Visualisation
Display type
Resolution
Brightness
Contrast ratio (CR)
Background lighting
Mechanical data
Housing dimensions (L x W)
Installation dimensions (W x H x
D)
Installation cut-out (W x H)
Housing material
Weight
Installation
Protection class
Connection
Test standards
Humidity
Vibration
Shock
CE marking
Accessories
Connection cable, 19-pole, 3 m
Deutsch plug set
CANdongle with PC software
ehbTools
MCflex starter kit
CAN dongle, ehbTools,
connecting cable, power supply
unit
1.8
Spare parts
No spare parts are available for this device. If the device is faulty, contact the manufacturer.
Dot matrix LCD, transflective, dark-blue representation,
grey background
16 x 2 characters, 5 x 8 dots per character
>1,000 cd/m²
8.24
LED, white
72 mm x 72 mm
66 mm x 66 mm x 130 mm
66 mm x 66 mm
PA 6 30 GB, black, UV-stabilised
340 g
Mounting bracket or screw-fastening, 3 x M6
IP67
Deutsch connector type HDP24-24-19PE
DIN EN 60068-2-3
DIN EN 60068-2-6
DIN EN 60068-2-27
According to Directive 2014/30/EU
ehb2268
ehb1469
ehb5365
ehb5378
Translation of the original operating instructions • Engine controller MCflex • 08/05/2018 • 3.0 • GB
Spare parts
9
