Redkite Baby Go Round Twist Instruction Leaflet page 3

4. Line up the six fixing pegs on the
rear of the seat fabric with the six
square holes around the rear of the
top tray and push firmly down until they
click in place. FIg 4.
Fig 4a. Check underneath the walker
to ensure the pegs are fully through
and secure Fig 4a. Push the three front
pins on the seat fabric in to the three
keyholes and then push downwards
Fig 4b. Check underneath the walker
to ensure all three pins are locked in
place. FIg 4c. There should be no visible
gap below the pins.
5. Place the toy tray in to the recess
fig 5 and lock it in place by pushing the
2 keys underneath upwards and then
turning 90 degrees. Fig 5a.
6. Insert the remaining toys in to the
corresponding holes on the toy tray
and main frame. Fig 6.
7. Slot the musical car toy in to the toy
tray and slide the lever to the side to
lock it in place. Fig 7.
Height adjustment and folding
8. Turn the button 90 degrees and
press it in. Keep it pressed in and raise
or lower the walker to the desired
position. Fig 8.
The padded foot mat
can be used whilst the
Baby Go Round Wizz
is in rocker mode to
protect baby' s feet.
Attach it to the walker
base with the hooks
provided.
Fig 4
Fig 4a
Fig 4b
Rear pegs Front pegs
Fig 5
Fig 6
Fig 8
Turn the button 90 degres
Fig 4c
Assembeled
Fig 5a
Locking key
Fig 7
7
Musical car toy
