and only individually selected points will register. - Page 59 Chapter 5 - Initializing the GP CONTRAST SETTING This option is not available with the GP-377RT. BRIGHTNESS SETTING When set to ON, BRIGHTNESS SETTING can be performed via touch input. Press the bottom left corner (2) of the screen while holding down the bottom right corner (1) to enter BRIGHTNESS SETTING mode.
-
Page 60: Plc Setup
Chapter 5 - Initializing the GP PLC SETUP Setup the System Area and the Unit number in this screen. Because 1:1 and n:1 GP connections utilize different settings, confirm your connection's needs before using any settings. The following assumes that the Direct Access format is used. -
Page 61: Station Setup (N:1)
Chapter 5 - Initializing the GP RESET GP ON WRITE ERROR Designates the mode which enables you to cancel the error from the error display when the Write error occurs. 5.5.2 STATION SETUP (n:1) The STATION SETUP, necessary for the n:1 (Multi-link) setup, checks whether correct communications run with the connected GP System configuration. - Page 62 Chapter 5 - Initializing the GP For example, when these 4 GP units—bit 0, bit 2, bit 3, bit 5—are con- nected, 002D (h) is written here. Connection List 002D (h) • Be certain to setup this data before running. •...
-
Page 63: Customize Setup (N:1)
Chapter 5 - Initializing the GP 5.5.3 CUSTOMIZE SETUP (n:1) The Customize function modifies the n:1 (multi-link) connection's commu- nication method to make it more effective. To run communication effi- ciently, the user should first determine whether they wish to have Operation or Display priority set for the GP. - Page 64 Chapter 5 - Initializing the GP • Speed Difference between Display Priority and Operation Priority When using the Mitsubishi Electric Corp. A3A PLC, with a scan time of 20ms with consecutive addresses (80 words not included in the System Area), the difference in reading speed is as shown in the following graphs. GP TOUCH MONOPOLIZE The monopolizing of touch panel use can be set ON or OFF.
-
Page 65: Initialize Internal Memory
Chapter 5 - Initializing the GP INITIALIZE INTERNAL MEMORY This command erases all the GP screen data and initializes the GP's SRAM. • You cannot cancel the Initialization procedure after pressing the Start key. • AIl backed up data in SRAM is lost. •... -
Page 66: Set Up Screen
Chapter 5 - Initializing the GP SET UP SCREEN The initial screen display upon powering up, the character size when in RUN mode, and other general screen items are setup here. INITIAL SCREEN NO. Set up the screen file number that will display first upon powering up. If the BIN option for DATA TYPE OF SCREEN NO in SYSTEM SET UP had been selected, enter a number from 1 to 8999. -
Page 67: Font Setting
Chapter 5 - Initializing the GP FONT SETTING FONT SETTING Select the character font that displays during RUN mode. Available selec- tions are [EUROPE], [JAPAN], [KOREA], [CHINESE] and [TAIWAN- ESE]. KANJI FONT QUALITY When [FONT SETTING] is set to [JAPAN] Full sized characters: [STANDARD] : Full sized 16-dot characters display. - Page 68 MEMO...
-
Page 69: Chapter 6 Gp Run Mode And Errors
Chapter 6 GP RUN Mode and Errors 1. GP RUN Mode 2. Troubleshooting 3. SELF-DIAGNOSIS 4. Error Messages This chapter describes both the GP RUN mode and GP problem solving processes. GP RUN Mode There are two ways of entering the GP's RUN mode; first, immediately after plugging in the unit's power cord, and the other, from the GP's OFFLINE mode. - Page 70 Chapter 6 - GP RUN and Errors • To enter OFFLINE Mode, simply touch the top left corner of the GP's screen within 10 seconds after connecting the GP's power cord. E.g. After powering up the GP, the initial screen that appears is equipped with a built-in (invisible) switch in the top left corner.
-
Page 71: Troubleshooting
Chapter 6 - GP RUN and Errors Troubleshooting This section describes how to find and resolve problems that may occur on the GP. If there is a problem on the PLC side, refer to the corresponding PLC manual. 6.2.1 Possible Types of Trouble Followings are some problems that may occur while using this unit. -
Page 72: Troubleshooting Checklists
Chapter 6 - GP RUN and Errors 6.2.2 Troubleshooting Checklists Follow the flowchart below when the screen does not display when powering up, or the screen turns OFF by itself during RUN mode, to find an appropriate solution. No Screen Display Transfer screen data from the Has data been screen editing software. - Page 73 Chapter 6 - GP RUN and Errors Does turning the power ON one more time start the display? Is the Status LED's Complete orange light turned ON? The back light has burned Are the communication out. Contact your nearest cables connected properly GP distributor for the to the unit? backlight replacement.
- Page 74 Chapter 6 - GP RUN and Errors Erase the data that has been written. When using Direct Access, the address is +9; when using Memory Has Display Off data Link, the address is 12. For more on been written to the SYS- the SYSTEM DATA AREA TEM DATA AREA? PLC Connection...
-
Page 75: No Gp/Host Communication
Chapter 6 - GP RUN and Errors 6.2.3 No GP/Host Communication When the GP will not communicate with the host PLC, follow the flowchart below to find both the cause of the problem and a suitable response. Or, if an error message displays on the screen, check the error code (refer to the Error Messages section in this chapter) to find the appropriate solution. - Page 76 Chapter 6 - GP RUN and Errors Are the corresponding Is the SELF-DIAGNOSIS/ SIO INITIALIZE settings SIO CHECK OK? There is a problem with the GP unit. Please contact your local GP distributor. Enter correct settings and values. Chapter 5, Are all Tags set "Initializing the GP".
-
Page 77: Touch Panel Does Not Respond
Chapter 6 - GP RUN and Errors 6.2.4 Touch Panel Does Not Respond When the touch panel does not respond, or its response time is very slow after it is pressed, please use the flowchart below to find the origin of the problem, and the appropriate solution. -
Page 78: Self-Diagnosis
Chapter 6 - GP RUN and Errors SELF-DIAGNOSIS The GP unit is equipped to check its own System and Interface for any problems. Use it to help diagnose any problems. 6.3.1 GP SELF-DIAGNOSIS Item List DISPLAY PATTERN Checks all the figures and tiling patterns. TOUCH PANEL Checks each GP touch panel square. -
Page 79: Self-Diagnosis - Details
Chapter 6 - GP RUN and Errors 6.3.2 SELF-DIAGNOSIS - Details This section explains the contents of SELF-DIAGNOSIS. For information on how to operate the Screen, Chapter 4, "OFFLINE Mode"; for information about how to set up the Special Tools, Chap- ter 3, "Installation and Wiring". - Page 80 Chapter 6 - GP RUN and Errors TOOL CONNECTOR Use the Tool Connector Control line and Send/Receive line check when the GP cannot send and receive data from the PC. To run the check, connecting a Tool Connector Check Loop Back Cable (Dsub9 pin, pin-side) mounted to the Downloading Cable (provided in the software package) is necessary.
-
Page 81: Error Messages
Chapter 6 - GP RUN and Errors Error Messages This section explains the messages that appear when an error has occurred in the GP unit during RUN mode. The problem causing the error message and its related countermeasure are explained in the table below. After a problem has been solved, unplug the GP's power cord and then reattach it. - Page 82 Chapter 6 - GP RUN and Errors ScreenData is corrupted: Check the screens that have SCREEN MEMORY *nnnn indicates the Screen Number that errors, correct all errors, and DATA IS CORRUPT (nnnn:mmmm) has an error. then transfer the screen data *mmmm indicates the number of screens again.
-
Page 83: Error Message Details
Chapter 6 - GP RUN and Errors 6.4.2 Error Message Details SYSTEM ERROR Indicates a fault in the basic operations of the GP. Following the error message, an error code, as shown below, will appear. Report the error number and details on how the error developed to your local GP distributor. - Page 84 Chapter 6 - GP RUN and Errors When OFFLINE mode displays during RUN mode When the GP changes to OFFLINE mode without the user first pressing the screen, there is a possibility that the screen data has been damaged. In this case, after the SYSTEM ERROR displays, the screen automatically reverts to OFFLINE mode after about 10 seconds.
- Page 85 Chapter 6 - GP RUN and Errors ILLEGAL ADDRESS IN SCREEN DATA Caused by an overlap of addresses. After the error message, error codes, as listed below will appear. If the error cannot be fixed, please report the error code and details on how the error developed to your local GP distributor.
- Page 86 Chapter 6 - GP RUN and Errors PLC COM. ERROR Appears when the address setup for tags exceeds the address range used in the host (PLC.) Check the Error Number that appears and use the following table to solve the problem. PLC COM.
- Page 87 Chapter 6 - GP RUN and Errors • In Toshiba's PROSEC T Series, the Error Code is 4 characters long; on the GP, Error Numbers are changed to and displayed in Hexadecimal. • With the Allen-Bradley PLC-5 and SLC-500 Series, the EXT/STS error codes have been re-mapped to start at D0 HEX, so they will not conflict with other error codes.
- Page 88 Chapter 6 - GP RUN and Errors SCREEN TAG LIMIT EXCEEDED (max. of 384) When tags are setup beyond the tag limit, all tags in excess of #384 will be disabled. Plus, when tags involve registered Windows and loaded screens, they are disabled in this order: Window Registry, Load Screen.
-
Page 89: Chapter 7 Maintenance
Chapter 7 Maintenance 1. Regular Cleaning 2. Periodic Check Points 3. Changing the Backlight Regular Cleaning 7.1.1 Cleaning the Display When the surface or the frame of the display gets dirty, soak a soft cloth in water with a neutral detergent, wring the cloth tightly, and wipe the display. •... - Page 90 Chapter 7 - Maintenance Be sure to insert the packing into the groove so that the long side is Cross Section View vertical. Gasket Groove 2) Insert the gasket into the GP's three remaining corners, as shown in step 1. •...
-
Page 91: Periodic Check Points
Chapter 7 - Maintenance Periodic Check Points To keep your GP unit in its best condition, please inspect the following points periodically. GP Operation Environment ) Is the operating temperature within the allowable range (0 C to 40 C )? ) Is the operating humidity within the specified range (20% RH to 85% RH)? ) Is the operating atmosphere free of any corrosive gasses? Electrical Specifications... -
Page 92: Changing The Backlight
Changing the Backlight GP377RT series unit backlights are not user replaceable. When the backlight burns out, the GP's Status LED (orange lamp) turns ON, and if the "OFFLINE" menu's [USE TOUCH PANEL AFTER BACK- LIGHT BURNOUT] selection is set to [NO], touch-operation is disabled except "Force Reset". -
Page 93: Index
