Naneos PartectorTEM Operation Manual page 7

www.naneos.ch
Supplying power
To charge the partectorTEM or to operate it for periods longer than the
battery lifetime, connect the partectorTEM USB port to a PC or Laptop or
to a USB-Charger to charge the device.
While charging, the blue charge LED on the front panel lights up. When
the partectorTEM is fully charged, it turns off.
Insert / remove SD-card
To store data on the microSD-card, insert it in the partectorTEM as shown
in the graph till it snaps in. To remove the SD-card, press on the inserted
card which will force the release. To insert the card in your SD-card slot
on a PC you need to insert the card first in the SD/SD-card adapter or
SD/USB adapter provided.
Figure 2a: Inserting the SD-
Figure 2 Insert SD-card
card
Turning the device on and off
To turn the device on, press the power button. To turn it off, press and
hold the power button for two seconds and release it when the goodbye
message appears.
Recording measurements on the SD-card
If a SD-card is inserted in the partectorTEM at startup, the device
automatically starts recording on the SD-card when the device is turned
on. It automatically generates a filename depending on start date, time
and device serial. For more information about this, read the "partector data
file" section.
If you insert the SD-card while the device is running, the data
logging will not start automatically. You need to turn the device
on after inserting the card.
Figure 3b: Inserting the SD-card into the adapter
7 | 17
