- Page 1 Manual EN Installation instructions hook bolt lock, Lock M 161911-01...
-
Page 2: Table Of Contents
Tools and aids ........................................5 Torques ..........................................5 Installation .................................6 Installing hook bolt lock Lock M in the main closing edge .......................6 Installing the strike plate in the main closing edge or post profile ....................8 Post installation, 1-leaf ....................................9 Service and maintenance ..........................13... -
Page 3: Symbols And Illustrations
à The country-specific laws and regulations are to be observed during safety-related tests. à If unauthorised changes are made to the system, GEZE cannot be held liable in any way whatsoever for any resulting damage, and the approval for use in escape and rescue routes ceases. -
Page 4: Safety Conscious Working
Safety notices Hook bolt lock, Lock M Safety conscious working à Secure workplace against unauthorised entry. à Watch swivelling range of long system parts. à Never carry out work with a high safety risk (e.g. installing the drive, cover or door leaf ) while alone. -
Page 5: Overview
Hook bolt lock, Lock M Overview Overview Diagrams Drawing no. / Mat. no. Designation 70487-0-007 Drive drawing SLT 70504-9-0981 Drive drawing EC 70504-0-001 70506-0-001 Drive drawing PL 70506-9-0960 70511-9-0953 Drive drawing SL NT 70511-0-001 70715-9-9864 Leaf drawing SL NT 70715-9-9865... -
Page 6: Installation
Before the work described below is done, the moving leaves must be adjusted properly. Installing hook bolt lock Lock M in the main closing edge 3.1.1 Installing hook bolt lock Lock M in the main closing edge, without pushing rosette M5 x 30 / SW3 M5 ×... - Page 7 Hook bolt lock, Lock M Installation 3.1.2 Installing hook bolt lock Lock M in the main closing edge, with pushing rosette M5 x 30 / SW3 M5 × 30 / SW3 3 Nm 3 Nm M5 x 35 / SW3 M5 ×...
-
Page 8: Installing The Strike Plate In The Main Closing Edge Or Post Profile
Installation Hook bolt lock, Lock M Installing the strike plate in the main closing edge or post profile Screw the M5 screw (2) into the strike plate (1). Thread the strike plate (1) with M5 screw into the main closing edge of the moving leaf (2- leaf ) or post profile (1-leaf ). -
Page 9: Post Installation, 1-Leaf
Hook bolt lock, Lock M Installation Post installation, 1-leaf 3.3.1 1-leaf system at a wall corner with or without side part 1-leaf, right-closing The illustrations below show the version 1-leaf right-closing. Implementation of the 1-leaf left-closing version is reversed accordingly. - Page 10 Installation Hook bolt lock, Lock M Use 4 screws (5) to screw the side screen profile (4) provisionally to the square post. Adjust the position of the side screen profile (4) and square post (2) in relation to the door leaf, underlay to- wards the wall if necessary.
- Page 11 Hook bolt lock, Lock M Installation Adjusting the height in relation to the door leaf Adjust the position of the lower edge of the side screen profile post to 4 mm below the side screen profile leaf 4 mm 4 mm 3.3.2 1-leaf system in front of a continuous wall, right- or left-closing...
- Page 12 Installation Hook bolt lock, Lock M Mount the wall profile (3) with screws (4) on the wall, underlay if necessary. Screw the side screen profile (2) with screws (5) through the wall profile (3) on the wall.
-
Page 13: Service And Maintenance
Hook bolt lock, Lock M Service and maintenance Adjusting the height in relation to the door leaf Adjust the position of the lower edge of the side screen profile post (2) to 4 mm below the side screen profile leaf (6) - Page 14 Troubleshooting Hook bolt lock, Lock M...
- Page 15 Hook bolt lock, Lock M...
- Page 16 E-Mail: danmark.se@geze.com Tel. +49 (0) 7152 203 594 www.geze.at www.geze.hu www.geze.dk E-Mail: leonberg.de@geze.com Baltic States Iberia Singapore GEZE GmbH Baltic States office GEZE Iberia S.R.L. GEZE (Asia Pacific) Pte, Ltd. GEZE GmbH E-Mail: office-latvia@geze.com E-Mail: info@geze.es E-Mail: gezesea@geze.com.sg Niederlassung Süd-Ost www.geze.com www.geze.es...
