Stealth Series Dual Band Booster Amplifiers
BRB Stealth Z1
User Manual
COTTAGES
BUILDINGS
Increases your Cellular and PCS Band
Signals, expands your service coverage
area, enhances voice call quality and
significantly increases Data speeds.
HOMES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stealth Z1 and is the answer not in the manual?

Questions and answers

Related Manuals for SmoothTalker Stealth Z1

Summary of Contents for SmoothTalker Stealth Z1

  • Page 1 ® Stealth Series Dual Band Booster Amplifiers BRB Stealth Z1 User Manual COTTAGES BUILDINGS Increases your Cellular and PCS Band Signals, expands your service coverage area, enhances voice call quality and significantly increases Data speeds. HOMES...

  • Page 2: Table Of Contents

    Table of Contents Kit Type Configurations................3 Optional parts....................3 Antenna and Booster Installation............4 Installation Illustrations................5 Control panel ....................6 LED lights - Outside signal level/RX power..........6 Frequently asked questions..............7 Troubleshooting guide................7 Inside Antennas ....................8 Outside Antennas ..................8 Splitters/Power Dividers................8 Extention Cables ..................9 Specifications....................11 Glossary of terms..................12 FCC Information..................12...

  • Page 3: Kit Type Configurations

    Package Contents BRBZ Series (Individual Kit Configuration Parts Included Vary By Model) Typical Configuration Outdoor Antenna Indoor Antenna Main Booster Unit AC/DC Power Supply NOTE : Your model may ship with different antennas. Optional Parts Co-Ax Cables RF Splitter/Power Divider Co-Ax Adapters Antenna Pole Mount Kit 2”...

  • Page 4: Antenna And Booster Installation

    If outside signal is poor or marginal, splitting signal to more than one distribution antenna results in decreased coverage for both distribution antennas. Use only genuine SmoothTalker splitters. Contact your dealer or www.smoothtalker.com Amplifier/Booster Location: Install the repeater in a location that has proper ventilation, away from excessive heat and moisture.

  • Page 5: Installation Illustrations

    Fig. 1 Directional antennas separation distance - Close Omni directional antennas separation distance - Far Fig. 2 Fig. 3 Fig. 4 Pg. 5...

  • Page 6: Control Panel

    Control Panel: Understanding the Control Panel and LED lights General: Mobile networks, phones and data devices operate in two frequency bands (800Mhz & 1900Mhz). The Stealth Booster will amplify signals in both bands if they are present. The band that the phone or cellular data device will transmit (TX) and receive (RX) on is determined by the cellular provider and cannot be chosen by the user.

  • Page 7: Frequently Asked Questions

    TX power (pg 5). Will the booster boost signals from service providers other than mine? Yes. Smoothtalker Stealth series boosters are wideband RF amplifiers that will improve all Cellular and PCS signals in your area.

  • Page 8: Inside Antennas

    FCC Rules specify that all approved antennas, cables and accessories to be used with this booster are to be listed in this manual. The approved accessories are listed below. Inside Antennas Minimum Maximum Net Gain Antenna Description Cable Cable Loss Antenna (dB) (dB)

  • Page 9: Extention Cables

    Extension Cables Minimum Cable Part # Description Cable Cable loss (dB) SEMRCBXmaXfe10 extension cable 10 ft. SEMRC205 -1.00 SEMRCBXmaXfe20 extension cable 20 ft. SEMRC205 -2.00 SEMRCBXmaXfe30 extension cable 30 ft. SEMRC205 -3.00 SEMRCBXmaXfe40 extension cable 40 ft. SEMRC205 -4.00 SEMRCBXmaXfe50 extension cable 50 ft.
  • Page 10 Extension Cables (continued) Minimum Cable Part # Description Cable Cable loss (dB) SEMRCBGmaGfe60 extension cable 60 ft. RG6 -5.40 SEMRCBGmaGfe70 extension cable 70 ft. RG6 -6.30 SEMRCBGmaGfe80 extension cable 80 ft. RG6 -7.20 SEMRCBGmaGfe90 extension cable 90 ft. RG6 -8.10 SEMRCBGmaGfe100 extension cable 100 ft.

  • Page 11: Specifications

    Specifications Operational Bands 800MHz Cellular and 1900MHz PCS Impedance 50 Ohms TX Output Power 29.9 dBm EIRP RX Output Power 11.0 dBM EIRP Oscillation Control (Automatic) 35 dB in 1db steps Oscillation Control Timing < 1 sec RX High Power Control Dynamic up and down <...

  • Page 12: Glossary Of Terms

    2-User changes changes or modifications will void warranty. Warranty Smoothtalker boosters are warranted against manufacturing defects for a period of one year from the date of purchase. The original bill of sale is required for any warranty claims. For warranty claim contact original dealer or smoothtalker.com...
