MANUFACTURED BY
ROBAND AUSTRALIA PTY LTD
ASSEMBLY INSTRUCTIONS
STAINLESS STEEL FOOD BAR TROLLEYS &
PANELS
Models: ET22, ET23, ET24, ET25 & ET26
ETP22, ETP23, ETP24, ETP25 & ETP26
Version 2 Units
®
These instructions cover the models of ROBAND
Stainless steel trolleys and
panels listed above. Although there are slight variances between them, the
installation, operation, care and maintenance procedure is the same for all.
Advertisement
Related Manuals for ROBAND ET22
Summary of Contents for ROBAND ET22
- Page 1 MANUFACTURED BY ROBAND AUSTRALIA PTY LTD ASSEMBLY INSTRUCTIONS STAINLESS STEEL FOOD BAR TROLLEYS & PANELS Models: ET22, ET23, ET24, ET25 & ET26 ETP22, ETP23, ETP24, ETP25 & ETP26 Version 2 Units ® These instructions cover the models of ROBAND Stainless steel trolleys and panels listed above.
- Page 2 Quantities ET22 ET23 ET24 ET25 ET26 Diagrams Parts No.’s/Contents 4 x DC0103 Pre Assembled bag Packed in castor box 4 x DC0104 8 x PC0326 4 X MS0427– 455mm Vertical Frame (preassembled) 4 x DC0103 4 x DC0104 4 x MC0761 4 X MS0428- 504.5mm...
-
Page 3: Installation
INSTALLATION Remove all the packaging materials and tape, as well as any protective plastic from the unit. Clean off any glue residue left over from the protective plastic using methylated spirit. Do not remove the double-sided adhesive tape at this stage. Tools To assemble the trolley the following tools are required. - Page 4 2. Select the 3 bars above labelled above and start to assemble the trolley frame. Insert the joiner into the vertical leg of the trolley (labelled MC0427) the flat straight side of the joiner should face to the front. The legs should fit tightly into the joiner you may need so use the mallet to gently tap into place.
- Page 5 4. Now that this corner of the frame is together, connect the 3 other corners this way. Again not screwing them together. 5. Insert Joiners into the other end of the vertical bars again making sure the joiners flat ends are flush. Page 5...
- Page 6 6. As in the previous steps attach the joiners and blanking plug to the corners. Now attach the castors using the screws provided. Use the Allen key to tighten the screws as in the following diagram. Note that the screws for the castors will form their own thread as they are screwed into the legs.
- Page 7 7. Now flip the trolley over carefully, and insert the screws into the top joiner covers, and tighten. Again, the screws will form their own thread in the extruded legs as the screw is tightened. Your trolley frame should now be tightly secured together and resemble the diagram below.
- Page 8 Inserting Shelf Panels ET series trolleys are supplied with the shelf panels. Refer to page 1 for quantities. Note that ETI series trolleys do not have shelf panels supplied. Note: If you have purchased ETP panels with your trolley then assemble those panels first, before you install the shelf panels.
- Page 9 ETP Series optional panels. ETP Series panels (charges additional) ET Series panels Shelf Shelf Front Outer Front Centre Size End Panels Outer Centre Panels Panels Panels Panels Note: All ETP panels are supplied with double sided tape to fix them in position. This tape should be stuck to the trolley frame rail at the top of the frame not to the rail closest to the castors.
- Page 10 The Dark Panels illustrate how the front and end panels rest on the trolley frame. 3. Lastly, fit the shelf panels in place. Refer to page 8. Page 10...
- Page 11 NOTES This page is intentionally left blank. Please note your favourite settings here. Page 11...
- Page 12 NOTES This page is intentionally left blank. Please note your favourite settings here. Page 12...
