  • Page 1 ™ Interface for 520 and 920i Indicators ™ Installation and Programming Manual 88537...
  • Page 3: Table Of Contents

    4.3 EtherNet/IP Interface Specifications ..........16 EtherNet/IP Interface Limited Warranty ....................17 © 2006 Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America. Specifications subject to change without notice.
  • Page 4 520/920i EtherNet/IP Installation and Programming Manual...
  • Page 5: About This Manual

    Authorized distributors and their Installation Manual for additional installation employees can view or download this information and detailed descriptions of indicator manual from the Rice Lake Weighing functions. Systems distributor site at www.rlws.com 1. EtherNet/IP™ is a trademark of ControlNet International, Ltd.
  • Page 6: Installation

    Installation The EtherNet/IP Interface hardware consists of a dual-board option card. EtherNet/IP-specific functions are provided by a EtherNet/IP module, which is factory-installed onto a bus adapter card. The bus adapter card plugs into an open option card slot on the 920i CPU board (or expansion board) and provides power and access from the indicator bus to...
  • Page 7: Installing Ethernet/Ip Option In The 520

    LED Array TE T DIP witch EtherNet/IP Module Figure 2-4. Option Installed 520 CPU Board 6. Remove existing cover plate. RJ-45 7. Re-use kep nuts to secure EtherNet/IP cover Connector plate to standoffs located on inside of enclosure backplate (see Figure 2-5). 8.
  • Page 8: Ethernet/Ip Network Connections

    EtherNet/IP Network Connections LED 2: Module Status LED 2 can be set to any of four configuration states, Feed the EtherNet/IP network cable through the 1–4, as described in the following tables. indicator cord grip. Allow enough cable for routing deactivates LED 2.
  • Page 9 LED 3: Network Status Watchdog LED LED 3 can be set to configuration states 1–3. In A s ingle bi-color LED on the surfa ce of the , LED 3 flashes the number of EtherNet/IP module provides diagnostic information c o n f i g u r a t i o n 1 e s t a b l i s h e d c o n n e c t i o n s t o t h e m o d u l e ;...
  • Page 10: Commands

    Commands Commands are used by the EtherNet/IP master device Decimal Command to send and receive data from the EtherNet/IP Enter Tare 0x00C Interface as integer or floating-point data. The master sends eight bytes in the output format (used to write 0x00D Acquire Tare commands to the indicator) and reads eight bytes in...
  • Page 11: Input Command Format

    Status Data Decimal Command Indicator status data is returned in the second word 0x128 Read Peak (float) (see Table 3-4). Batch commands return batch status in place of the low byte (see Table 3-5). Setpoint 0x130 Set Setpoint Value (float) commands return batch status in the low byte of the 0x131 Set Setpoint Hysteresis (float)
  • Page 12: Command Descriptions

    Command Descriptions Command 11 causes the tare weight on the specified scale to be displayed. If a scale number other than 0 is NOTE: For all commands that require a scale number, a value specified, the indicator first causes the specified scale of 0 indicates the current scale.
  • Page 13 Print Request Parameter: Scale number Command: 20, 0x014 Command 37 returns the weight value for the Parameter: Scale number specified scale as currently displayed. This may Command 20 causes the indicator to execute a print include gross, net, tare, piece count, or accumulator command for the current scale.
  • Page 14 Batch Start Set Digital Output OFF Command: 96, 0x060 Command: 115, 0x073 Parameter: Scale number Parameter: Slot number Command 96 starts a batch program from the current Value: Bit number step after a stop, pause, or reset. Batch status is Command 115 sets the specified digital output OFF returned with the current weight for the specified (inactive).
  • Page 15 Read Gross Weight as Float Set Setpoint Value as Float Command: 288, 0x120 Command: 304, 0x130 Parameter: Scale number Parameter: Setpoint number Command 288 returns the gross weight value for the Value: Target value specified scale in floating-point format. Command 304 sets the target value for the specified setpoint in floating-point format.
  • Page 16 Command 322 returns the bandwidth value for the specified setpoint in floating-point format. This command is only valid if the setpoint is enabled and requires a bandwidth value. Read Setpoint Preact as Float Command: 323, 0x143 Parameter: Setpoint number Command 323 returns the preact value for the specified setpoint in floating-point format.
  • Page 17: Appendix

    Appendix Configuration Procedure for 920i and PLC The following steps describe a typical procedure used to configure EtherNet/IP for a 920i controller and a PLC. ™ This example uses the CompactLogix L32E controller with RSLogix 5000 software, both from Rockwell ®...
  • Page 18 Input_1 Control Bits <Local:1:I.Data.0> B_Bit1 Control Bits SWPB B_Bit1 Swap Byte Source RLWS_EthernetIP:I.Data(0) 8192 Order Mode HIGH/LOW Dest DevNetIn1 SWPB Swap Byte Source RLWS_EthernetIP:I.Data(1) 3329 Order Mode HIGH/LOW Dest DevNetIn2 SWPB Swap Byte Source RLWS_EthernetIP:I.Data(2) Order Mode HIGH/LOW Dest DevNetIn3 SWPB Swap Byte Source...
  • Page 19: Eds File

    EDS File The EDS file for the EtherNet/IP adapter, shown below, is included on the CD that comes with the option. The EDS file must be installed in the host device to enable communication with the indicator. [File] DescText = "HMS AnyBus-Communicator EtherNet/IP"; CreateDate = 04-02-2003;...
  • Page 20: Ethernet/Ip Interface Specifications

    17 = change of state (0 = not supported) 18 = on demand (0 = not supported) 19-23 = reserved (must be zero) 24-27 = exclusive owner 28-30 = reserved (must be zero) 31 = client 0 (don't care for classes 0 and 1) 0x44240405, $ point/multicast &...
  • Page 21: Ethernet/Ip Interface Limited Warranty

    EtherNet/IP Interface Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for one year.
