Interface adapter USM21A
4

Connecting the interface adapter

4.4 Connecting the interface adapter
Device
®
• MOVIDRIVE B
®
• MOVITRAC B
®
• MOVIFIT MC/FC/SC
®
• MOVIMOT MM..D
®
• MOVISAFE UCS..B
®
• MOVISAFE DCS..B
In preparation:
®
• MOVIGEAR B
• DRC electronic motor
In preparation:
®
• MOVIAXIS
When using an EtherCAT
master without mailbox
gateway function:
®
• MOVIDRIVE modular
with CiA402 device pro-
file
®
• MOVIDRIVE system
with CiA402 device pro-
file
®
MOVIDRIVE technology
®
MOVIGEAR performance
10
Manual – Interface Adapter USM21A
Connecting an engineering PC to a unit via the interface adapter USM21A requires
various connection cables.
A shielded USB connection cable of type USB A‑B, which is included in the delivery, is
required to connect an engineering PC to the interface adapter. SEW‑EURODRIVE
recommends exclusively using the supplied USB connection cable.
It is possible to connect the interface adapter to the following units from
SEW‑EURODRIVE:
Key to the connection cables:
• RJ10 = 2 x RJ10 connectors
• D‑sub = RJ10 connector and 9‑pin D‑sub connector (available as option)
• M12 = Optional design: RJ10 connector and M12 socket (available as option)
Interface
RS485 CAN
X
X
X
®
X
X
X
Connection cable
RJ10 D-sub M12
X
X X
X
X
X
X X
Engineering software
®
MOVITOOLS MotionStudio ver-
sion V6.30 or later
®
MOVITOOLS MotionStudio (in
preparation)
®
MOVITOOLS MotionStudio (in
preparation)
®
MOVISUITE standard SP9 or
later; recommended version:
®
MOVISUITE standard SP9 ser-
vice pack 1, V2.0.114.100 or
later.
®
MOVISUITE standard SP10 or
later
®
MOVISUITE standard SP9 ser-
vice pack 1 V2.0.114.100 or later.
