Magnacoustics Genesis ULTRA Installation And Operation Manual

Communication / music system
Hide thumbs Also See for Genesis ULTRA:

Advertisement

Table of Contents

See also: Installation Manual
Communication / Music System
Installation and Operation Manual
Important Safety Instructions: ...................................... 2
System Notes & Preventive Maintenance: ...................... 3
Troubleshooting Guide................................................ 4 & 5
Technologist Control Unit Operation: ............................. 8, 9 &10
Pre-Installation & System Parts List: ............................. 11
Genesis ULTRA Installation and Connections: ................ 12,13,14&15
Rear Panel: ............................................................. 16
Component Locations and Wiring Pictorial: ...................... 17
QR 127
Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA)



Genesis ULTRA

Table of Contents

Magnacoustics Inc.
1995 Park Street
Atlantic Beach NY 11509
1 |
Appendix A page 18
rev-t

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genesis ULTRA and is the answer not in the manual?

Questions and answers

Related Manuals for Magnacoustics Genesis ULTRA

Summary of Contents for Magnacoustics Genesis ULTRA

  • Page 1: Table Of Contents

    Addendum: Genesis Ultra Install/User Manual EXTERNAL DEVICE CONNECTIONS FOR SYSTEMS WITHOUT AUDIO INPUT ON Appendix A page 18 STEREO Magnacoustics Inc. 1995 Park Street Atlantic Beach NY 11509 QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t...

  • Page 2: Important Safety Instructions

    10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and  the point where they exit from the apparatus.  11) Only use attachments/accessories specified by the manufacturer.  12) Use only with a cart, stand, bracket, or table specified by the manufacturer, or sold with the apparatus. When  a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip‐over.  13) Unplug this apparatus during lightning storms or when unused for long periods of time.  14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged  in any way, such as power‐supply cord or plug is damaged, liquid has been spilled or objects have fallen into the  apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.  15) Warning ‐ this equipment is not waterproof. To prevent a fire or shock hazard, do not place any container  filled with liquid near this equipment (such as a vase or flower pot) or expose it to dripping, splashing, rain or  moisture.  Warning:  This equipment has been certified to comply with the limits for a Class B computing device, pursuant to  Subpart J of Part 15 of FCC Rules.  Only peripherals certified to comply with the Class B limits may be attached to  this equipment.  Operation with non‐certified peripherals is likely to result in interference. This equipment  generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with  the manufacturer’s instructions, may cause interference.   It has been type tested and found to comply with the  limits for a Class B computing device in accordance with the specifications in Subpart J of Part 15 of FCC Rules,  which are designed to provide reasonable protection against such interference.  :  The power switch on this unit will not completely shut off all power from the AC outlet. Since the power cord  serves as the main disconnect device for the unit, you will need to unplug it from the AC outlet to shut down all  the power. Therefore, make sure the unit has been installed so that the power cord can be easily unplugged from  the AC outlet in case of an accident. To avoid fire hazard, the power cord should also be unplugged from the AC  outlet when left unused for a long period of time (for example if facility will not be in operation for a few weeks)   QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t...
  • Page 3 To clean the CD optical pickup mechanism, purchase a Maxell CD-340 CD Lens Cleaner Model: CD-340 from RadioShack Catalog #: 55016610. These are also available from Amazon. QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t...

  • Page 4: Troubleshooting Guide

    Diagnostic 1: Check to be sure there is output from the stereo in Tech area. Cause / Corrective Action 1: Make sure power to stereo is turned on, the Tech Mute is not on and you are on the correct input. If this does not correct the problem contact Magnacoustics Customer Support. ____________________________________________________________________________________ Symptom: Patient Can’t Hear Technologists Speak from our Mic...
  • Page 5 Diagnostic Observation: Tech unit does not respond to any commands Cause / Corrective Action: Re-boot system, by turning rocker switch “J12” off for 10 seconds then back on. If this does not correct the issue please contact Magnacoustics Customer Support. ____________________________________________________________________________________ Symptom: CD not working properly Corrective Action: Refer to CD USE NOTE under Preventative Maintenance on page 3.

  • Page 6: Magnacoil™ Headset & Magnaplug™ Instructions

    10 ~ seconds for the disposable item. Ear infections the more attenuation they will foam to expand before easily. are spread very provide. releasing. MagnaCoil Headset & MagnaPlug Instructions ™ ™ QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t...

  • Page 7: Technologist Control Unit Operation

    This will ensure your patients hearing protection with all coils in addition to allowing your system to meet and / or exceed GE Healthcare’s attenuation requirements. 2. Use of any other headset with your Magnacoustics MRI Music System will NOT work and may cause serious patient safety issues.
  • Page 8 10: The Genesis has a feature called AUTO GAIN this provides the ability to automatically adjust volume level of music to Patients dependent on the amount gradient noise being created by MRI. Technologist Control Unit Operation QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t...
  • Page 9 Pulse High Pulse Low High Held Low Held 15. IR Remote Sony-US/IP 16. IR Remote Dwell 1Sec 2Sec 3Sec 4Sec 17. Restore Defaults 18. Muting IR ON IR OFF QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t...
  • Page 10 Technologist Control Unit Operation QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t 10 |...
  • Page 11 9. Patient volume control Red and Green buttons. 10. Patient selection control Blue and Yellow buttons. 11. CB1 - 90 ft. DB9 Female to Male DB9 Cable (Links Genesis Ultra module to Penetration Panel.) 12. CB2 - 50ft. DB9 Female to Female DB9 Cable (Links from Penetration Panel to Transducer.)

  • Page 12: Genesis Ultra Installation And Connections

    ”SPK1 AUDIO IN on the Genesis Ultra module. Follow the same colors and polarity as you did with the Stereo. Connect one cable CB5 6ft stereo 3.5mm to J1 IN AUDIO on the rear of Genesis Ultra module, and the other side of CB5 to the rear of the stereo marked J1 Audio.
  • Page 13 21: Zip tie cable “CB1” to existing supports, or cables from penetration panel to provide strain relief. 22: Connect Female end of cable “CB1” to J11 on the rear of Genesis Ultra module. 23: From the scan room side of penetration panel, connect cable “CB2” (50ft. DB9 Female to Female) to the RF filter you installed on penetration panel.
  • Page 14 4. Please ensure that the module and stereo AC plugs are connected to outlets that are at the same Ground Potential as the Scanner or Damage to our Equipment and or poor SNR performance will result!! QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t 14 |...
  • Page 15 34: Look at the front panel of the Genesis and ensure the all-8 red LED’s are lit under Circuit A Power and Circuit B Power. If not, unplug the AC power cords and contact Magnacoustics Tech Support at 1-800-637-2282 or E-mail at support@magnacoustics.com...

  • Page 16: Rear Panel

    J7= IR Output to Stereo/TTL PRS output SPK2= Spare Speaker Junction F1, F2, F3, & F4= 4.0 A SB J11 ISO T5.0 A Component Locations and Wiring Pictorial QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t 16 |...
  • Page 17 QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t 17 |...

  • Page 18: Addendum: Genesis Ultra Install/User Manual

    8. Please ensure that the module and stereo AC plugs are connected to outlets that are at the same Ground Potential as the Scanner or Damage to our Equipment and or poor SNR performance will result!! QR 127 Magnacoustics Inc™ © 2014 1-800-637-2282 (inside USA) 516-239-0042 (outside USA) rev-t 18 |...
