SECTION 12 - TECHNICAL SPECIFICATIONS
Conversion
DSP
Sample Rate
Input Impedance
SNR
Frequency Response
Max Input Level
Power
Bypass
Dimensions
Weight
Federal Communications Commission Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment requires shielded interface cables in order to meet FCC class B limit.
Any unauthorized changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
24 bit A/D and D/A
32 bit floating point
48000 Hz
1 Meg Ohm
110dB typical
20Hz-20kHz
+9 dBu (instrument level setting)
+12.5 dBu (line/synth level setting)
9V DC center-negative, 150mA, 2.1mm jack
Selectable True Bypass (Relay) or Analog Buffered Bypass
4.25" wide, 4.5" long, 2" tall
14.6 ounces
