Installation and Maintenance
Instructions for Drying
JCB30CE, JCB30CG, JCB30CSH, JCB30CSL, JCB30WE, JCB30XG,
SCB30CE, SCB30CG, SCB30CSH, SCB30CSL, SCB30WE and SCB30XG
JC50CE, JC50CG, JC50CSH, JC50EG, JCB50CE, JCB50CG, JCB50CSH,
JCB50EG, SC50CE, SC50CG, SC50CSH, SC50EG, SCB50CE, SCB50CG,
JC75CE, JC75CG, JC75CSH, JCB75CE, JCB75CG, JCB75CSH, SC75CE,
SC75CG, SC75CSH, SCB75CE, SCB75CG and SCB75CSH
ATTENTION: Please read the enclosed instructions before using the machine.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
(If this tumbler changes ownership, be sure this manual
accompanies the tumbler).
A copy of the operating instruction must remain with the tumbler after
installation.
To locate the servicer nearest you, call (414) 748-3121.
Manufactured By:
Speed Queen Company
P.O. Box 990
Ripon, WI 54971-0990
U.S.A.
Tumblers
30 Pound (13 Kg) Capacity
50 Pound (22 Kg) Capacity
SCB50CSH and SCB50EG
75 Pound (34 Kg) Capacity
Part No. M412616
1/95
Distributed By:
Advertisement
Table of Contents
Related Manuals for Speed Queen Drying Tumblers JC50CE
Summary of Contents for Speed Queen Drying Tumblers JC50CE
- Page 1 A copy of the operating instruction must remain with the tumbler after installation. To locate the servicer nearest you, call (414) 748-3121. Manufactured By: Speed Queen Company P.O. Box 990 Ripon, WI 54971-0990 U.S.A. Tumblers 30 Pound (13 Kg) Capacity...
- Page 3 WARNINGS AND LABELS aWARNING FAILURE TO INSTALL, MAINTAIN, AND/OR OPERATE THIS MACHINE ACCORDING TO MANUFACTURER’S INSTRUCTIONS MAY RESULT IN CONDITIONS WHICH CAN PRODUCE SERIOUS INJURY, DEATH AND/OR PROPERTY DAMAGE. NOTE: The WARNING and IMPORTANT instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur.
- Page 4 WARNING To reduce the risk of fire, electric shock, serious injury or death to persons when using your dryer, follow these basic precautions: 1. Do not allow children to play on or in the tumbler. Close supervision of children is necessary when the tumbler is used near children.
-
Page 5: Table Of Contents
TABLE OF CONTENTS NAMEPLATE LOCATION ... 4 REPLACEMENT PARTS INFORMATION ... 4 SECTION I ROUGHING-IN DIMENSIONS AND SPECIFICATIONS 30 pound (13 kg) Narrow Cabinet: Gas Tumblers ...5 Electric Tumblers ...7 30 Pound (13 kg): Gas Tumblers ...9 Electric Tumblers ...11 Steam Tumblers ...13 50 Pound (22 kg): Gas Non-reversing Tumblers ...15... -
Page 6: Nameplate Location
NAMEPLATE LOCATION IMPORTANT When writing for information on any tumbler, be sure to mention model and serial numbers. The model and serial numbers will be found on the nameplate as shown on rear of tumbler or underneath the door hinge. REPLACEMENT PARTS INFORMATION If replacement parts are required, contact the source from whom you purchased your tumbler or, contact the Ripon Service Parts Center, P.O. -
Page 7: Section I
Roughing-In Dimensions and Specifications 30 Pound (13 kg) Narrow Cabinet Gas Tumbler 67.95 cm (26-3/4") 3.81 cm (1-1/2") 81.76 cm (32-3/16") 113.98 cm (44-7/8") DISCONNECT SWITCH 71.12 cm (28") M412616 SECTION I SIDE PANEL T258IE3A 15.24 cm (6") DIAMETER EXHAUST AIR FLOW SWITCH CONNECTION... - Page 8 30 Pound (13 kg) Narrow Cabinet Gas Tumbler Cabinet Finish: Cylinder: Motor: Electrical Requirements: Gas Consumption: Gas Connection: Types of Gas: Air Flow: Net Weight: Electrostatically applied thermosetting polyester. 26.5" x 30" (67.3 cm x 76.2 cm) perforated galvanized steel with three baffles H.P., lifetime lubricated, internal overload protected 230 Volt, 50 Hertz, 1 Phase;...
-
Page 9: Electric Tumblers
30 Pound (13 kg) Narrow Cabinet Electric Tumbler 67.95 cm (26-3/4") 3.81 cm (1-1/2") 81.76 cm (32-3/16") 113.98 cm (44-7/8") DISCONNECT SWITCH ELECTRICAL JUNCTION BOX AIR FLOW SWITCH M412616 T258IE3A 15.24 cm (6") DIAMETER EXHAUST 71.12 cm (28") T259IE3B SIDE PANEL 8.59 cm (3-3/8") - Page 10 30 Pound (13 kg) Narrow Cabinet Electric Tumbler Cabinet Finish: Cylinder: Motor: Electrical Requirements: (See nameplate for voltage of your tumbler) Element: Air Flow : Net Weight: Electrostatically applied thermosetting polyester. 26.5" x 30" (67.3 cm x 76.2 cm) perforated galvanized steel with three baffles H.P., lifetime lubricated, internal overload protected 230 Volt, 50 Hertz, 1 Phase;...
-
Page 11: Pound (13 Kg): Gas Tumblers
30 Pound (13 kg) Gas Tumbler CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... - Page 12 30 Pound (13 kg) Gas Tumbler Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 30" x 30" (76.2 x 76.2 cm) perforated galvanized steel with three baffles; 30 pounds (13.6 kg) dry weight (cotton load) Motor: Electrical Requirements: 230 Volt, 50 Hertz, 1 Phase, 5.5 Amp Gas Consumption: Energy Saver Models —...
-
Page 13: Electric Tumblers
30 Pound (13 kg) Electric Tumbler CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... - Page 14 30 Pound (13 kg) Electric Tumbler Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 30" x 30" (76.2 x 76.2 cm) perforated galvanized steel with three baffles; 30 pounds (13.6 kg) dry weight (cotton load) Motor: Electrical Requirements: 230 Volt, 50 Hertz, 1 Phase, 90 Amp (see nameplate for voltage 230 Volt, 50 Hertz, 3 Phase, 54 Amp of your tumbler)
-
Page 15: Steam Tumblers
30 Pound (13 kg) Steam Tumbler CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... - Page 16 30 Pound (13 kg) Steam Tumbler Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 30" x 30" (76.2 x 76.2 cm) perforated galvanized steel with three baffles; 30 pounds dry weight (13.6 kg) (cotton load) Motor: High Pressure (4 coils) Low Pressure (4 coils) Boiler Horsepower: 4 coil High Pressure –...
-
Page 17: 50 Pound (22 Kg) Gas Non-Reversing Tumblers
50 Pound (22 kg) Gas Non-reversing Tumblers CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... - Page 18 50 Pound (22 kg) Gas Tumblers Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 37" x 30" (94 cm x 76.2 cm) perforated galvanized steel with four baffles; 50 pounds (22.7 kg) dry weight (cotton load) Motor: 1/2 H.P., lifetime lubricated, internal overload protected (Nonreversing Models) (See below for reversing models.) Electrical Requirements:...
-
Page 19: Gas And Steam Reversing Tumblers
50 Pound (22 kg) Gas and Steam Reversing DISCONNECT SWITCH 194.6 cm (76-5/8") AIRFLOW SWITCH MOTOR M412616 Tumblers ELECTRICAL JUNCTION BOX 13.65 cm (5-3/8") 98.1 cm (38-5/8") CYLINDER MOTOR 20.3 cm (8") DIAMETER EXHAUST THIMBLE CONNECTOR (Energy Saver Gas Models) 146.4 cm (57-5/8") 20.3 cm (8") -
Page 20: Electric Non-Reversing Tumblers
50 Pound (22 kg) Electric Non-reversing Tumblers CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... - Page 21 50 Pound (22 kg) Electric Tumblers Cabinet Finish: Cylinder: Motor: (Nonreversing models) Electrical Requirements: (see nameplate for voltage of your tumbler) Element: Air Flow: Net Weight: 50 LB. CYLINDER M412616 Electrostatically applied thermosetting polyester 37" x 30" (94 x 76.2 cm) perforated galvanized steel with four baffles; 50 pounds (22.7 kg) dry weight (cotton load) 1/2 H.P., lifetime lubricated, internal overload protected (See below for reversing models.)
-
Page 22: Electric Reversing Tumblers
50 Pound (22 kg) Electric Reversing Tumblers ELECTRICAL DISCONNECT JUNCTION BOX SWITCH CYLINDER MOTOR 194.6 cm (76-5/8") 20.3 cm (8") DIAMETER EXHAUST THIMBLE CONNECTION AIRFLOW SWITCH 34 cm (13-3/8") 13.65 cm (5-3/8") 98.1 cm MOTOR (38-5/8") T263IE3B M412616... -
Page 23: Steam Non-Reversing Tumblers
50 Pound (22 kg) Steam Non-reversing Tumblers 71.75 cm (28-1/4") 3.81 cm (1-1/2") 81.75 cm (32-3/16") 119.4 cm (47") 38.7 cm (15-1/4") 19.05 cm (7-1/2") 1.9 cm (3/4") I.D. STEAM INLET ELECTRICAL JUNCTION BOX 1.9 cm (3/4") I.D. STEAM OUTLET 13.65 cm 20.3 cm (8") (5-3/8") - Page 24 50 Pound (22 kg) Steam Tumblers Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 37" x 30" (94 x 76.2 cm) perforated galvanized steel with four baffles; 50 pounds (22.7 kg) dry weight (cotton load) Motor: High Pressure Steam — 1/2 H.P. (Nonreversing Models) Low Pressure Steam —...
-
Page 25: 75 Pound (34 Kg) Gas Non-Reversing Tumblers
75 Pound (34 kg) Gas Non-reversing Tumblers DISCONNECT ELECTRICAL JUNCTION BOX CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. -
Page 26: Gas And Steam Reversing Tumblers
75 Pound (34 kg) Gas and Steam Reversing Tumblers ELECTRICAL DISCONNECT JUNCTION BOX SWITCH CYLINDER MOTOR 194.6 cm (76-5/8") 20.3 cm (8") DIAMETER EXHAUST THIMBLE CONNECTION AIRFLOW SWITCH 34 cm (13-3/8") 13.65 cm (5-3/8") MOTOR 98.1 cm (38-5/8") T265IE3B M412616... - Page 27 75 Pound (34 kg) Gas Tumblers Cabinet Finish: Cylinder: Motor: (Non-reversing models) Electrical Requirements Nonreversing Models: Electrical Requirements Reversing Models: Gas Consumption: Types of Gas: Gas Connection: Air Flow: Net Weight: Calorific Value: 75 LB. CYLINDER M412616 Electrostatically applied thermosetting polyester 37"...
-
Page 28: Electric Non-Reversing Tumblers
75 Pound (34 kg) Electric Non-reversing Tumblers CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... -
Page 29: Electric Reversing Tumblers
75 Pound (34 kg) Electric Reversing Tumblers ELECTRICAL DISCONNECT JUNCTION BOX SWITCH CYLINDER MOTOR 194.6 cm (76-5/8") 20.3 cm (8") DIAMETER EXHAUST THIMBLE CONNECTION AIRFLOW SWITCH 34 cm (13-3/8") 13.65 cm (5-3/8") 98.1 cm MOTOR (38-5/8") T263IE3B M412616... - Page 30 75 Pound (34 kg) Electric Tumblers Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 3 7" x 36" (94 x 91.4 cm) perforated galvanized steel with four baffles; 75 pounds (34.1 kg) dry weight (cotton load) Motor: 3/4 H.P., lifetime lubricated internal overload protected. (Non-reversing models) (See below for reversing models.) Electrical...
-
Page 31: Steam Non-Reversing Tumblers
75 Pound (34 kg) Steam Non-reversing Tumblers CLEARANCES: Minimum to nearest Combustible Material Top — 12" (30.5 cm) Minimum. 0" permitted for first 4" (10.2 cm) along front of machine. Back — 0" - 24" (61 cm) Minimum recommended for service access. Sides —... - Page 32 75 (34 kg) Pound Steam Tumblers Cabinet Finish: Electrostatically applied thermosetting polyester Cylinder: 37" x 36" (94 x 91.4 cm) perforated galvanized steel with four baffles; 75 pounds (34.1 kg) dry weight (cotton load) Motor: High Pressure Steam — 3/4 H.P. (Non-reversing models) Low Pressure Steam —...
-
Page 33: Installation Instructions
Installation Instructions RECEIVING INSPECTION Upon delivery, visually inspect crate carton and parts for any visible shipping damage. If crate, carton or cover are damaged or signs of possible damage are evident, have carrier note condition on shipping papers before shipping receipt is signed, or advise carrier of condition as soon as it is discovered. -
Page 34: Make-Up Air
Proper sized exhaust ducts are essential for proper operation. All elbows should be sweep type. Do not install elbows with a radius less than shown in table below. Exhaust ducts must be assembled so interior surfaces are smooth to reduce accumulation of lint. Do not use sheet metal screws to join vent sections. - Page 35 WARNING WARNING WARNING WARNING WARNING Solvent gases and vapors from dry cleaning machines create acids when drawn through the heater of a drying tumbler. These acids are corrosive to the drying tumbler as well as to the laundry load being dried. Be sure make-up air is free of solvent gases and vapors.
- Page 36 VERTICAL EXHAUST INSTALLATION WALL CONNECT TO TUMBLER 2" (5.1 cm) MINIMUM NOTE: WHERE THE EXHAUST DUCT PIERCES A COMBUSTIBLE WALL OR CEILING, AN OPENING HAVING A DIAMETER FOUR INCHES (10.2 cm) LARGER THAN THE DIAMETER OF THE EXHAUST DUCT SHALL BE PROVIDED, AND THE EXHAUST DUCT CENTERED WITHIN THE OPENING.
-
Page 37: Electrical Requirements
ELECTRICAL REQUIREMENTS For 30 Pound (13 kg) Narrow Cabinet Tumblers REQUIREMENTS Heat Source Electrical Specs 230-50-1 Electric 230-50-1 Electric 230-50-3 Electric 380-50-3 Electric 415-50-3 GAS DRYING TUMBLERS Minimum Wire Size Circuit Breaker No. of Poles ELECTRIC DRYING TUMBLERS 240V 50 Hz. 1 Ph Amp Rating 91 Amp Circuit Breaker... -
Page 38: Pound (13 Kg) Tumblers
ELECTRICAL REQUIREMENTS For 30 Pound (13 kg) Tumblers REQUIREMENTS Heat Source Electrical Specs Gas & Steam Electric Electric Electric Steam GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS Minimum Wire Size Circuit Breaker Poles ELECTRIC DRYING TUMBLERS NOTE: DO NOT use aluminum wire. - Page 39 30 Pound (13 kg) Tumblers LOW STEAM DRYING TUMBLERS LOW PRESSURE STEAM DRYING TUMBLERS Minimum Wire Size Circuit Breaker Poles GROUNDING INSTRUCTIONS Drying tumbler must be grounded. In event of malfunction or breakdown, grounding will reduce risk of electric shock by providing a path of least resistance for electric current. Drying tumbler must be connected to a grounded metal, permanent wiring system;...
-
Page 40: Pound (22 Kg) Tumblers
ELECTRICAL REQUIREMENTS For 50 Pound (22 kg) Tumblers REQUIREMENTS Heat Source Non-Reversing Models Gas & Steam Steam Electric Electric Reversing Models Gas & Steam Gas & Steam Electric Electric GAS AND HIGH PRESSURE STEAM DRYING TUMBLER GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS Minimum Wire Size Circuit Breaker Poles... - Page 41 50 Pound (22 kg) Tumblers LOW PRESSURE STEAM DRYING TUMBLERS LOW PRESSURE STEAM DRYING TUMBLERS Minimum Wire Size Circuit Breaker Poles GROUNDING INSTRUCTIONS Drying tumbler must be grounded. In event of malfunction or breakdown, grounding will reduce risk of electric shock by providing a path of least resistance for electric current.
-
Page 42: Pound (34 Kg) Tumblers
ELECTRICAL REQUIREMENTS For 75 Pound (34 kg) Tumblers REQUIREMENTS Heat Source Electrical Specs Gas & Steam 230/50/1 Electric 208-230/50-60/3 Electric 380/50/3 Electric 415/50/3 Steam 380/50/3 GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS Minimum Wire Size Circuit Breaker Poles ELECTRIC DRYING TUMBLERS... -
Page 43: Electrical Connections
ELECTRICAL CONNECTIONS WARNING All electrical connections should be made by a qualified electrician. To reduce the risk of electrical shock, de-energize the electrical circuit being connected to the tumbler before mak- ing any electrical connections. Never attempt to connect a live circuit. Use the following steps to connect electrical service to the tumbler: 1. -
Page 44: Positioning The Drying Tumbler
POSITIONING DRYING TUMBLER Tumbler may be removed from skid before moving to installation location or moved while still attached to skid. Remove tumbler from skid by unscrewing four shipping capscrews (one at each corner) and remove tumbler from skid. Lint panel door will have to be removed in order to remove two front capscrews. -
Page 45: Example Of Gas Loop Piping
Example of Gas Loop Piping IMPORTANT: Gas loop piping must be installed as illustrated to equalize gas pressure for all tumblers connected to single gas service. Other gas using appliances should be connected upstream from loop. MAIN REGULATOR METER GAS WATER HEATERS IMPORTANT: Line pressure must be maintained at 6-1/2"... - Page 46 GAS PIPE SIZE REQUIRED FOR 1,000 BTU NATURAL GAS — .64 SPECIFIC GRAVITY AT 6½ 1½ INCH WATER COLUMN PRESSURE (1.62 ± .37 kPa) 25 FT. (7.63 m) APPLIANCES TOTAL BTU/HR. (Kcal/hr) BASED ON 0.3" WATER COLUMN (0.75 mBar) PRESSURE DROP FOR LENGTH GIVEN 100,000 (25,200) "...
-
Page 47: Gas Connections (Gas Drying Tumblers)
GAS CONNECTIONS (Gas Drying Tumblers) Before connecting gas piping to tumbler, make certain gas service is same as that specified on nameplate (near gas connection), Page 5. NATURAL GAS service must be supplied at 6 inch water column pressure (1.62 L.P. -
Page 48: Drying Tumbler Enclosure Construction
DRYING TUMBLER ENCLOSURE CONSTRUCTION IMPORTANT: DO NOT block airflow at top rear of tumbler with laundry, etc. Doing so would prevent adequate air supply to tumbler’s heat chamber. A typical tumbler enclosure is shown in Figure 23. Note that enclosure does touch tumbler top and side panels. -
Page 49: Steam Requirements (Steam Drying Tumblers)
STEAM REQUIREMENTS (Steam Drying Tumblers) Size of steam service pipe is dependent upon many variables (length, tees, high pressure system, low pressure system, etc.) Specific pipe size STEAM CONNECTIONS (Steam Drying Tumblers) INSTALLING STEAM SOLENOID VALVE AND MAKING STEAM INLET CONNECTIONS High pressure machines require a (constant) 80 to 100 psig (5.62 to 7.03 kg/sq. - Page 50 STEAM CONNECTIONS (Steam Drying Tumblers) NOTE: See Figure 25 for sizing of steam lines. Piping must also be sized accordingly for length of runs, and number of elbows. SUPPLY STEAM BONNET RELIEF VALVE SOLENOID VALVE (Supplied with machine) OPTIONAL VACUUM BREAKER TUMBLER STEAM PRESSURE...
-
Page 51: Lighting And Shutting Down Gas Ignition System
LIGHTING AND SHUTTING DOWN GAS IGNITION SYSTEM 1. Turn machine disconnect switch, located on rear of tumbler, to the “on” position. 2. Turn gas shut-off valve, located on rear of tumbler, to the “on” position (gas valve handle should be parallel with gas line). 3. -
Page 52: Accessory Timing Cam Installation
ACCESSORY TIMING CAM INSTALLATION (Coin Meter Models) Cycle Length (Minutes) No. of Pins in Cam Figure 27 Cams that allow other timer increments are available through your distributor. To figure time increments, use this formula: Timer Motor Speed (60) divided by number of pins on cam = Cycle Length (minutes). -
Page 53: Preliminary Operating Checks
PRELIMINARY OPERATING CHECKS 1. Remove or open all panels and inspect accessible bolts, nuts, screws, terminals and fittings for security. 2. Check belt tension, adjust if necessary (refer to Adjustment Section). 3. Energize electrical circuit to tumbler circuit breaker and turn on tumbler disconnect switch. 4. - Page 54 NOTES M412616...
-
Page 55: Adjustments
MAIN GAS BURNER AIR SHUTTER (All Gas Models) NOTICE: Both air inlet shutters on burner must be adjusted so sufficient air is metered into system for proper combustion and maximum efficiency. Before adjusting inlet shutters be sure that all lint is removed from lint compartment and lint screen. - Page 56 Electric Models: If switch remains open, or pops open and closed during cycle, heating system will shut off. Cylinder and fan will continue to operate even though air flow switch is malfunctioning. Gas Models: If switch remains open, entire unit will shut down when Push-to-start button is released.
-
Page 57: Loading Door Switch
LOADING DOOR SWITCH Loading door switch turns off tumbler any time loading door is opened. To adjust loading door switch, follow these steps: 1. Start tumbler following operating instructions which accompanied it. 2. Slowly open loading door. Cylinder and heating system should stop when door is open 3"... -
Page 58: Drive V-Belt
DRIVE V-BELT WARNING To reduce the risk of serious injury or death, disconnect power to the tumbler before performing this operation. Proper tension is when belt can be depressed approximately inch (1.27 cm) by applying light thumb pressure at a point midway between the sheave and motor pulley. -
Page 59: Preventive Maintenance Instructions
Preventive Maintenance Instructions DAILY 1. Make certain drying cycle has ended. 2. Open loading door. 3. Unlock and remove lint panel. 4. Remove accumulated lint in lint compartment. Lint left in lint compartment will be drawn back onto lint screen and restrict air circulation. 5. -
Page 60: Quarterly
Quarterly 1. Deactivate electrical circuit by turning off disconnect switch on rear of tumbler. 2. Perform daily cleaning of accumulated lint. 3. Perform monthly inspection and cleaning of accumulated lint. 4. Clean accumulated lint and other debris from front and back motor air vents. 5. -
Page 61: Maintenance Check Chart
QUARTERLY MAINTENANCE Clean air vents on drive motor. Check and clean steam coils. (Steam Models Only) Clean exhaust ducts. Check flow of combustion air. Check flow of ventilation air. Check belt tension. Check chain tension. BIANNUAL MAINTENANCE Check for loose nuts. Check for loose bolts. - Page 62 NOTES M412616...
-
Page 63: Decommissioning Instructions
SECTION V Decommissioning Instructions 1. Turn off electrical supply external to machine. 2. Turn off electrical disconnect on machine. 3. Turn off gas supply external to machine. 4. Turn off manual gas shut-off valve on machine. 5. Turn off steam supply external to machine. 6. - Page 64 NOTES M412616...
- Page 65 M412616...
- Page 66 M412616...
