DEHUMIDIFIER
DUE - 1239
Owner's Manual
READ THESE INSTRUCTIONS CAREFULLY BEFORE OPERATING THE APPLIANCE
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
1

Advertisement

loading

Summary of Contents for UNITED DUE-1239

  • Page 1 DEHUMIDIFIER DUE - 1239 Owner’s Manual READ THESE INSTRUCTIONS CAREFULLY BEFORE OPERATING THE APPLIANCE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE...
  • Page 2 This unit removes unwanted moisture from the air to create a more comfortable environment in your home or office. It can be conveniently moved from room to room within your home. FEATURES Powerful Dehumidifying Capability Taking advantage of refrigeration technology, the dehumidifier powerfully removes moisture from the air to decrease the humidity level of the room and keep the indoor air dry and comfortable.
  • Page 3: Safety Warnings

    SAFETY WARNINGS When using the unit, please observe the following safety precautions: 1. Unplug the power supply cord before cleaning or storing. 2. This appliance can be used indoors but not in laundry rooms. 3. Do not set the unit close to heat-generating devices or near flammable and dangerous materials.
  • Page 4 17. Appliances that are obviously damaged must not be operated. WARNING Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater).
  • Page 5 For any repairs you need, contact the nearest authorized Service Centre and strictly follow the manufacturer’s instructions only. B Warning for disposal: It is prohibited to dispose of this appliance in domestic household waste. For disposal there are several possibilities 1.
  • Page 6 C Technical Data SPECIFICATIONS Model DUE-1239 Power Supply 220V-240V~50Hz Water Tank Capacity Refrigerant/charge R290/50g The dehumidification capacity is rated at a room temperature of 30℃ with a relative humidity of 80%. If specifications are improved after this pointing, the product nameplate will reflect the new specifications.
  • Page 7: Product Diagram

    PRODUCT DIAGRAM Parts 1. Air Outlet 2. Display Screen 3. Control Panel 4. Handle 5. Filter Box 6. Water Tank 7. POWER CORD 8. CASTER Water Pipe...
  • Page 8 OPERATING INSTRUCTIONS Display Screen Colorful Halo Led Display The front display screen has a 3 color halo (Red、Blue、Purple). When you turn on the unit, the halo will be lighted. If the environment humidity is higher than 70%, it will show red color If the environment humidity is lower than 50%, it will show purple color If the environment humidity is between 50% to 70%, it will show blue color...
  • Page 9 Button Function OPERATING INSTRUCTIONS : 1. The Buzzer will alarm when the unit starts on, the LED will show the Room Humidity for 3 second, then the PCB will automatically off. 2. Press button once to start operation. The first 20 seconds will show the room temperature, the next 20 seconds will show the environment humidity.
  • Page 10 40% in the dehumidifying mode. The default dehumidifier setting for the dehumidifier mode is 40% 5. Press to set the timer function: Press to set the auto turn-on time when the unit is in stand-by mode and switched on, the LED will display the time set from 1-24 hours, so the unit will auto turn on after the setting time.
  • Page 11 NOTE Do not remove the float from the water tank. The water full sensor will no longer be able to detect the water level correctly without the float and water may leak from the water tank. If the drainage tank is dirty, wash it with cold or lukewarm water. Do not use any detergent, scouring pads, chemically treated dust cloths, gasoline, benzene, thinner, or other solvents, as these can scratch and damage the tank and cause water leakage.
  • Page 12: Maintenance

    Continuous Water Drainage The unit features a continuous drainage port. Using a plastic pipe (with an inner diameter of 10mm) insert it into the drain hole (on intermediate plate), reach out from the side of the water tank, install it in place, and arrange the drain pipe. The water in the drainage tank can be continuously drained out from the continuous port on the unit.
  • Page 13 2. Clean the air filter Run a vacuum cleaner lightly over the surface of the air filter to remove dirt. If the air filter is exceptionally dirty, wash it with warm water and a mild cleanser and dry thoroughly. 3. Attach the air filter Insert the filter into the grill smoothly, and place the inlet grill into the right position Storing the Dehumidifier When the unit is not being used for a long period of time and you want to store it note...
  • Page 14: Troubleshooting

    TROUBLESHOOTING If a condition listed below occurs, please check the following items before calling customer service. Problem Possible Cause Solution Has the power cord been Plug the power cord disconnected? into the outlet. Is the tank full indication Empty the water in the lamp blinking? (The tank The unit doesn't drainage tank and then...
  • Page 15 NOTE FOR MAINTENANCE WORK 1.Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repairs on the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
  • Page 16 are no flammable hazards or ignition risks. “No Smoking” signs must be displayed. 6.Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out.
  • Page 17 the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
  • Page 18 Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. 13.Leak detection methods The following leak detection methods are acceptable for systems containing flammable refrigerant.
  • Page 19 Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system.
  • Page 20 c) Before attempting the procedure ensure that: mechanical handling equipment is available, if repaired, for handling refrigerant cylinders; all personal protective equipment is available and being used correctly; the recovery process is supervised at all times by a competent person; recovery equipment and cylinders conform to the appropriate standards.
  • Page 21 The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants. In addition, a set of calibrated weighing scales shall be available and in good work order.
  • Page 22 ErP Directive 09 / 125 / EC CE Marking: 93 / 68 / EEC RoHS Directive: 11 / 65 / EU & Delegating Directive (EU) 15 / 863 The detailed declaration of conformity can be found at www.united-electronics.gr Importer: Kalliopi Karyda & Co, LP 87A, 17 Noemvriou str, P.C.
