- Page 1 1464T ISTRUZIONI PER L’USO INSTRUCTIONS FOR USE MODE D’EMPLOI GEBRAUCHSANWEISUNG INSTRUCCIONES INSTRUÇÕES DE USO GEBRUIKSAANWIJZING INSTRUKCJA OBSŁUGI HASZNÁLATI ÚTMUTATÓ...
- Page 2 The result of the measurements is displayed on the 5 inch touch screen. The display will be either numeric or graphic, depending on the test being performed. Item 1464T is fitted with an internal memory, to store the collected data, so that they can later be sent to a computer.
- Page 3 INSTRUCTIONS FOR USE In the next picture you can see that the upper part of the tester accommodates a keypad with the start key and the start and battery charge LED indicators. The upper part of the tester accommodates a start button. Press it briefly to start or turn off the instrument. Once the tester has started, a splash screen with a logo will be displayed.
- Page 4 INSTRUCTIONS FOR USE Compression test A six-bar chart will be displayed in the screens of the compressometer for petrol engines and of the compressome- ter for diesel engines. The six bars can be used to measure up to six cylinders. Pressing the blue button indicating the cylinder number will allow the cylinder that needs to be measured to be selected at any time.
- Page 5 INSTRUCTIONS FOR USE The low pressure circuit basically comprises the following: fuel tank, fuel pump, filter, pressure regulator and pipes. How can the low pressure circuit be tested? Checking the low pressure circuit is relatively easy; the fuel pressure should be checked at certain points of the system.
- Page 6 INSTRUCTIONS FOR USE Test n°. 3 Description: return circuit pressure test. Correct value: 0.7 ÷ 0.8 bar Results of test n°. 3: – Correct pressure: 0.7 ÷ 0.8 bar. Test completed successfully. – Significantly higher pressure: return tube obstructed. Once replaced, if pressure remains high, return valve of high pressure pump is faulty.
- Page 7 MAINTENANCE Maintenance and repair jobs must be carried out by trained personnel. For such jobs, you can contact Beta Utensili S.P.A.’s repair centre. DISPOSAL Under article 13 of Italian Legislative Decree n°. 15 of July 25, 2005, “Implementation of Directives 2002/95/EC, 2002/96/EC and 2003/108/EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment, and the disposal of waste material”, the...
