Redkite Baby Go Round Twist Instruction Leaflet page 2

Parts list
1. Main frame
2. Friction strips x 6
3. Rear wheels x 2
4. Front wheels x 2
5. Seat fabric
6. Toy tray
7. Musical car toy
8. Tray toys
9. Main frame toys
10. Padded foot mat (not shown)
Assembly instructions
1. With the walker upside down, push the
six friction strips in to the base of the
walker. Fig 1.
2. Push the front and rear wheels in to
the corresponding holes in the base of
the walker. Fig 2.
3. Turn the walker over and lift the top
tray upwards until it clicks in place. Fig 3.
To change from a walking to a
rocking base
Lift the knobs and swivel 90
degrees.
1
2
Tools required for assembly: Cross head screwdriver (not supplied).
Fig 1
Fig 2
4
Fig 3
7
8
4
3
2
3
4
Lift
5
6
9
3
