ZFR1810 Wireless Field Bus Coordinator
Installation Instructions
MS-ZFR1810-x
Application
IMPORTANT: Use the ZFR1810 Wireless Field
Bus Coordinator only to provide an input to
equipment under normal operating conditions.
Where failure or malfunction of the ZFR1810
Coordinator could lead to personal injury or property
damage to the controlled equipment or other
property, additional precautions must be designed
into the control system. Incorporate and maintain
other devices, such as supervisory or alarm systems
or safety or limit controls, intended to warn of or
protect against failure or malfunction of the
ZFR1810 Coordinator.
IMPORTANT: The ZFR1800 Series Wireless Field
Bus System is not designed or intended for use in
mission-critical or life/safety applications.
A ZFR1810 Wireless Field Bus Coordinator provides a
wireless interface between field controllers equipped
with a ZFR1811 Router and a Network Automation
Engine (NAE) 35/45/55 or Network Control Engine
(NCE) 25 supervisory controller. Each wireless mesh
network requires one ZFR1810 Coordinator, which
initiates the formation of the network.
A ZFR1810 Coordinator can operate from either of two
power sources:
• a 24 VAC, Class 2 power source when used with
an NAE55 supervisory controller
• 15 VDC power provided from the FC Bus Jack on
most Field Equipment or Supervisory Controllers
that are connected directly to the FC Bus
The ZFR1810 Coordinator features a remote-mount
antenna and cable to allow transmission when the
ZFR1810 Coordinator is mounted inside a metal panel.
Refer to the ZFR1800 Series Wireless Field Bus
System Technical Bulletin (LIT-12011295) or the
ZFR1800 Series Wireless Field Bus System Quick
Reference Guide (LIT-12011630) for information on
commissioning and configuring a ZFR1800 Series
Wireless Field Bus System for operation.
ZFR1810 Wireless Field Bus Coordinator Installation Instructions
Part No. 24-10325-2, Rev. L
Issued April 2016
