A 96 x 96 mm (DIN) Controller for
Control Valves
Controls motor valves without a potentiometer.
Optimum PID control with feed-forward control
circuitry.
High precision regardless of the set temperature.
Compatible with various inputs (input selected via
internal switch).
Models with communications capabilities also
available.
Ordering Information
Electronic Temperature Controller
Communica-
None
tions
Model
E5AX-PRR
*The Controller can also be equipped with a terminal block to connect communications. Specify a terminal block by adding "-X" to the model
number. Example: E5AX-PRR02-X
**Capable of transmitting the process value or output value, but remote setting by external input is not possible.
Temperature Ranges
Input (switch
selectable)
Chromel vs.
alumel
Range
%C
–200 to 1,300
–300 to 2,300
%F
Resolution (%C/%F)
1
(main settings and
alarm)
Communications Boards
Communications
Model
E53-X01
RS-232C
RS-422*
E5AX-PRR01 E5AX-PRR02 E5AX-PRR03 E5AX-PRR20 E5AX-PRRF
K
J/L
Iron vs.
Copper vs.
constantan
constantan
–100 to 850
–200 to 400
–100 to 1,500
–300 to 700
RS-232C
RS-422
E53-X02
RS-485*
BCD
Thermocouple
T/U
E
Chromel
Platinum vs.
vs.
platinum
constantan
13% rhodium
0 to 600
0 to 1,700
0 to 1,100
0 to 3,000
RS-485
E53-X03
E5AX-P
Transmission
Communications
output*/**
Board Add-on Type
(4 to 20 mA)
E5AX-PRRM
R
S
Platinum vs.
platinum 10%
rhodium
0 to 1,700
0 to 3,000
BCD
Transmission output
(4 to 20 mA)
E53-X20
E53-XF
Temperature
resistance
thermometer
PT platinum
resistance
thermometer
(Pt100/JPt100)
–99.9 to 450.0
–99.9 to 800.0
0.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E5AX-P Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron E5AX-P Series

Summary of Contents for Omron E5AX-P Series

  • Page 1 Temperature Controller E5AX-P A 96 x 96 mm (DIN) Controller for Control Valves Controls motor valves without a potentiometer. Optimum PID control with feed-forward control circuitry. High precision regardless of the set temperature. Compatible with various inputs (input selected via internal switch).
  • Page 2 E5AX-P E5AX-P Specifications Ratings Supply voltage 100 to 240 VAC, 50/60 Hz (either frequency applicable with same unit) Operating voltage range 85% to 110% of rated supply voltage Power consumption Approx. 10 VA (at 100 VAC) to 15 VA (at 240 VAC) Approx.
  • Page 3 E5AX-P E5AX-P Characteristics Setting accuracy (+0.3% of set value or +1%C, whichever greater), +1 digit max. Indication accuracy (+0.3% of set value or +1%C, whichever greater), +1 digit max. (Set value coincides with the indicated value, because no relative error exists between both values.) Disable band 0.1% to 10.0% (in units of 0.1%) Proportional band...
  • Page 4 E5AX-P E5AX-P Nomenclature Process Value (PV) Display Displays the process value, the character for parameter being displayed on the SV display and error messages. Auto-tuning Indicator Flashes on and off every second when auto-tun- ing is taking place. Manual Output Mode In- dicator Lights when in manual Set Value (SV) Display...

  • Page 5: Operating Mode Selector

    E5AX-P E5AX-P sible settings for temperature sensors. Refer to temperature range Operating Mode Selector (SW201, charts under Ordering Information for further information. FUNCTION) The scale displayed (%C or %F) is selected by the operating mode This DIP switch selects the operation modes listed in the following selector (SW201).
  • Page 6 E5AX-P E5AX-P Key Protection Switch (SW101, PROTECT) When the key protection switch is set to the ON position, the Level Key, Up and Down Keys, and Auto-tuning Key cannot be operated. In effect, the Temperature Controller is write-protected and the set values (such as the alarm value) can be read out only. The set point, however, will not be protected if the SP protection disable is turned ON (pin 4 of SW201).
  • Page 7 E5AX-P E5AX-P Motor Calibration: calb The following setting are used to set the opening/closing time for controlling valves. Always set the following parameters when installing the controller. If a display is required for valve position, set the open and close positions at the same time. Down Keys to set the fully open/close time to a value between 1 and 999 s in the units of 1 s.
  • Page 8 E5AX-P E5AX-P Inputting Parameters The Temperature Controller has three display levels, 0, 1, and 2, in which only specific parameters can be set. Level 0 is the initial and is auto- matically entered at power application. To change the mode to set or change a different group of parameters, hold down the Level Key for 2 seconds minimum.
  • Page 9 E5AX-P E5AX-P Alarm: al Level 1 When al is displayed on the PV display, the alarm value for alarm output can be set on the SV display. When the temperature exceeds or falls below the set alarm value, the corresponding alarm output is sl–l produced and the ALM indicator on the front panel lights.
  • Page 10 E5AX-P E5AX-P Lower/Upper Limits of Setting Range: sl–l, sl–h Input Type: in–t When in–t is displayed on the PV display, the present setting of the –200 1,300 input type selector (SW206), is displayed on the SV display. The fol- lowing table shows the messages that may be displayed: Display Sensor SL-L...

  • Page 11: Auto Tuning

    E5AX-P E5AX-P Starting Control Operation The E5AX will start control operations as soon as power is turned on Previous PID New PID constants constants until power is turned off. If you don’t want control operations to be performed while setting parameters, turn off the power and then turn Main setting it back on after setting the desired parameters.
  • Page 12 E5AX-P E5AX-P Dimensions Note: All units are in millimeters unless otherwise indicated. 11 5 Mounting Screw 2 to 10 RS-422 RS-485 4 to 20 mA transmission output Communications connector Communications board Communications board (RS-232C and BCD connector is shown.) (RS-422 and 485 terminals are shown.) (4 to 20 mA transmission output is shown.) Panel Cutout Side-by-side Mounting...

  • Page 13: Connection Examples

    E5AX-P E5AX-P Precautions Mounting Stickers Inside Frontcover The dimensions of the Temperature Controller conform to DIN Stickers indicating the temperature sensor type (R, S, K, J, T, E, L, 43700. Recommended panel thickness is 1 to 8 mm. and U) are supplied with the Temperature Controller. Attach the proper stickers to the front panel as shown below.
  • Page 14 To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527. Cat. No. H54-E1-1A In the interest of product improvement, specifications are subject to change without notice. OMRON Corporation Temperature Control Devices Division 29th Fl., Crystal Tower Bldg.
