Installation Instructions for
*MES80 Ultra Low NOx Gas Furnace -
CATEGORY I CATÉGORIE I
These furnaces comply with requirements embodied in the
American National Standard/National Standard of Canada
ANSI Z21.47·CSA-2.3 Gas Fired Central Furnaces.
Only personnel that have been trained to install, adjust, service
or repair (hereinafter, "service") the equipment specified in
this manual should service the equipment. The manufacturer
will not be responsible for any injury or property damage
arising from improper service or service procedures. If you
service this unit, you assume responsibility for any injury or
property damage which may result. In addition, in jurisdictions
that require one or more licenses to service the equipment
specified in this manual, only licensed personnel should service
the equipment. Improper installation, adjustment, servicing or
repair of the equipment specified in this manual, or attempting
to install, adjust, service or repair the equipment specified in
this manual without proper training may result in product
damage, property damage, personal injury or death.
PROP 65 WARNING
FOR CALIFORNIA CONSUMERS
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
R
ECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION
NOTE: Please contact your distributor or our website listed below
for the applicable Specification Sheet referred to in this manual.
IOG-2019B
10/2019
Installer: Affix all manuals
adjacent to the unit.
-
0140M00517-A
5151 San Felipe Suite 500 • Houston, TX 77056
www.goodmanmfg.com • www.amana-hac.com
© 2019 Goodman Manufacturing Company, L.P.
is a registered trademark of Maytag Corporation or its related companies and is used under license. All rights reserved.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS ....................................................... 3
Additional Safety Considerations ...................................... 5
Shipping Inspection ........................................................... 5
Electrostatic Discharge (ESD) Precautions ......................... 6
To The Installer .................................................................. 6
PRODUCT APPLICATION ........................................................... 6
LOCATION REQUIREMENTS AND CONSIDERATIONS ................ 7
Clearances and Accessibility.............................................. 8
Installation Positions ......................................................... 8
Venting For Horizontal Left Or Right Installations ............. 8
Horizontal Installation ....................................................... 8
Furnace Suspension .......................................................... 9
Existing Furnace Removal .................................................. 9
Thermostat Location ....................................................... 10
COMBUSTION AND VENTILATION AIR REQUIREMENTS ........ 10
CATEGORY I VENTING (VERTICAL VENTING) .......................... 10
Checklist Summary .......................................................... 11
Check 1 - Proper chimney termination........................... 11
Vented into this Chimney Channel ................... 12
Check 3 - Chimney Crown Condition .............................. 12
Check 4 - Debris in Cleanout ........................................... 12
Check 5 - Liner Condition ................................................ 12
Check 6 - Dilution Air ...................................................... 13
Check 7 - Complete the Installation ............................... 13
Fix 1 - Liner Termination .................................................. 13
Fix 2 -Change Venting Arrangements .............................. 13
Fix 3 - Rebuild the Crown ................................................ 13
Fix 4 - Relining ................................................................. 13
ATTENTION INSTALLING PERSONNEL
As a professional installer, you have an obligation to know
the product better than the customer. This includes all safety
precautions and related items.
Prior to actual installation, thoroughly familiarize yourself
with this Instruction Manual. Pay special attention to all
safety warnings. Often during installation or repair, it is
possible to place yourself in a position which is more
hazardous than when the unit is in operation.
Remember, it is your responsibility to install the product
safely and to know it well enough to be able to instruct a
customer in its safe use.
Safety is a matter of common sense...a matter of thinking
before acting. Most dealers have a list of specific, good
safety practices...follow them.
The precautions listed in this Installation Manual are
intended as supplemental to existing practices. However,
if there is a direct conflict between existing practices and
the content of this manual, the precautions listed here take
precedence.
