Instructions for use
Refrigerator
R2684SR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R2684SR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asko R2684SR

Summary of Contents for Asko R2684SR

  • Page 1 Instructions for use Refrigerator R2684SR...
  • Page 2 We thank you for the confidence you have shown by purchasing our appliance. We wish you find a lot of pleasure in its use. The appliance is intended solely for household use. The refrigerator is intended for storing fresh food at temperatures above 0°C.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND PRECAUTIONS 10 ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE 11 APPLIANCE DESCRIPTION DESCRIPTION 12 INSTALLATION AND CONNECTION 14 CHANGING THE DIRECTION OF DOOR OPENING 16 OPERATING THE APPLIANCE 19 APPLIANCE INTERIOR EQUIPMENT 23 RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE STORING AND 24 STORING FOOD IN THE REFRIGERATOR...

  • Page 4: Important Notes And Precautions

    IMPORTANT NOTES AND PRECAUTIONS BEFORE USING THE APPLIANCE FOR THE FIRST TIME Before connecting the appliance to the power mains, please read carefully the instructions for use which describe the appliance and its correct and safe use. The instructions apply to several appliance types/models; thus, settings or equipment may be described herein which is not available in your appliance.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING! Risk of fire/flammable materials. The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations. WARNING! Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Before cleaning the appliance, unplug it from the power mains (unplug the power cord from the wall outlet).
  • Page 6 Danger of frostbite Never put frozen food in your mouth and avoid touching frozen food as this may cause frostnip or frostbite. Safety of children and vulnerable persons The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 7 Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances. Warning regarding the refrigerant The appliance contains a small amount of an environmentally friendly yet flammable gas R600a. Make sure that no parts of the cooling system are damaged. A gas leak is not hazardous to the environment, but it could cause eye injury or fire.
  • Page 8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE WARNING! This appliance is intended to be used in household and similar applications such as: – staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments;...
  • Page 9 Technical information on the appliance Rating plate can be found in the appliance interior. It indicates data on voltage, gross and net volume, type and amount of refrigerant, and information on the climate classes. If the language on the rating plate is not the language of your choice or the language of your country, replace it with the one supplied.

  • Page 10: Advice For Saving Power With Refrigeration Appliances

    ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance).

  • Page 11: Appliance Description

    APPLIANCE DESCRIPTION Control unit 2 LED lighting of refrigerator interior 3 Fan with air ionizer (+ on/off switch) 4 Pull-out glass shelf (heightadjustable) 5 FreshZone 6 Fruit and vegetable bin (CrispZone) with humidity control 7 Fruit and vegetables drawer 8 Height-adjustable door bin 9 Bottle shelf •...

  • Page 12: Installation And Connection

    INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Class Temperature from +10°C to +32°C...
  • Page 13 • Do not expose the appliance to direct sunlight and do not place it near any source of heat. If this cannot be avoided, install an insulation panel. • The appliance may stand alone or it may be placed ext to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram).

  • Page 14: Changing The Direction Of Door Opening

    CHANGING THE DIRECTION OF DOOR OPENING Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, flat screwdriver The procedure to change the direction of door opening should be carried out by at least two persons. 1. Remove the upper hinge cover (A) and the covering cap (G). 2.

  • Page 16: Operating The Appliance

    OPERATING THE APPLIANCE A On/off key B Acoustic alarm off key C Cooling boost on/off key D Refrigerator temperature keys E Refrigerator temperature display G ECO function on/off key SWITCHING THE APPLIANCE ON/OFF Switching the appliance on: Switch on the appliance by briefly pressing the A key.
  • Page 17 ADJUSTING THE TEMPERATURE IN THE APPLIANCE • Us the D keys to set the temperature. lower temperature ; higher temperature. • Refrigerator compartment temperature can be set in the range from +1°C to 9°C. • After one of the D keys is pressed, the most recent temperature setting will fl...
  • Page 18 HIGH TEMPERATURE ALARM If the temperature inside the appliance is too high, acoustic alarm will be activated (intermittent tone) and the B key will flash. • Acknowledge and turn off the acoustic alarm by pressing the B key. • The acoustic alarm will be activated every 24 hours if the temperature in the appliance is not low enough and there is danger of food spoilage.

  • Page 19: Appliance Interior Equipment

    APPLIANCE INTERIOR EQUIPMENT (* Equipment depends on the model) SHELF • For easier access to food and clarity, the shelves can be partly pulled out. • The shelves may be adjusted tu suit your preferences using the guides in the refrigerator interior.
  • Page 20 CRISPZONE – FRUIT AND VEGETABLE BIN WITH HUMIDITY CONTROL • The bin at the bottom of the refrigerator is intended for storing fruit and vegetables. It provides humidity and prevents the food from drying out. • Store the food in suitable packaging to prevent them from emitting or taking on odours. The bin has integrated humidity regulator which allows setting the humidity according to the amount of food stored.
  • Page 21 STORAGE BIN (MULTIBOX)* • MultiBox bin offers a convenient way for storing food with a strong or pungent smell, e.g. ripened or blue-vein cheese, sausages, onions, butter etc. • The silicone lid provides an air-tight seal that prevents the food from drying out and the odour to spread throughout the refrigerator compartment.
  • Page 22 Switching the ionizer on/off OFF = When the ionizer is switched on, a red dot will be visible on the switch. ADAPTIVE INTELLIGENT TECHNOLOGY Innovative sensor technology allows adjusting appliance operation to the user's habits or behaviour. Adaptive intelligent system monitors, analyzes, and records on a daily and weekly basis the use of appliance and adapts appliance operation to the perceived patterns.

  • Page 23: Recommended Distribution Of Food In The Appliance

    RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE Sections of the refrigerator: - upper part: canned food, bread, wine, pastry etc. - middle part: dairy products, ready-made meals, desserts, soft drinks, beer, cooked food, etc. - Fresh bin: - meat, meat produce, delicatessen; - Fruit and vegetable bin: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips etc.

  • Page 24: Storing Food In The Refrigerator

    STORING FOOD IN THE REFRIGERATOR IMPORTANT WARNINGS REGARDING FOOD STORAGE Correct use of the appliance, appropriate packaging, maintaining the right temperature, and observing the food hygiene standards has a decisive impact on the quality of food storage. Observe the expiry dates for the food, specified on the packaging.
  • Page 25 FOOD STORAGE TIMES Recommended storage time in the refrigerator Type of food Time eggs, marinades, smoked meat up to 10 days cheese up to 10 days root vegetables up to 8 days butter up to 7 days deserts, fruit, ready-to-eat food, chunks of raw up to 2 days meat fish, raw minced meat, seafood...

  • Page 26: Storing Food In The Freshzone Drawer

    STORING FOOD IN THE FRESHZONE DRAWER In the FreshZone compartment, food stays fresh longer than in a conventional refrigerator, retaining more flavour and nutrients. Decay and loss of mass are slowed down; therefore, fruit and vegetables remain fresh and natural longer. For optimum performance, the drawer should be fully closed.

  • Page 27: Defrosting The Appliance

    DEFROSTING THE APPLIANCE AUTOMATIC REFRIGERATOR DEFROSTING Refrigerator does not need defrosting because the ice on the back interior wall is thawed automatically. Any accumulated ice will melt when the compressor unit is inactive. Drops will flow through an opening in the refrigerator rear wall into a tray fitted above the compressor, from where they will evaporate.

  • Page 28: Cleaning The Appliance

    CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface.

  • Page 29: Troubleshooting

    TROUBLESHOOTING Problem: Cause or remedy: Appliance is connected • Make sure there is voltage in the power outlet and that to the power mains but it the appliance is switched on. does not work. Cooling system operates • Too high environment temperature. continuously for a long •...
  • Page 30 Problem: Cause or remedy: Door is difficult to open: • If you are trying to open the appliance door after just having closed it, this could be difficult to do. As you open the door, some cool air escapes from the appliance and it is replaced by warm air from the environment.

  • Page 31: Information About Appliance Noise

    WE RESERVE THE RIGHT TO MAKE CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.asko.com...
  • Page 32 en (08-19)
