Summary of Contents for Eurotherm 4103C

  • Page 1 E U ROT H E R M Installation and Operation Manual...
  • Page 3 Dominion Way, Worthing, West Sussex, BN14 8QL, United Kingdom. Product type: Industrial chart recorder Models: 4103C (Status level I11 or higher) 4103M (Status level K12 or higher) Safety specification: EN61010-1: 1993 / A2:1995 EMC emissions specification: EN50081-2 (Group1; Class A)

  • Page 5: Table Of Contents

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 100 mm Chart Recorder Installation and Operation Manual Overall contents list Section Page SAFETY NOTES ................ i - 5 SECTION 1 INSTALLATION ..........1 - 1 1.1 UNPACKING THE RECORDER ..........1 - 1 1.2 INSTALLATION ..............
  • Page 6 100 MM RECORDER INSTALLATION AND OPERATION MANUAL Contents list Cont.) Section Page 2.4.3 Channel configuration ............2 - 6 TEMPERATURE UNITS ............2 - 7 LINEARISATION TYPE ............2 - 7 CJC TYPE ................ 2 - 7 SCALE PAGE ..............2 - 7 VALUE FORMAT ..............
  • Page 7 100 MM RECORDER INSTALLATION AND OPERATION MANUAL Contents list Cont.) Section Page 4.4.5 Print mode ................4 - 8 CYCLICAL MESSAGES ............. 4 - 8 DEMAND MESSAGES ............. 4 - 8 MODES ................4 - 8 4.4.6 Interpolation ................. 4 - 9 4.4.7 Adaptive recording ...............
  • Page 8 100 MM RECORDER INSTALLATION AND OPERATION MANUAL Contents list Cont.) Section Page 4.14 ADJUST................4 - 28 4.14.1 Input adjust ................ 4 - 28 4.14.2 Chart adjust ............... 4 - 29 4.15 DEFAULT CONFIGURATION ..........4 - 30 4.16 CONFIGURATION MENUS SUMMARY ......4 - 31 SECTION 5 REFERENCE ..........

  • Page 9: Safety Notes

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL Safety Notes HA249902 Section i Issue 14 Sep 05 Page i - 5...
  • Page 10 100 MM RECORDER INSTALLATION AND OPERATION MANUAL Static electricity Recorder labelling Refer to the Manual for instructions Protective Earth This recorder for ac supply only This recorder for dc supply only. This recorder for either ac or dc supply Risk of electric shock Section i HA249902 Page i - 6...

  • Page 11: Section 1 Installation

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL SECTION 1 INSTALLATION 1.1 UNPACKING THE RECORDER 1.2 INSTALLATION 1.2.1 Mechanical installation 1.2.2 Electrical installation CONFIGURATION TRANSFER WIRING Recorder 1 Recorder 2 Inner: Terminal transmit Receive Receive Inner Inner Outer: 0 Volts Transmit Transmit Centre Centre...
  • Page 12 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 390 mm (Open long terminal cover) 275 mm (Closed long terminal cover) 236 mm (Short terminal cover) 220 mm 144 mm 200 mm Case clamp Maximum panel Front view thickness = 25 mm 1.75 mm View on right hand side Alternative location...
  • Page 13 100 MM RECORDER INSTALLATION AND OPERATION MANUAL Continuous-trace recorder Multi-point recorder Line input: 90 to 264V (45 to 65 Hz) Line input: 90 to 264V (45 to 65 Hz) OR, if Low voltage option fitted, OR, if Low voltage option fitted, 20 to 53 Vdc or ac (45 to 400 Hz RMS) 20 to 53 Vdc or ac (45 to 400 Hz RMS) Safety cover not shown...

  • Page 14: Chart Installation

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 1.3 CHART INSTALLATION Op:Display Op:Chart ↵ for Chart Off ↵ for Fast Chart Off ↵ for Chart On ↵ ↵ to Park 1.3.1 Z-Fold charts Remove old chart Remove cassette by pulling on the handles Fan new chart Place new chart in paper tray Circular holes...

  • Page 15: Roll Charts

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 1.3.2 Roll Charts Remove cassete by pressing down on, then pulling on the retaining clip. (Multi-point recorder shown - continuous trace type similar). Remove inner tube Insert new chart roll Open cassette top Open cassette top Pull off either end pinion Lift 'ears' to eject take-up...

  • Page 16: Chart Review/Tear Off

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL CHART REVIEW/TEAR OFF First, lift 'ears' to eject chart Then, review chart, and if required, remove section using the tear-off strip 1.4 CHANGING THE PENS/CARTRIDGE 1.4.1 Continuous-trace recorders Pull pen forward 1.4.2 Multipoint recorders Pull cartridge downwards Section 1 HA249902...

  • Page 17: Preventive Maintenance

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 1.5 PREVENTIVE MAINTENANCE 1.5.1 Maintenance schedule 1.5.2 Changing the battery EQUIPMENT REQUIRED ACCESS TO THE BATTERY BOARD Unscrew the jacking bolt A Carefully slide the chassis forwards, ensuring that the flexi cable at the rear of the writing system is not forcibly pulled out of its connector.

  • Page 18: Original Design

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL BATTERY REPLACEMENT ORIGINAL DESIGN Insert the PLASTIC tweezers (or Grasp the battery and pull it out of its other non-conductive tool). holder NEW DESIGN Section 1 HA249902 Page 1 - 8 Issue 14 Sep 05...

  • Page 19: Section 2 Basic Operation

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL SECTION 2 BASIC OPERATION 2.1 POWER UP 09:15 29/02/96 Inst 1 1200 mm/hr 09:15 29/02/96 Inst 1 OFFLINE Channel - in - alarm Current channel's measured value Current channel's number indicators Alarm annunciator Channel Hold Indicator All active alarms have (Use...

  • Page 20: Interpreting The Background Display

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.2 INTERPRETING THE BACKGROUND DISPLAY 2.2.1 Channel number 'dv' 'NN' 2.2.2 Channel value 2.2.3 Channel data display Furnace1 TempA Deg C Deg C Alarms:1^ 2^ Section 2 HA249902 Page 2 - 2 Issue 14 Sep 05...

  • Page 21: Bar Graphs

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.2.4 Bar graphs -100 2.2.5 Alarm indication 2.3 KEY USAGE Scroll-up Alarm acknowledge Scroll-down Cursor T a g Cancel C h a n n e l U n i t s Page Enter Figure 2.3 Recorder keys HA249902 Section 2...

  • Page 22: Key Functions

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.3.1 Key functions Alarm acknowledge Cancel Enter Op:Display Scroll up / down keys Cursor Log Int 0hrs 0mins Log Int 0hrs 0mins Page Section 2 HA249902 Page 2 - 4 Issue 14 Sep 05...

  • Page 23: Configuration Example

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.4 CONFIGURATION EXAMPLE 2.4.1 Channel inputs/outputs 2.4.2 Entering configuration C h a n n e l Op: Display Op:Chart Op:Alarm Summary Op:Channel 1 Alarm 1 Op: Action Op:Clock Op:System Error Op:Configuration Password 00000 HA249902 Section 2 Issue 14 Sep 05...

  • Page 24: Channel Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.4.2 Entering Configuration (Cont.) Password 00000 Password 00000 Password 00000 Password 00000 Password 00010 2.4.3 Channel configuration Conf: Instrument Conf:Chart Conf:Channel 1 Conf:Channel 2 Channel : Range I/P Type Off I/P type T/C I/P Range Lo 0.00 I/P Range Hi...

  • Page 25: Temperature Units

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.4.3 CHANNEL CONFIGURATION (Cont.) Temperature units I/P Units ˚C Lin Type Type B Lin Type Type C Lin Type Type E Linearisation type Lin Type Type J CJC Type Off CJC Type CJC Type Internal Scale page Unscaled Value Format...

  • Page 26: Input Break Response

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.4.3 CHANNEL CONFIGURATION (Cont.) Input Break Response Damping None Brk Rsp None Brk Rsp Drive Hi Offset Offset 0.00 Tag: Channel 1 Tag: Furnace1 tempA Tag: Furnace1 tempA Channel : Range Channel : Alarm 1 Alarm type Channel :Range Alarm : Setpoint...

  • Page 27: Alarm Threshold (Setpoint)

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.4.3 CHANNEL CONFIGURATION (Cont.) Type Absolute High Alarm Threshold (Setpoint) Threshold 0.00 Threshold 780.00 Threshold 780.00 Alarm : Setpoint Alarm : Setpoint Alarm : Job 1 No Action Chart Online Chart speed B Chart span B Ch 1 Chart Span B for All Sound Buzzer...

  • Page 28: Checking That The Trace Is On

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 2.4.3 CHANNEL CONFIGURATION (Cont.) Channel : Trace Checking that the trace is ON Trace Off Trace On Trace On Channel : Trace Conf:Channel 2 Op: Configuration Op:Display d e g m p A F u r n a c e Over range display d e g...

  • Page 29: Section 3 Operator Menus

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL SECTION 3 OPERATOR MENUS 3.1 INTRODUCTION 3.2 TOP LEVEL OPERATOR MENUS Op:Display Op:Chart Op:Alarm Summary Cancel key Op:Alarm setup OP:Action Page key Op:Clock Op:System error Op:Configuration OP:Calibrate chart 3.3 CHART SUBMENU HA249902 Section 3 Issue 14 Sep 05 Page 3 - 1...

  • Page 30: Chart On/Off

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.3 CHART SUBMENU (Cont.) Op:Chart ↵ for Chart Off ↵ for Fast Chart Off Please wait ↵ for Chart On Please wait ↵ to Park Pens fan/Printhead parks ↵ to Advance Chart Chart advances 80 mm. ↵...

  • Page 31: Operator Messages

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.3.2 Operator messages Cursor Enter Field scroll keys (Up and down arrows) Page key to Print Text 1 Enter key 3.3.3 Logs OPERATOR INITIATION to Send Log N JOB INITIATION AUTOMATIC LOGGING HA249902 Section 3 Issue 14 Sep 05 Page 3 - 3...

  • Page 32: Scale Print (Dump Scales)

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.3.4 Scale print (Dump Scales) ↵ Dump Scales 3.4 ALARM SUMMARY PAGE Op:Alarm Summary 3.4.1 Display interpretation Table 3.4.1 3.5 ALARM SETUP PAGE Alarm type symbols Use up/down arrows and cursor to select Op:Channel 1 Alarm1 channel number and alarm number.

  • Page 33: Action

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.6 ACTION 3.7 CLOCK Op:Clock 14:59:20 05/09/05 Figure 3.7 Operator clock display page 3.7.1 Back-up battery TYPICAL USAGE EXAMPLES 3.8 SYSTEM ERROR HA249902 Section 3 Issue 14 Sep 05 Page 3 - 5...

  • Page 34: Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.9 CONFIGURATION Op:Configuration Password 00000 Conf:Instrument To further config pages Figure 3.9 Entry to configuration 3.10 CALIBRATE CHART Multipoint recorder Op:Calibrate Chart Paper zero. Use Paper span adjust Paper zero Paper span. Use adjust Figure 3.10b Zero and span adjustments Figure 3.10a Chart calibration pages...
  • Page 35 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.10 CALIBRATE CHART (Cont.) Continuous pen recorder Op:Calibrate Chart Blue zero. Use Blue span. Use Red zero. Use Red span. Use Green zero. Use Green span. Use Black zero. Use Black span. Use Annot zero.
  • Page 36 100 MM RECORDER INSTALLATION AND OPERATION MANUAL This page is deliberately left blank Section 3 HA249902 Page 3 - 8 Issue 14 Sep 05...

  • Page 37: Operator Menus Summary

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 3.11 OPERATOR MENUS SUMMARY Background Process Variable (PV) display Furnace 1 Temp Deg C Use 'Cancel' key to enter Operator Use 'Page' key to move from page to page. menus Op:Display Use 'Enter' key to enter 'Page', to confirm changes or to return to PV display.
  • Page 38 100 MM RECORDER INSTALLATION AND OPERATION MANUAL This page is deliberately left blank Section 3 HA249902 Page 3 - 10 Issue 14 Sep 05...

  • Page 39: Section 4 Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL SECTION 4 CONFIGURATION 4.1 INTRODUCTION 4.1.1 Password Setting the password to a 00000 sub- sequently allows direct access from the operator menu without further need for a password. 4.1.2 Text entry Character set β...
  • Page 40 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.1 INTRODUCTION (Cont.) Parameter etc. to be edited Configuration page name Where to look Adaptive recording Chart Section 4.4.7 Adjust input Adjust Section 4.14 Alarm Jobs Channel: Alarm: Jobs Section 4.5.2 Alarm Messages (enable/disable) Alarm messages Section 4.9 Alarm Parameters...

  • Page 41: Options

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.1.3 Options 4.1.4 Logs 4.1.5 Jobs HA249902 Section 4 Issue 14 Sep 05 Page 4 - 3...
  • Page 42 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.1.5 JOBS (Cont.) No Action Chart online While Active Chart speed B While Inactive Use cursor and up/down arrow keys to enter channel number (N) Chart Span B Ch While UnAck'ed Chart Span B for All Sound Buzzer Disable all alarms Ack All Alarms...

  • Page 43: Configuration Techniques

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.2 CONFIGURATION TECHNIQUES Conf : Channel 1 Channel : Range Alarm : Setpoint Alarm : Job 1 Channel : Alarm 1 Channel : Trace Enable off Enable Unlatched Use page key to move from parameter to parameter Enable Latched...

  • Page 44: Instrument Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.3 INSTRUMENT CONFIGURATION Conf:Instrument Use Cursor and arrow keys to enter Set Password: 00010 new password. Language: English Scrolls through English, French, German Scrolls through Enabled, Disabled Remote CJ Disabled Use Arrow keys to enter channel number Remote CJ Channel: 1 Scrolls through ˚C, ˚F, K, R Remote CJ units...

  • Page 45: Chart Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.4 CHART CONFIGURATION Conf:Chart Scrolls through Cassette: Roll Roll; Z-fold. Speed A: 1200 mm/hr Use cursor and arrow keys to enter new speeds if required. Speed B: 2400 mm/hr Scrolls through Speed Units:mm/hr mm/hr, in/hr Annotation option required for continuous-trace recorders Use arrow keys to enter...

  • Page 46: Cassette Type

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.4.1 Cassette Type 4.4.2 Chart speeds A and B 4.4.3 Chart speed units 4.4.4 Log intervals A and B 4.4.5 Print mode CYCLICAL MESSAGES DEMAND MESSAGES MODES Section 4 HA249902 Page 4 - 8 Issue 14 Sep 05...

  • Page 47: Interpolation

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.4.5 PRINT MODE (Cont.) 4.4.6 Interpolation Figure 4.4.6 Interpolation 4.4.7 Adaptive recording HA249902 Section 4 Issue 14 Sep 05 Page 4 - 9...

  • Page 48: Pen Offset Compensation Option

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.4.8 Pen offset compensation option W/S Failure 4.4.9 Chart messages disable Section 4 HA249902 Page 4 - 10 Issue 14 Sep 05...

  • Page 49: Channel Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5 CHANNEL CONFIGURATION 4.5.1 Range configuration Conf:Channel 1 Channel : Alarm 1 Channel : Range Channel : Trace Scrolls through T/C, mV, V, mA, RTD, I/P type Off I/P type T/C Ohms, Dig, Comms (if fitted), Test. I/P Range Lo 0.00 Enter low and high input...

  • Page 50: Input Type

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.1 RANGE CONFIGURATION (Cont.) Input type Input Range Shunt Value Ω Input units Linearisation type CJC type Section 4 HA249902 Page 4 - 12 Issue 14 Sep 05...

  • Page 51: Unscaled

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.1 RANGE CONFIGURATION (Cont.) Unscaled Value Format Damping Input Recorder response Damping Break Response Open / Closed __-__ _____ Test Waveforms HA249902 Section 4 Issue 14 Sep 05 Page 4 - 13...

  • Page 52: Alarm Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.2 Alarm configuration Setpoint configuration Use arrow keys to select channel Conf:Channel 1 Use arrow keys to select alarm 1 to 4 Channel : Range Channel : Alarm 1 Channel : Trace Alarm : Job 1 Alarm : Setpoint Scrolls through Enable Off...
  • Page 53 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.2 ALARM CONFIGURATION (Cont.) Latest part of chart Absolute High Absolute Low setpoint setpoint Measured Absolute Low value alarm active Absolute High alarm active setpoint - hysteresis Hysteresis Hysteresis Earliest part of chart setpoint + hysteresis Figure 4.5.2b Absolute alarm definition Reference + Deviation...
  • Page 54 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.2 ALARM CONFIGURATION (Cont.) Latest part of chart Rate of change - rise alarm active Measured value Rate of change - fall Rate of change - fall alarm active alarm active In this example, both rise and fall alarms are triggered at 200 litres per minute Rate of change - rise...

  • Page 55: Alarm Parameters

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.2 ALARM CONFIGURATION (Cont.) Alarm parameters ∆ ∆ Alarm jobs HA249902 Section 4 Issue 14 Sep 05 Page 4 - 17...

  • Page 56: Trace Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.3 Trace configuration Trace Colour Line thickening Span A / Span B Section 4 HA249902 Page 4 - 18 Issue 14 Sep 05...
  • Page 57 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.5.3 TRACE CONFIGURATION (Cont.) Use arrow keys to select channel Conf:Channel 1 Use arrow keys to select alarm 1 to 4 Channel : Range Channel : Alarm 1 Channel : Trace Alarm : Job 1 Alarm : Setpoint Scrolls through Enable Off...

  • Page 58: Log Groups 1, 2

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.6 GROUP CONFIGURATION Conf:Group Display Conf:Group Log 1 01 02 03 04 05 06 01 02 03 04 05 06 Conf:Group DV Option PVs (if fitted) Option PVs (if fitted) Conf:Group Log 2 Include item tag yes Note: DV Group appears only...

  • Page 59: Dv Group

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.6 GROUP CONFIGURATION (Cont.) 4.6.2 DV Group 4.6.3 Display Group 4.7 OPERATOR ACTION CONFIGURATION ↵ Conf:Oper Action Use arrow keys and cursor Label:ACK ALL key to enter text string Latched yes Latched no Figure 4.7 Operator action configuration 4.8 CLOCK CONFIGURATION Conf:Clock...

  • Page 60: Format

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.8 CLOCK CONFIGURATION (Cont.) FORMAT 4.9 MESSAGE CONFIGURATION 4.9.1 Embedded sequences ONE PART SEQUENCES TWO PART SEQUENCES Section 4 HA249902 Page 4 - 22 Issue 14 Sep 05...

  • Page 61: Alarm Messages

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.9.1 EMBEDDED SEQUENCES (Cont.) <TIME><.TA><-PV> <TIME><6.TA><6-PV> 4.10 ALARM MESSAGES Conf:Alarm Messages On/Off Messages no On/Off Message yes Ack Messages no Ack Messages yes 4.10.1 On/Off Messages 4.10.2 Acknowledge messages HA249902 Section 4 Issue 14 Sep 05 Page 4 - 23...

  • Page 62: Internal Events

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.11 INTERNAL EVENTS Ch 4 Event 2 Event Job 1 Event 1 Sound S1.S2 Ch 2 Buzzer S1.S2 4.11.1 Event sources Section 4 HA249902 Page 4 - 24 Issue 14 Sep 05...
  • Page 63 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.11 EVENT CONFIGURATION (Cont.) Use arrow keys to select event Conf:Events 1 number See section 4.1.5 for a list of jobs. Event : Source Event : Job 1 Event Disabled Event Enabled S1 Only S1 And S2 S1 Or S2 S1:No event...

  • Page 64: Configuration Transfer

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.12 CONFIGURATION TRANSFER Conf:Transfer ↵ to Save Config Config Saved ↵ to Restore Config Config Restored Scrolls through 150, 300, 600, Baud rate 150 1200, 2400, 4800, 1800, 9600, 19200. Figure 4.12 Configuration transfer pages. ↵...

  • Page 65: Operator Access

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.13 OPERATOR ACCESS Conf:Access Use Arrow keys to scroll Chart Speed:yes through no, yes Use Arrow keys to scroll Chart On/Offline:yes through no, yes Use Arrow keys to scroll Edit/Print Text:no through yes, no Use Arrow keys to scroll Start Chart log:yes through no, yes...

  • Page 66: Adjust

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.14 ADJUST 4.14.1 Input adjust Conf:Adjust Adjust : Input Adjust : Chart Use arrow/cursor keys to enter range of channels Apply to Ch1..1 Apply known low signal to input(s); Wait for displayed value(s) to stabilise (view other channels using arrow keys) then 'Enter'.

  • Page 67: Chart Adjust

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.14.1 INPUT ADJUST (Cont.) Conf:Adjust Adjust : Input Use up/down/cursor keys to enter relevant channel numbers Remove from ch1..1 View adjust Ch1..1 Apply to Ch1..1 ↵ to Remove Unadjusted Use arrow keys to scroll through Takes a few seconds selected channels.

  • Page 68: Default Configuration

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.15 DEFAULT CONFIGURATION Conf:Default ↵ to default config ↵ Sure? Please wait Chan 1 Units Figure 4.15 Default configuration Section 4 HA249902 Page 4 - 30 Issue 14 Sep 05...

  • Page 69: Configuration Menus Summary

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 4.16 CONFIGURATION MENUS SUMMARY Top level Operator menu Set : OP:Configuration Chart speeds A and B Chart speed units Log interval Password _____ Print mode Interpolation Enter password Adaptive recording Pen offset compensation (option) Resets recorder to Conf:Instrument Chart messages on/off individually...
  • Page 70 100 MM RECORDER INSTALLATION AND OPERATION MANUAL This page is deliberately left blank Section 4 HA249902 Page 4 - 32 Issue 14 Sep 05...

  • Page 71: Section 5 Reference

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL SECTION 5 REFERENCE 5.1 COSHH Product: WATER BASED INKS NOT CONTAINING FORMAMIDE Part numbers: LA248163 LA249556 5.1.1 Printheads LA250280 HAZARDOUS INGREDIENTS Name % Range Toxicological data Acid dye Not available Not established 1 to 4 PHYSICAL DATA 1.05 to 1.1 Specific gravity...

  • Page 72: Pen Inks

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 5.1.2 Pen inks Product: RECORDING PENS Part numbers: LA128964 LA230393 LZ127886 LA125451 LA128965 LA233023 LA234423 LA243770 LA246521 LA249550 LA249550 LZ127887 LA125452 LA128966 LA233461 LA234424 LA243771 LA246522 LA249551 LA249551 LZ127888 LA125453 LA128969 LA233462 LA234425 LA243772 LA246523 LA249552...

  • Page 73: Error Messages

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 5.2 ERROR MESSAGES 5.2.1 Invalid configuration 5.2.2 Failure to adjust channel (Adj fail on ch NN) 5.2.3 Input adjust not available (I/P Adj n/a on ch NN) 5.2.4 Printer must be off line 5.2.5 Writing system failure (W/S failure) HA249902 Section 5...

  • Page 74: Glossary Of Terms

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL 5.3 GLOSSARY OF TERMS input signal list relay output analogue input derived channel pens printhead thermocouple configure process variables memory card communications process vari- able traces job list job list Section 5 HA249902 Page 5 - 4 Issue 14 Sep 05...
  • Page 75 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 5.3 GLOSSARY OF TERMS (Cont.) alarms retransmission input channel derived channel mathemati- cal function job list input signal setpoint alarms Start Alarm without hysteresis Input signal value Al arm off only when value falls below 90. Alarm with hysteresis input signals relay...
  • Page 76 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 5.3 GLOSSARY OF TERMS (Cont.) Maths functions (Cont.) Constant Square root Log base 10 Latching maximum Switch Copy Channel average Rate of change Continuous maximum High select Group average Sample and hold Polynomial Low select Subtract Rolling average...
  • Page 77 100 MM RECORDER INSTALLATION AND OPERATION MANUAL 5.3 GLOSSARY OF TERMS (Cont.) alarm hysteresis Ω process variable linearisation tables job lists thermocouples resistance ther- mometers (RTDs) pens/printheads HA249902 Section 5 Issue 14 Sep 05 Page 5 - 7...
  • Page 78 100 MM RECORDER INSTALLATION AND OPERATION MANUAL This page is deliberately left blank Section 5 HA249902 Page 5 - 8 Issue 14 Sep 05...

  • Page 79: Annex A Technical Specification

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL ANNEX A TECHNICAL SPECIFICATION INSTALLATION CATEGORY AND POLLUTION DEGREE HA249902 Annex A Issue 14 Sep 05 Page A - 1...

  • Page 80: A1 Technical Specification (Recorder)

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL A1 TECHNICAL SPECIFICATION (Recorder) Board types (I/O) Universal input board (standard) 3-Changeover relay output board (optional) 4 Normally open relay output board (optional) 4 Normally closed relay output board (optional) 2 channel analogue output (retransmision) board (optional) Options (See options manual) Host Communications Memory Card...

  • Page 81: A2 Technical Specification (Input Board)

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL A1 TECHNICAL SPECIFICATION (Recorder) (Cont.) Electromagnetic compatibility (EMC) Emissions: BS EN50081-2 Immunity: BS EN50082-2 Electrical safety BS EN61010. Installation category ; Pollution degree Paper transport Type Stepper motor driving sprocket tube Chart speeds Continuous: 0 to 36,000 mm/hr (0 to 1417 in/hr) (Annotation inhibited at speeds >900 mm/hr;...
  • Page 82 -50 to + 170 DIN43760:1987 0.01 ˚C Pt100 -200 to + 850 IEC 751 0.01 ˚C Pt100A -200 to + 600 Eurotherm Recorders SA 0.09 ˚C Pt1000 -200 to + 850 IEC 751 0.01 ˚C Annex A HA249902 Page A - 4...

  • Page 83: Index

    100 MM RECORDER INSTALLATION AND OPERATION MANUAL Index C (Cont.) Channel (Cont.) Absolute alarms ............. 4 - 15 Line thickening ........... 4 - 18 Adaptive recording ........... 4 - 9 Linearisation types ..........4 - 12 Adjust Nº of decimal places .......... 4 - 13 Backlash ............
  • Page 84 100 MM RECORDER INSTALLATION AND OPERATION MANUAL Jack plug wiring ............1 - 1 Damping ..............4 - 13 Jobs ............. 4 - 3 to 4 - 4 Date Format ..............4 - 21 Setting ..............4 - 21 View ..............3 - 5 Key usage ..........
  • Page 85 100 MM RECORDER INSTALLATION AND OPERATION MANUAL P (Cont.) Safety notes ............... i - 5 Offset compensation .......... 4 - 10 Scaling ..............4 - 13 Park ..............1 - 4 Shunt value entry ........... 4 - 12 Replacement ............1 - 6 Span setting ............
  • Page 86 100 MM RECORDER INSTALLATION AND OPERATION MANUAL This page is deliberately left blank HA249902 Index Page i - 4 Issue 14 Sep 05...
