Summary of Contents for Black & Decker 90559281

  • Page 1 GKC1817 GKC1817P GKC1817NM
  • Page 2 English (Original instructions)
  • Page 5: Intended Use

    Intended use ENGLISH Your Black & Decker Compact Chainsaw has been designed for light duty cutting and pruning. This tool is intended for consumer use only. Safety instructions General power tool safety warnings Warning! Read all safety warnings and all instructions.
  • Page 6 d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation.
  • Page 7 Make a fresh cut every time. We strongly recommend you do not attempt to operate  your chainsaw while in a tree, on a ladder or on any other unstable surface. If you decide to do so, be advised that these positions are extremely dangerous.
  • Page 8 Vibration The declared vibration emission values stated in the technical data and the declaration of conformity have been measured in accordance with a standard test method provided by EN 60745 and may be used for comparing one tool with another. The declared vibration emission value may also be used in a preliminary assessment of exposure.
  • Page 9 Do not probe the charger.  The appliance/tool/battery must be placed in a well  ventilated area when charging. Labels on the charger The following symbols are found on your charger:  Read the instruction manual before use. The charger automatically shuts off if the ambient temperature becomes too high.
  • Page 10 The battery (10) will be fully charged in approximately 8 hours. It can be removed at any time or left in the connected charger indefinitely. 1 hour charger (fig. C) To charge the battery (10), remove it from the tool and ...
  • Page 11 Switching on and off (fig. H) For your safety, this tool is equipped with a double switching system. This system prevents starting the tool inadvertently. Switching on Press the lock-off button (2) and at the same time  squeeze the on/off switch (1). Release the lock-off button (2).
  • Page 12 Saw chain tension Regularly check the saw chain tension. What to do if your chainsaw needs repair. Your tool is in accordance with the relevant safety requirements. Repairs should only be carried out by a qualified person using original spare parts otherwise this may result in considerable danger to the user.
  • Page 13 Technical data GKC1817 H1 Input voltage Vdc 18 No load chain speed min Weight kg 2 Battery Model GKC1817 Voltage Vdc 18 Capacity Ah 1.5 Weight kg 0.8 Charger TPCA-240080*1 Model GKC1817, GKC1817P GKC1817NM Input voltage Vac 200-240 Output voltage Vdc 18 Output current mA 800...
  • Page 14: Ec Declaration Of Conformity

    EC declaration of conformity MACHINERY DIRECTIVE OUTDOOR NOISE DIRECTIVE GKC1817, GKC1817P, GKC1817NM Black & Decker declares that these products described under "technical data" are in compliance with: 2006/42/EC, EN60745-1, EN60745-2-13 For more information, please contact Black & Decker at the following address or refer to the back of the manual.
  • Page 16 Mt Wellington Auckland 1060 United Kingdom Black & Decker 210 Bath Road Slough, Berkshire SL1 3YD 90559281 REV 0 ENGLISH product code to Black & Decker in your country. Tel. 03-8720 5100 Fax 03-9727 5940 Tel. +64 9 259 1133 Fax +64 9 259 1122 Tel.
