Summary of Contents for Rice Lake DeviceNet Series

  • Page 1 DeviceNet ™ Interface for 520, 720i , 820i and 920i Indicators ® ® ® Installation and Programming Manual 69949 Rev A...
  • Page 3: Table Of Contents

    Course descriptions and dates can be viewed at www.ricelake.com/training or obtained by calling 715-234-9171 and asking for the training department. © Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America. Specifications subject to change without notice.
  • Page 4 Get Register ..............13 DeviceNet Interface Specifications................... 14 DeviceNet Interface Limited Warranty ....................15 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars. 520/720i/820i/920i DeviceNet Installation and Programming Manual...
  • Page 5: About This Manual

    About This Manual This manual provides information needed to install and The DeviceNet Interface is installed inside the use the Rice Lake Weighing Systems DeviceNet indicator enclosure. Installation in NEMA 4X stainless Interface. The DeviceNet Interface allows 520, s t e e l e n c l o s u r e s p e r m i t s u s e i n w a s h d o w n 720i ®...
  • Page 6: Installation

    Installation The DeviceNet Interface hardware consists of a dual-board option card. DeviceNet-specific functions are provided by a DeviceNet module, which is factory-installed onto a bus adapter card. The bus adapter card plugs into an open option card slot on the 520, 820i, or 920i CPU board (or expansion board) and provides power and access from the indicator bus to the DeviceNet module.
  • Page 7: Installing Devicenet Option In The 520

    10. Reconnect power to the indicator. The 3. Carefully align the large option card connector indicator automatically recognizes all installed with connector J2 on the CPU board (see option cards when the unit is powered on. No Figure 2-5). Press to seat the option card down hardware-specific configuration is required to...
  • Page 8: Devicenet Network Connections

    DeviceNet Network Connections DIP Switch Configuration Feed DeviceNet network cable through cord grip. A DIP switch is used to configure the DeviceNet Allow enough cable for routing along inside of network baud rate and node address. Figure 2-7 shows enclosure to connector on the DeviceNet module. the DIP switch assignments.
  • Page 9 Node Node Addre Addre Switch Settings (MSB—>LSB) Switch Settings (MSB—>LSB) Decim Decim Octal Octal Table 2-3. Switch Settings for DeviceNet Interface Node Address Installation...
  • Page 10: Led Status Indicators

    LED Status Indicators A single bi-color LED on the surface of the DeviceNet module provides diagnostic information for debugging An LED array on the DeviceNet module provides the module itself. Table 2-5 lists the indications status information for troubleshooting. LED 2 provides provided by the debugging LED.
  • Page 11: Commands

    Commands Commands are used by the DeviceNet master device to Decimal Command send and receive data from the DeviceNet Interface as 0x00D Acquire Tare integer or floating-point data. The master sends eight 0x00E Clear Tare bytes in the output format (used to write commands to the indicator) and reads eight bytes in the input format 0x010 Primary Units...
  • Page 12: Parameter Value

    Status Data Decimal Command Indicator status data is returned in the second word (see 0x133 Set Setpoint Preact (float) Table 3-4). Batch commands return batch status in 0x140 Read Setpoint Value (float) place of the low byte (see Table 3-5). Setpoint commands return batch status in the low byte of the 0x141 Read Setpoint Hysteresis (float)
  • Page 13: Return Status And Current Weight As Integer

    Display Tare weight and status data for the specified scale. Command: 11, 0x00B Return Status and Current Weight as Integer Parameter: Scale number Command: 0, 0x000 Command 11 causes the tare weight on the specified Parameter: Scale number scale to be displayed. If a scale number other than 0 is Command 0 returns the status and weight of the specified, the indicator first causes the specified scale specified scale in integer format, without changing the...
  • Page 14: Units Key Press (Toggle Units)

    Units Key Press (toggle units) Return Tare as Integer Command: 19, 0x013 Command: 34, 0x022 Parameter: Scale number Parameter: Scale number Command 19 toggles the current format of the Command 34 returns the tare weight value for the specified scale to the next units configured for that specified scale as an integer.
  • Page 15: Batch Start

    Batch Start Set Digital Output OFF Command: 96, 0x060 Command: 115, 0x073 Parameter: Scale number Parameter: Slot number Value: Bit number Command 96 starts a batch program from the current step after a stop, pause, or reset. Batch status is Command 115 sets the specified digital output OFF returned with the current weight for the specified scale.
  • Page 16: Read Net Weight As Float

    Read Peak Value as Float Command 288 returns the gross weight value for the specified scale in floating-point format. Command: 296, 0x128 Parameter: Scale number Read Net Weight as Float Command 296 returns the net peak value for the Command: 289, 0x121 specified scale in floating-point format.
  • Page 17: Read Setpoint Hysteresis As Float

    Read Setpoint Hysteresis as Float Command: 321, 0x141 Parameter: Setpoint number Command 321 returns the hysteresis value for the specified setpoint in floating-point format. This command is only valid if the setpoint is enabled and requires a hysteresis value. Read Setpoint Bandwidth as Float Command: 322, 0x142 Parameter: Setpoint number Command 322 returns the bandwidth value for the...
  • Page 18: Devicenet Interface Specifications

    DeviceNet Interface Specifications Power Requirements Communications Specifications Bus Adapter Card with DeviceNet Module, DC Power: DeviceNet Network Communications: 820i 920i Twisted-pair cabling at 125, 250, or 500 Kbps Supply voltage: 6 VDC, supplied by Typical current draw: 270 mA Update rate is dependent on the configured baud rate and the Power consumption: 1.62 W number of network nodes.
  • Page 19: Devicenet Interface Limited Warranty

    DeviceNet Interface Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for one year.
  • Page 20 520/820i/920i DeviceNet Installation and Programming Manual...
  • Page 21 Rice Lake Weighing Systems August 7, 2013 PN 69949 Rev A...
